R422 BIRC823010500 C RESISTOR 82K Ω 1/10W
R423 BIRC224010500 C RESISTOR 220K Ω 1/10W
R424 BIRC223010500 C RESISTOR 22K Ω 1/10W
R425 BIRC222010500 C RESISTOR 2.2K Ω 1/10W
R426 BIRC222010500 C RESISTOR 2.2K Ω 1/10W
R427 BIRC222010500 C RESISTOR 2.2K
Ω 1/10W
R428 BIRC1230085M00 C RESISTOR 12 K
Ω 1/8W
R429 BIRC1230085M00 C RESISTOR 12 K Ω 1/8W
R430 BIRC182010500 C RESISTOR 1.8K Ω 1/10W
R431 BIRC222010500 C RESISTOR 2.2K Ω 1/10W
R432 BIRC1520085N00 C RESISTOR 1.5K Ω 1/8W
R433 BIRC103010500 C RESISTOR 10K Ω 1/10W
R434 BIRC102010500 C RESISTOR 1K Ω 1/10W
R435 BIRC102010500 C RESISTOR 1K Ω 1/10W
R436 BIRC102010500 C RESISTOR 1K Ω 1/10W
R437 BIRC102010500 C RESISTOR 1K Ω 1/10W
R438 BIRC222010500 C RESISTOR 2.2K Ω 1/10W
R439 BIRC182010500 C RESISTOR 1.8K Ω 1/10W
R440 BIRC153010500 C RESISTOR 15K Ω 1/10W
R441 BIRC153010500 C RESISTOR 15K Ω 1/10W
R442 BIRC222010500 C RESISTOR 2.2K
Ω 1/10W
R443 BIRC222010500 C RESISTOR 2.2K
Ω 1/10W
R444 BIRC3320085M00 C RESISTOR 3.3K Ω 1/8W
R445 BIRC472010500 C RESISTOR 4.7K Ω 1/10W
R446 BIRC151010500 C RESISTOR 150 Ω 1/10W
R447 BIRC3320085M00 C RESISTOR 3.3K Ω 1/8W
R448 BIRC472010500 C RESISTOR 4.7K Ω 1/10W
R449 BIRC151010500 C RESISTOR 150 Ω 1/10W
R450 BIRC332010500 C RESISTOR 3.3K Ω 1/10W
R451 BIRC102010500 C RESISTOR 1K Ω 1/10W
R452 BIRC4720085M00 C RESISTOR 4.7K Ω 1/8W
R453 BIRC1220085M00 C RESISTOR 1.2K Ω 1/8W
R454 BIRC1010085M00 C RESISTOR 100 Ω 1/8W J
R455 BIRC473010500 C RESISTOR 47K Ω 1/10W
R456 BIRC223010500 C RESISTOR 22K Ω 1/10W
R457 BIRC4720085M00 C RESISTOR 4.7K Ω 1/8W
R458 BIRC103010500 C RESISTOR 10K Ω 1/10W
R459 BIRC222010500 C RESISTOR 2.2K Ω 1/10W
R460 BIRC183010500 C RESISTOR 18K Ω 1/10W
R461 BIRC183010500 C RESISTOR 18K Ω 1/10W
R462 BIRC473010500 C RESISTOR 47K Ω 1/10W
R463 BIRC102010500 C RESISTOR 1K Ω 1/10W
R464 BIRC102010500 C RESISTOR 1K Ω 1/10W
R465 BIRC683010500 C RESISTOR 68K Ω 1/10W
R467 BIRC222010500 C RESISTOR 2.2K Ω 1/10W
R468 BIRC222010500 C RESISTOR 2.2K Ω 1/10W
R469 BIRC103010500 C RESISTOR 10K Ω 1/10W
R471 BIRC123010500 C RESISTOR 12K
Ω 1/10W
R472 BIRC563010500 C RESISTOR 56K
Ω 1/10W
R478 BIRC2220085N00 C RESISTOR 2.2K
Ω 1/8W
R479 BIRC1200045M00 C RESISTOR 12 Ω 1/4W
R480 BIRC272010500 C RESISTOR 2.7K
Ω 1/10W
