Front board (MX-KC45A)
Block No. [0][6]
R755 BIRC133010500 C RESISTOR 13K
Ω
1/10W
R756 BIRC1020085N00 C RESISTOR 1K
Ω
1/8W
R757 BIRC1020085N00 C RESISTOR 1K
Ω
1/8W
R758 BIRC181010500 C RESISTOR 180
Ω
1/10W
R759 BIRC103010500 C RESISTOR 10K
Ω
1/10W
R760 BIRC103010500 C RESISTOR 10K
Ω
1/10W
R761 BIRC682010500 C RESISTOR 6.8K
Ω
1/10W
R762 BIRC1020085M00 C RESISTOR 1K
Ω
1/8W J
R763 BIRC202010500 C RESISTOR 2K
Ω
1/10W
R764 BIRC0100025N00 C RESISTOR 1
Ω
1/2W
R780 BIRC101010500 C RESISTOR 100
Ω
1/10W
R781 BIRC101010500 C RESISTOR 100
Ω
1/10W
R782 BIRC101010500 C RESISTOR 100
Ω
1/10W
R801 BIRC121010500 C RESISTOR 120
Ω
1/10W
R802 BIRC1010085M00 C RESISTOR 100
Ω
1/8W J
R803 BIRC1010085M00 C RESISTOR 100
Ω
1/8W J
R804 BIRC105010500 C RESISTOR 1M
Ω
1/10W
R805 BIRC101010500 C RESISTOR 100
Ω
1/10W
R806 BIRC101010500 C RESISTOR 100
Ω
1/10W
R807 BIRC101010500 C RESISTOR 100
Ω
1/10W
R808 BIRC104010500 C RESISTOR 100K
Ω
1/10W
R809 BIRC104010500 C RESISTOR 100K
Ω
1/10W
R810 BIRC101010500 C RESISTOR 100
Ω
1/10W
R811 BIRC101010500 C RESISTOR 100
Ω
1/10W
R814 BIRC1210085M00 C RESISTOR 120
Ω
1/8W
R815 BIRC102010500 C RESISTOR 1K
Ω
1/10W
R816 BIRC101010500 C RESISTOR 100
Ω
1/10W
R817 BIRC101010500 C RESISTOR 100
Ω
1/10W
R821 BIRC1020085M00 C RESISTOR 1K
Ω
1/8W J
R850 BIRC102010500 C RESISTOR 1K
Ω
1/10W
L301 BI26100000KN00 FIXED INDUCTOR 10uH
L302 BI18843556N00 FILTER BED 843556
L304 BI1891612100 FERRITE BED 120
Ω
L501 BI18843556N00 FILTER BED 843556
L503 BI18843556N00 FILTER BED 843556
L505 BICH103500KM01 C CPCITOR 0.01uF 50V
L509 BI18843556N00 FILTER BED 843556
L702 BI26100000KN00 FIXED INDUCTOR 10uH
L801 BI26100000KN00 FIXED INDUCTOR 10uH
L802 BI26100000KN00 FIXED INDUCTOR 10uH
L803 BI26100000KN00 FIXED INDUCTOR 10uH
L804 BI26100000KN00 FIXED INDUCTOR 10uH
L805 BI26100000KN00 FIXED INDUCTOR 10uH
L806 BIRC000010500 C RESISTOR 0
Ω
1/10W
L807 BI18843556N00 FILTER BED 843556
L808 BI18843556N00 FILTER BED 843556
T401 BI603141V COIL OSC
CN201 BI12S1800061V CONNECTOR 18P
CN205 BI12S30039 CONNECTOR 3P
CN301 BI12S30039 CONNECTOR 3P
CN302 BI12S80024 CONNECTOR 8P
CN303 BI12S90024V FFC CONNECTOR 9P
CN306 BI12S100047X CONNECTOR 10P
CN601 BI12S240004V FFC CONNECTOR 24P
CN701 BI12S160031V FFC CONNECTOR 16P
CN702 BI12P60142V CONNECTOR WIRE 6P to CD MECH
CN703 BI12P100051X CONNECTOR WIRE
10P to CD PICK
UP
JR301 BIRC000010500 C RESISTOR 0
Ω
1/10W
JR302 BIRC000010500 C RESISTOR 0
Ω
1/10W
JR401 BIRC000010500 C RESISTOR 0
Ω
1/10W
JR402 BIRC000010500 C RESISTOR 0
Ω
1/10W
JR403 BIRC000010500 C RESISTOR 0
Ω
1/10W
JR404 BIRC000010500 C RESISTOR 0
Ω
1/10W
JR408 BIRC000010500 C RESISTOR 0
Ω
1/10W
JR701 BIRC000010500 C RESISTOR 0
Ω
1/10W
JR702 BIRC000010500 C RESISTOR 0
Ω
1/10W
JR703 BIRC000008500 C RESISTOR 0
Ω
1/8W
JR801 BIRC000008500 C RESISTOR 0
Ω
1/8W
X801 BI2102361 CRYSTL 16.9344MHz
XT301 BI2101012 CRYSTL 32.768KHz
XT302 BI29ZT8.00P015 C RESONTOR 8MHz
Symbol
No.
