JVC MX-KC45E - Page 63

3-25
C207 BICE226500MP01 E CAPACITOR 22uF 50V
C209 BICC104500KA04 C CAPACITOR 0.1uF 50V
C211 BICE107500MP01 E CAPACITOR 100uF 50V
C212 BICC104500KA04 C CAPACITOR 0.1uF 50V
C213 BICC104500KA04 C CAPACITOR 0.1uF 50V
C221 BICC102500KA04 C CAPACITOR 1000pF 50V
C222 BICC102500KA04 C CAPACITOR 1000pF 50V
C225 BICC104500KA04 C CAPACITOR 0.1uF 50V
C226 BICC104500KA04 C CAPACITOR 0.1uF 50V
C227 BICC101500JA04 C CAPACITOR 100pF 50V
C228 BICC101500JA04 C CAPACITOR 100pF 50V
C229 BICC101500JA04 C CAPACITOR 100pF 50V
C230 BICC102500KA04 C CAPACITOR 1000pF 50V
C231 BICC102500KA04 C CAPACITOR 1000pF 50V
C233 BICE108063MP01 E CAPACITOR 1000uF 6.3V
R203 BIRC1030105A00 C RESISTOR 10K Ω 1/10W
R204 BIRC1030105A00 C RESISTOR 10K Ω 1/10W
R205 BIRC1010105A00 C RESISTOR 100 Ω 1/10W
R206 BIRC2210105A00 C RESISTOR 220 Ω 1/10W
R207 BIRC0100105A00 C RESISTOR 1
Ω 1/10W
R208 BIRC0100105A00 C RESISTOR 1
Ω 1/10W
R209 BIRC1000085M00 C RESISTOR 10 Ω 1/8W
R210 BIRC2730105A00 C RESISTOR 27K Ω 1/10W
R212 BIRC1030105A00 C RESISTOR 10K Ω 1/10W
R213 BIRC1030105A00 C RESISTOR 10K Ω 1/10W
R214 BIRC1030105A00 C RESISTOR 10K Ω 1/10W
R215 BIRC9110105A00 C RESISTOR 910 Ω 1/10W
R216 BIRC1120105A00 C RESISTOR 1.1K Ω 1/10W
R217 BIRC1320105A00 C RESISTOR 1.3K Ω 1/10W
R218 BIRC1820105A00 C RESISTOR 1.8K Ω 1/10W
R219 BIRC2020105A00 C RESISTOR 2K Ω 1/10W
R220 BIRC3020105A00 C RESISTOR 3K Ω 1/10W
R221 BIRC3920105A00 C RESISTOR 3.9K Ω 1/10W
R222 BIRC1030105A00 C RESISTOR 10K Ω 1/10W
R223 BIRC9110105A00 C RESISTOR 910 Ω 1/10W
R224 BIRC1120105A00 C RESISTOR 1.1K Ω 1/10W
R225 BIRC1320105A00 C RESISTOR 1.3K Ω 1/10W
R226 BIRC1820105A00 C RESISTOR 1.8K Ω 1/10W
R227 BIRC2020105A00 C RESISTOR 2K Ω 1/10W
R228 BIRC3020105A00 C RESISTOR 3K Ω 1/10W
R229 BIRC3920105A00 C RESISTOR 3.9K Ω 1/10W
R230 BIRC6220105A00 C RESISTOR 6.2K Ω 1/10W
R231 BIRC9110105A00 C RESISTOR 910 Ω 1/10W
R232 BIRC1120105A00 C RESISTOR 1.1K Ω 1/10W
R233 BIRC1320105A00 C RESISTOR 1.3K Ω 1/10W
R234 BIRC1820105A00 C RESISTOR 1.8K Ω 1/10W
R235 BIRC2020105A00 C RESISTOR 2K
Ω 1/10W
R236 BIRC3020105A00 C RESISTOR 3K
Ω 1/10W
R237 BIRC3920105A00 C RESISTOR 3.9K
Ω 1/10W
R238 BIRC6220105A00 C RESISTOR 6.2K Ω 1/10W
R241 BIRC1030105A00 C RESISTOR 10K
Ω 1/10W
R247 BIRC1020105A00 C RESISTOR 1K
Ω 1/10W
R248 BIRC1020085M00 C RESISTOR 1K Ω 1/8W J
R249 BIRC1020085M00 C RESISTOR 1K
Ω 1/8W J
R250 BIRC1020085M00 C RESISTOR 1K Ω 1/8W J
R251 BIRC4730105A00 C RESISTOR 47K
Ω 1/10W
R252 BIRC4730105A00 C RESISTOR 47K
Ω 1/10W
R253 BIRC4730105A00 C RESISTOR 47K Ω 1/10W
R254 BIRC4730105A00 C RESISTOR 47K
Ω 1/10W
R255 BIRC4730105A00 C RESISTOR 47K
Ω 1/10W
R256 BIRC4730105A00 C RESISTOR 47K Ω 1/10W
R257 BIRC4730105A00 C RESISTOR 47K
Ω 1/10W
R258 BIRC4730105A00 C RESISTOR 47K
Ω 1/10W
R259 BIRC4730105A00 C RESISTOR 47K Ω 1/10W
R260 BIRC4730105A00 C RESISTOR 47K
Ω 1/10W
R261 BIRC4730105A00 C RESISTOR 47K
Ω 1/10W
R262 BIRC4730105A00 C RESISTOR 47K
Ω 1/10W
R263 BIRC4730105A00 C RESISTOR 47K
Ω 1/10W
R264 BIRC4730105A00 C RESISTOR 47K Ω 1/10W
R265 BIRC4730105A00 C RESISTOR 47K
Ω 1/10W
R266 BIRC4730105A00 C RESISTOR 47K
Ω 1/10W
R267 BIRC4730105A00 C RESISTOR 47K Ω 1/10W
R268 BIRC4730105A00 C RESISTOR 47K
Ω 1/10W
R269 BIRC4730105A00 C RESISTOR 47K
Ω 1/10W
R270 BIRC4730105A00 C RESISTOR 47K Ω 1/10W
R271 BIRC4730105A00 C RESISTOR 47K
Ω 1/10W