R481 BIRC272010500 C RESISTOR 2.7K
Ω 1/10W
R482 BIRC473010500 C RESISTOR 47K Ω 1/10W
R483 BIRC473010500 C RESISTOR 47K
Ω 1/10W
R484 BIRC471010500 C RESISTOR 470 Ω 1/10W
R501 BIRC1530085M00 C RESISTOR 15K
Ω 1/8W
R502 BIRC1540085M00 C RESISTOR 15K
Ω 1/8W
R503 BIRC2230085M00 C RESISTOR 22K Ω 1/8W
R504 BIRC2230085M00 C RESISTOR 22K
Ω 1/8W
R505 BIRC393010500 C RESISTOR 39K
Ω 1/10W
R506 BIRC393010500 C RESISTOR 39K Ω 1/10W
R507 BIRC222010500 C RESISTOR 2.2K
Ω 1/10W
R508 BIRC4720085M00 C RESISTOR 4.7K
Ω 1/8W
R509 BIRC683010500 C RESISTOR 68K Ω 1/10W
R510 BIRC563010500 C RESISTOR 56K
Ω 1/10W
R511 BIRC4720085M00 C RESISTOR 4.7K
Ω 1/8W
R512 BIRC2220085M00 C RESISTOR 2.2K
Ω 1/8W
R513 BIRC562010500 C RESISTOR 5.6K
Ω 1/10W
R514 BIRC104010500 C RESISTOR 100K Ω 1/10W
R515 BIRC104010500 C RESISTOR 100K
Ω 1/10W
R516 BIRC105010500 C RESISTOR 1M
Ω 1/10W
R517 BIRC100010500 C RESISTOR 10 Ω 1/10W
R518 BIRC104010500 C RESISTOR 100K
Ω 1/10W
R519 BIRC104010500 C RESISTOR 100K
Ω 1/10W
R520 BIRC103010500 C RESISTOR 10K Ω 1/10W
R521 BIRC000010500 C RESISTOR 0
Ω 1/10W

Symbol
No.
Part No. Part Name Description Local
R523 BIRC222010500 C RESISTOR 2.2K Ω 1/10W
R525 BIRC104010500 C RESISTOR 100K Ω 1/10W
R526 BIRC104010500 C RESISTOR 100K Ω 1/10W
R528 BIRC103010500 C RESISTOR 10K Ω 1/10W
R533 BIRC103010500 C RESISTOR 10K Ω 1/10W
R537 BIRC392010500 C RESISTOR 3.9K
Ω 1/10W
R538 BIRC222010500 C RESISTOR 2.2K
Ω 1/10W
R539 BIRC222010500 C RESISTOR 2.2K Ω 1/10W
R540 BIRC472010500 C RESISTOR 4.7K Ω 1/10W
R541 BIRC472010500 C RESISTOR 4.7K Ω 1/10W
R542 BIRC103010500 C RESISTOR 10K Ω 1/10W
R543 BIRC103010500 C RESISTOR 10K Ω 1/10W
R546 BIRC562010500 C RESISTOR 5.6K Ω 1/10W
R547 BIRC562010500 C RESISTOR 5.6K Ω 1/10W
R548 BIRC471010500 C RESISTOR 470 Ω 1/10W
R549 BIRC471010500 C RESISTOR 470 Ω 1/10W
R550 BIRC392010500 C RESISTOR 3.9K Ω 1/10W
R557 BIRC103010500 C RESISTOR 10K Ω 1/10W
R558 BIRC472010500 C RESISTOR 4.7K Ω 1/10W
R559 BIRC473010500 C RESISTOR 47K Ω 1/10W
R560 BIRC223010500 C RESISTOR 22K
Ω 1/10W
R561 BIRC223010500 C RESISTOR 22K
Ω 1/10W
R562 BIRC223010500 C RESISTOR 22K Ω 1/10W
R563 BIRC471010500 C RESISTOR 470 Ω 1/10W
R566 BIRC682010500 C RESISTOR 6.8K Ω 1/10W
R567 BIRC332010500 C RESISTOR 3.3K Ω 1/10W
