3-24
Front board
(MX-KC45UW,MX-KC45UY.MX-KC45UJ)
Block No. [1][0]
R572 BIRC4720085M00 C RESISTOR 4.7K
Ω
1/8W
R573 BIRC2210085M00 C RESISTOR 220
Ω
1/8W
R574 BIRC1030105A00 C RESISTOR 10K
Ω
1/10W
R575 BIRC1010085M00 C RESISTOR 100
Ω
1/8W J
R576 BIRC2220085M00 C RESISTOR 2.2K
Ω
1/8W
R577 BIRC2220085M00 C RESISTOR 2.2K
Ω
1/8W
R578 BIRC4710045M00 C RESISTOR 470
Ω
1/4W
R579 BIRC4700085M00 C RESISTOR 47
Ω
1/8W
R580 BIRC1040105A00 C RESISTOR 100K
Ω
1/10W
R581 BIRC3320105A00 C RESISTOR 3.3K
Ω
1/10W
R585 BIRC0000105A00 C RESISTOR 0
Ω
1/10W
R586 BIRC0000105A00 C RESISTOR 0
Ω
1/10W
R597 BIRC4710045M00 C RESISTOR 470
Ω
1/4W
R598 BIRC2210085M00 C RESISTOR 220
Ω
1/8W
R701 BIRC0820105A00 C RESISTOR 8.2
Ω
1/10W
R702 BIRC8230105A00 C RESISTOR 82K
Ω
1/10W
R703 BIRC3930105A00 C RESISTOR 39K
Ω
1/10W
R704 BIRC3930105A00 C RESISTOR 39K
Ω
1/10W
R705 BIRC3930105A00 C RESISTOR 39K
Ω
1/10W
R706 BIRC3930105A00 C RESISTOR 39K
Ω
1/10W
R707 BIRC8230105A00 C RESISTOR 82K
Ω
1/10W
R708 BIRC3940105A00 C RESISTOR 390K
Ω
1/10W
R709 BIRC4720105A00 C RESISTOR 4.7K
Ω
1/10W
R710 BIRC1010105A00 C RESISTOR 100
Ω
1/10W
R711 BIRC8220105A00 C RESISTOR 8.2K
Ω
1/10W
R714 BIRC1030105A00 C RESISTOR 10K
Ω
1/10W
R715 BIRC1830105A00 C RESISTOR 18K
Ω
1/10W
R716 BIRC2230105A00 C RESISTOR 22K
Ω
1/10W
R717 BIRC1050105A00 C RESISTOR 1M
Ω
1/10W
R718 BIRC1030105A00 C RESISTOR 10K
Ω
1/10W
R719 BIRC5620105A00 C RESISTOR 5.6K
Ω
1/10W
R720 BIRC1020105A00 C RESISTOR 1K
Ω
1/10W
R721 BIRC1030105A00 C RESISTOR 10K
Ω
1/10W
R722 BIRC1030105A00 C RESISTOR 10K
Ω
1/10W
R723 BIRC6830105A00 C RESISTOR 68K
Ω
1/10W
R724 BIRC5630105A00 C RESISTOR 56K
Ω
1/10W
R725 BIRC1530105A00 C RESISTOR 15K
Ω
1/10W
R726 BIRC4730105A00 C RESISTOR 47K
Ω
1/10W
R727 BIRC8230105A00 C RESISTOR 82K
Ω
1/10W
R728 BIRC3930105A00 C RESISTOR 39K
Ω
1/10W
R729 BIRC3940105A00 C RESISTOR 390K
Ω
1/10W
R730 BIRC1240105A00 C RESISTOR 120K
Ω
1/10W
R731 BIRC1040105A00 C RESISTOR 100K
Ω
1/10W
R732 BIRC4730105A00 C RESISTOR 47K
Ω
1/10W
R750 BIRC8200105A00 C RESISTOR 82
Ω
1/10W
R751 BIRC1010105A00 C RESISTOR 100
Ω
1/10W
R752 BIRC1330105A00 C RESISTOR 13K
Ω
1/10W
R753 BIRC1330105A00 C RESISTOR 13K
Ω
1/10W
R754 BIRC1330105A00 C RESISTOR 13K
Ω
1/10W
R755 BIRC1330105A00 C RESISTOR 13K
Ω
1/10W
R756 BIRC1020085N00 C RESISTOR 1K
Ω
1/8W
R757 BIRC1020085N00 C RESISTOR 1K
Ω
1/8W
R758 BIRC1810105A00 C RESISTOR 180
Ω
1/10W
R759 BIRC1030105A00 C RESISTOR 10K
Ω
1/10W
R760 BIRC1030105A00 C RESISTOR 10K
Ω
1/10W
R761 BIRC6820105A00 C RESISTOR 6.8K
Ω
1/10W
R762 BIRC1020085M00 C RESISTOR 1K
Ω
1/8W J
R763 BIRC2020105A00 C RESISTOR 2K
Ω
1/10W
R764 BIRC0100025N00 C RESISTOR 1
Ω
1/2W
R780 BIRC1010105A00 C RESISTOR 100
Ω
1/10W
R781 BIRC1010105A00 C RESISTOR 100
Ω
1/10W
R782 BIRC1010105A00 C RESISTOR 100
Ω
1/10W
R801 BIRC1210105A00 C RESISTOR 120
Ω
1/10W
R802 BIRC1010085M00 C RESISTOR 100
Ω
1/8W J
R803 BIRC1010085M00 C RESISTOR 100
Ω
1/8W J
R804 BIRC1050105A00 C RESISTOR 1M
Ω
1/10W
R805 BIRC1010105A00 C RESISTOR 100
Ω
1/10W
R806 BIRC1010105A00 C RESISTOR 100
Ω
1/10W
R807 BIRC1010105A00 C RESISTOR 100
Ω
1/10W
R808 BIRC1040105A00 C RESISTOR 100K
Ω
1/10W
R809 BIRC1040105A00 C RESISTOR 100K
Ω
1/10W
R810 BIRC1010105A00 C RESISTOR 100
Ω
1/10W
R811 BIRC1010105A00 C RESISTOR 100
Ω
1/10W
R814 BIRC1210085M00 C RESISTOR 120
Ω
1/8W
R815 BIRC1020105A00 C RESISTOR 1K
Ω
1/10W
R816 BIRC1010105A00 C RESISTOR 100
Ω
1/10W
R817 BIRC1010105A00 C RESISTOR 100
Ω
1/10W
Symbol
No.