Symbol
No.
Part No. Part Name Description Local
R272 BIRC4730105A00 C RESISTOR 47K Ω 1/10W
R273 BIRC4730105A00 C RESISTOR 47K Ω 1/10W
R274 BIRC4730105A00 C RESISTOR 47K Ω 1/10W
R275 BIRC4730105A00 C RESISTOR 47K Ω 1/10W
R276 BIRC4730105A00 C RESISTOR 47K Ω 1/10W
R277 BIRC4730105A00 C RESISTOR 47K
Ω 1/10W
R278 BIRC4730105A00 C RESISTOR 47K
Ω 1/10W
R279 BIRC4730105A00 C RESISTOR 47K Ω 1/10W
R280 BIRC4730105A00 C RESISTOR 47K Ω 1/10W
R281 BIRC4730105A00 C RESISTOR 47K Ω 1/10W
R282 BIRC4730105A00 C RESISTOR 47K Ω 1/10W
R283 BIRC4730105A00 C RESISTOR 47K Ω 1/10W
R284 BIRC4730105A00 C RESISTOR 47K Ω 1/10W
R285 BIRC1810045M00 C RESISTOR 180 Ω 1/4W
R286 BIRC1810045M00 C RESISTOR 180 Ω 1/4W
VR201 BI804401V ROTARY SW RE012307PVB30
L201 BI26100000KM00 FIXED INDUCTOR 10uH
L202 BI26100000KM00 FIXED INDUCTOR 10uH
L203 BI18A843556N00 FILTER BEAD 843556
CN201 BI12S30081X CONNCTOR 3P
CN203 BI12P30272X CONNECTOR WIRE
3P to FRONT
CN201
CW201 BI12S1800071 FFC CONNECTOR 18P
CW202 BI12P402341V CONNECTOR WIRE 4P to AMP CN202
CW205 BI12P30270X CONNECTOR WIRE 3P MAIN CN205
FL201 BI2702381X FL DISPLAY HNAC 17LM3 41P
JK201 BI2301211 MINI JACK CKX-3.5- 25
JK202 BI2301211 MINI JACK CKX-3.5- 25
LD201 BI28B4541EP01 LED
RED BL-B4541-AV-
TBS2
S201 BI8SKRGAED0P0 TACT SWITCH SKRGAED010
S202 BI8SKRGAED0P0 TACT SWITCH SKRGAED010
S203 BI8SKRGAED0P0 TACT SWITCH SKRGAED010
S204 BI8SKRGAED0P0 TACT SWITCH SKRGAED010
S205 BI8SKRGAED0P0 TACT SWITCH SKRGAED010
S206 BI8SKRGAED0P0 TACT SWITCH SKRGAED010
S207 BI8SKRGAED0P0 TACT SWITCH SKRGAED010
S208 BI8SKRGAED0P0 TACT SWITCH SKRGAED010
S209 BI8SKRGAED0P0 TACT SWITCH SKRGAED010
S210 BI8SKRGAED0P0 TACT SWITCH SKRGAED010
S211 BI8SKRGAED0P0 TACT SWITCH SKRGAED010
S212 BI8SKRGAED0P0 TACT SWITCH SKRGAED010
S213 BI8SKRGAED0P0 TACT SWITCH SKRGAED010
S214 BI8SKRGAED0P0 TACT SWITCH SKRGAED010
S215 BI8SKRGAED0P0 TACT SWITCH SKRGAED010
S216 BI8SKRGAED0P0 TACT SWITCH SKRGAED010
S217 BI8SKRGAED0P0 TACT SWITCH SKRGAED010
S218 BI8SKRGAED0P0 TACT SWITCH SKRGAED010
S219 BI8SKRGAED0P0 TACT SWITCH SKRGAED010
S220 BI8SKRGAED0P0 TACT SWITCH SKRGAED010
S221 BI8SKRGAED0P0 TACT SWITCH SKRGAED010
S222 BI8SKRGAED0P0 TACT SWITCH SKRGAED010
S223 BI8SKRGAED0P0 TACT SWITCH SKRGAED010
S224 BI8SKRGAED0P0 TACT SWITCH SKRGAED010
S225 BI8SKRGAED0P0 TACT SWITCH SKRGAED010
S226 BI8SKRGAED0P0 TACT SWITCH SKRGAED010
S227 BI8SKRGAED0P0 TACT SWITCH SKRGAED010
S228 BI8SKRGAED0P0 TACT SWITCH SKRGAED010
XXXXX BI1206721X FLAT CABLE
8P CW215 to
CW203

Symbol
No.
Part No. Part Name Description Local