R570 BIRC472010500 C RESISTOR 4.7K Ω 1/10W
R571 BIRC4710045M00 C RESISTOR 470 Ω 1/4W
R572 BIRC4720085M00 C RESISTOR 4.7K Ω 1/8W
R573 BIRC2210085M00 C RESISTOR 220 Ω 1/8W
R574 BIRC103010500 C RESISTOR 10K Ω 1/10W
R575 BIRC1010085M00 C RESISTOR 100 Ω 1/8W J
R576 BIRC2220085M00 C RESISTOR 2.2K Ω 1/8W
R577 BIRC2220085M00 C RESISTOR 2.2K Ω 1/8W
R578 BIRC4710045M00 C RESISTOR 470 Ω 1/4W
R579 BIRC4700085M00 C RESISTOR 47 Ω 1/8W
R580 BIRC104010500 C RESISTOR 100K Ω 1/10W
R581 BIRC332010500 C RESISTOR 3.3K Ω 1/10W
R585 BIRC000010500 C RESISTOR 0 Ω 1/10W
R586 BIRC000010500 C RESISTOR 0 Ω 1/10W
R597 BIRC4710045M00 C RESISTOR 470 Ω 1/4W
R598 BIRC2210085M00 C RESISTOR 220 Ω 1/8W
R701 BIRC082010500 C RESISTOR 8.2 Ω 1/10W
R702 BIRC823010500 C RESISTOR 82K Ω 1/10W
R703 BIRC393010500 C RESISTOR 39K Ω 1/10W
R704 BIRC393010500 C RESISTOR 39K Ω 1/10W
R705 BIRC393010500 C RESISTOR 39K Ω 1/10W
R706 BIRC393010500 C RESISTOR 39K
Ω 1/10W
R707 BIRC823010500 C RESISTOR 82K
Ω 1/10W
R708 BIRC394010500 C RESISTOR 390K
Ω 1/10W
R709 BIRC472010500 C RESISTOR 4.7K Ω 1/10W
R710 BIRC101010500 C RESISTOR 100
Ω 1/10W
R711 BIRC822010500 C RESISTOR 8.2K
Ω 1/10W
R714 BIRC103010500 C RESISTOR 10K Ω 1/10W
R715 BIRC183010500 C RESISTOR 18K
Ω 1/10W
R716 BIRC223010500 C RESISTOR 22K Ω 1/10W
R717 BIRC105010500 C RESISTOR 1M
Ω 1/10W
R718 BIRC103010500 C RESISTOR 10K
Ω 1/10W
R719 BIRC562010500 C RESISTOR 5.6K Ω 1/10W
R720 BIRC102010500 C RESISTOR 1K
Ω 1/10W
R721 BIRC103010500 C RESISTOR 10K
Ω 1/10W
R722 BIRC103010500 C RESISTOR 10K Ω 1/10W
R723 BIRC683010500 C RESISTOR 68K
Ω 1/10W
R724 BIRC563010500 C RESISTOR 56K
Ω 1/10W
R725 BIRC153010500 C RESISTOR 15K Ω 1/10W
R726 BIRC473010500 C RESISTOR 47K
Ω 1/10W
R727 BIRC823010500 C RESISTOR 82K
Ω 1/10W
R728 BIRC393010500 C RESISTOR 39K
Ω 1/10W
R729 BIRC394010500 C RESISTOR 390K
Ω 1/10W
R730 BIRC124010500 C RESISTOR 120K Ω 1/10W
R731 BIRC104010500 C RESISTOR 100K
Ω 1/10W
R732 BIRC473010500 C RESISTOR 47K
Ω 1/10W
R750 BIRC820010500 C RESISTOR 82 Ω 1/10W
R751 BIRC101010500 C RESISTOR 100
Ω 1/10W
R752 BIRC133010500 C RESISTOR 13K
Ω 1/10W
R753 BIRC133010500 C RESISTOR 13K Ω 1/10W
R754 BIRC133010500 C RESISTOR 13K
Ω 1/10W

Symbol
No.
Part No. Part Name Description Local