Part No. Part Name Description Local
Symbol
No.
Part No. Part Name Description Local
IC201 BI115291X IC RPM7138-V4
IC202 BI116661X IC S5G5128
D201 1SS133 FR DIODE
BI31SS133M000V
7
D202 1SS133 FR DIODE
BI31SS133M000V
7
D206 1SS133 FR DIODE
BI31SS133M000V
7
D207 1SS133 FR DIODE
BI31SS133M000V
7
D208 1SS133 FR DIODE
BI31SS133M000V
7
C201 BICC103500K02 C CPCITOR 0.01uF 50V
C202 BICC103500K02 C CPCITOR 0.01uF 50V
C203 BICE106500MP01 E CPCTIOR 10uF 50V
C204 BICC102500K04 C CPCITOR 1000pF 50V
C205 BICE226500MP01 E CPCITOR 22uF 50V
C207 BICE226500MP01 E CPCITOR 22uF 50V
C209 BICC104500K04 C CPCITOR 0.1uF 50V
C211 BICE107500MP01 E CPCITOR 100uF 50V
C212 BICC104500K04 C CPCITOR 0.1uF 50V
C213 BICC104500K04 C CPCITOR 0.1uF 50V
C221 BICC102500K04 C CPCITOR 1000pF 50V
C222 BICC102500K04 C CPCITOR 1000pF 50V
C225 BICC104500K04 C CPCITOR 0.1uF 50V
C226 BICC104500K04 C CPCITOR 0.1uF 50V
C227 BICC101500J04 C CPCITOR 100pF 50V
C228 BICC101500J04 C CPCITOR 100pF 50V
C229 BICC101500J04 C CPCITOR 100pF 50V
C230 BICC102500K04 C CPCITOR 1000pF 50V
C231 BICC102500K04 C CPCITOR 1000pF 50V
C233 BICE108063MP01 E CPCITOR 1000uF 6.3V
R203 BIRC103010500 C RESISTOR 10K
Ω
1/10W
R204 BIRC103010500 C RESISTOR 10K
Ω
1/10W
R205 BIRC101010500 C RESISTOR 100
Ω
1/10W
R206 BIRC221010500 C RESISTOR 220
Ω
1/10W
R207 BIRC010010500 C RESISTOR 1
Ω
1/10W
R208 BIRC010010500 C RESISTOR 1
Ω
1/10W
R209 BIRC1000085M00 C RESISTOR 10
Ω
1/8W
R210 BIRC273010500 C RESISTOR 27K
Ω
1/10W
R212 BIRC103010500 C RESISTOR 10K
Ω
1/10W
R213 BIRC103010500 C RESISTOR 10K
Ω
1/10W
R214 BIRC103010500 C RESISTOR 10K
Ω
1/10W
R215 BIRC911010500 C RESISTOR 910
Ω
1/10W
R216 BIRC112010500 C RESISTOR 1.1K
Ω
1/10W
R217 BIRC132010500 C RESISTOR 1.3K
Ω
1/10W
R218 BIRC182010500 C RESISTOR 1.8K
Ω
1/10W
R219 BIRC202010500 C RESISTOR 2K
Ω
1/10W
R220 BIRC302010500 C RESISTOR 3K
Ω
1/10W
R221 BIRC392010500 C RESISTOR 3.9K
Ω
1/10W
R222 BIRC103010500 C RESISTOR 10K
Ω
1/10W
R223 BIRC911010500 C RESISTOR 910
Ω
1/10W
R224 BIRC112010500 C RESISTOR 1.1K
Ω
1/10W
R225 BIRC132010500 C RESISTOR 1.3K
Ω
1/10W
R226 BIRC182010500 C RESISTOR 1.8K
Ω
1/10W
R227 BIRC202010500 C RESISTOR 2K
Ω
1/10W
R228 BIRC302010500 C RESISTOR 3K
Ω
1/10W
R229 BIRC392010500 C RESISTOR 3.9K
Ω
1/10W
R230 BIRC622010500 C RESISTOR 6.2K
Ω
1/10W
R231 BIRC911010500 C RESISTOR 910
Ω
1/10W
R232 BIRC112010500 C RESISTOR 1.1K
Ω
1/10W
R233 BIRC132010500 C RESISTOR 1.3K
Ω
1/10W
R234 BIRC182010500 C RESISTOR 1.8K
Ω
1/10W
R235 BIRC202010500 C RESISTOR 2K
Ω
1/10W
R236 BIRC302010500 C RESISTOR 3K
Ω
1/10W
R237 BIRC392010500 C RESISTOR 3.9K
Ω
1/10W
R238 BIRC622010500 C RESISTOR 6.2K
Ω
1/10W
R241 BIRC103010500 C RESISTOR 10K
Ω
1/10W
R247 BIRC102010500 C RESISTOR 1K
Ω
1/10W
R248 BIRC1020085M00 C RESISTOR 1K
Ω
1/8W J
R249 BIRC1020085M00 C RESISTOR 1K
Ω
1/8W J
To Next Page