Part No. Part Name Description Local
R821 BIRC1020085M00 C RESISTOR 1K
Ω
1/8W J
R850 BIRC1020105A00 C RESISTOR 1K
Ω
1/10W
L301 BI26100000KN00 FIXED INDUCTOR 10uH
L302 BI18A843556N00 FILTER BEAD 843556
L304 BI18A916121A00 FERRITE BEAD 120
Ω
L501 BI18A843556N00 FILTER BEAD 843556
L503 BI18A843556N00 FILTER BEAD 843556
L505 BICH103500KM01 C CAPACITOR 0.01uF 50V
L509 BI18A843556N00 FILTER BEAD 843556
L702 BI26100000KN00 FIXED INDUCTOR 10uH
L801 BI26100000KN00 FIXED INDUCTOR 10uH
L802 BI26100000KN00 FIXED INDUCTOR 10uH
L803 BI26100000KN00 FIXED INDUCTOR 10uH
L804 BI26100000KN00 FIXED INDUCTOR 10uH
L805 BI26100000KN00 FIXED INDUCTOR 10uH
L806 BIRC0000105A00 C RESISTOR 0
Ω
1/10W
L807 BI18A843556N00 FILTER BEAD 843556
L808 BI18A843556N00 FILTER BEAD 843556
T401 BI603141V COIL OSC
CN201 BI12S1800061V CONNECTOR 18P
CN205 BI12S30039 CONNECTOR 3P
CN301 BI12S30039 CONNECTOR 3P
CN302 BI12S80024 CONNECTOR 8P
CN303 BI12S90024V FFC CONNECTOR 9P
CN306 BI12S100047X CONNECTOR 10P
CN601 BI12S240004V FFC CONNECTOR 24P
CN701 BI12S160031V FFC CONNECTOR 16P
CN702 BI12P60142V CONNECTOR WIRE 6P to CD MECHA
CN703 BI12P100051X CONNECTOR WIRE
10P to CD PICK
UP
JR301 BIRC0000105A00 C RESISTOR 0
Ω
1/10W
JR302 BIRC0000105A00 C RESISTOR 0
Ω
1/10W
JR401 BIRC0000105A00 C RESISTOR 0
Ω
1/10W
JR402 BIRC0000105A00 C RESISTOR 0
Ω
1/10W
JR403 BIRC0000105A00 C RESISTOR 0
Ω
1/10W
JR404 BIRC0000105A00 C RESISTOR 0
Ω
1/10W
JR408 BIRC0000105A00 C RESISTOR 0
Ω
1/10W
JR701 BIRC0000105A00 C RESISTOR 0
Ω
1/10W
JR702 BIRC0000105A00 C RESISTOR 0
Ω
1/10W
JR703 BIRC0000085A00 C RESISTOR 0
Ω
1/8W
JR801 BIRC0000085A00 C RESISTOR 0
Ω
1/8W
X801 BI2102361 CRYSTAL 16.9344MHz
XT301 BI2101012 CRYSTAL 32.768KHz
XT302 BI29ZTA8.00P015 C RESONATOR 8MHz
Symbol
No.
Part No. Part Name Description Local
IC201 BI115291X IC RPM7138-V4
IC202 BI116661X IC S5G5128A
D201 1SS133 FR DIODE
BI31SS133M000V
7
D202 1SS133 FR DIODE
BI31SS133M000V
7
D206 1SS133 FR DIODE
BI31SS133M000V
7
D207 1SS133 FR DIODE
BI31SS133M000V
7
D208 1SS133 FR DIODE
BI31SS133M000V
7
C201 BICC103500KA02 C CAPACITOR 0.01uF 50V
C202 BICC103500KA02 C CAPACITOR 0.01uF 50V
C203 BICE106500MP01 E CAPACTIOR 10uF 50V
C204 BICC102500KA04 C CAPACITOR 1000pF 50V
C205 BICE226500MP01 E CAPACITOR 22uF 50V
Symbol
No.
Part No. Part Name Description Local
