3-27
Power trans board
(MX-KC45UW,MX-KC45UY.MX-KC45UJ)
Block No. [1][2]
C646 BICM104101KP01 M CAPACITOR 0.1uF 100V
C647 BICM104101KP01 M CAPACITOR 0.1uF 100V
C648 BICM104101KP01 M CAPACITOR 0.1uF 100V
C649 BICC121500JA04 C CAPACITOR 120pF 50V
C650 BICE476160MP01 E CAPACITOR 47uF 16V
C651 BICC223500KA04 C CAPACITOR 0.022uF 50V
C652 BICE226500MP01 E CAPACITOR 22uF 50V
C653 BICE227100MP01 E CAPACITOR 220uF 10V
C654 BICE106250MP01 E CAPACITOR 10uF 25V
C655 BICC153500KA04 C CAPACITOR 0.015uF 50V
C656 BICC153500KA04 C CAPACITOR 0.015uF 50V
R101 BIRC4720105A00 C RESISTOR 4.7K
Ω
1/10W
R102 BIRC2220105A00 C RESISTOR 2.2K
Ω
1/10W
R103 BIRC2230105A00 C RESISTOR 22K
Ω
1/10W
R104 BIRC2230105A00 C RESISTOR 22K
Ω
1/10W
R110 BIRC0220105A00 C RESISTOR 2.2
Ω
1/10W
R112 BIRC4710105A00 C RESISTOR 470
Ω
1/10W
R113 BIRC1020105A00 C RESISTOR 1K
Ω
1/10W
R114 BIRC5600105A00 C RESISTOR 56
Ω
1/10W
R115 BIRC2240105A00 C RESISTOR 220K
Ω
1/10W
R116 BIRC4730105A00 C RESISTOR 47K
Ω
1/10W
R117 BIRC4710105A00 C RESISTOR 470
Ω
1/10W
R118 BIRC1020105A00 C RESISTOR 1K
Ω
1/10W
R119 BIRC1020105A00 C RESISTOR 1K
Ω
1/10W
R120 BIRC3330105A00 C RESISTOR 33K
Ω
1/10W
R121 BIRC3330105A00 C RESISTOR 33K
Ω
1/10W
R123 BIRC1020105A00 C RESISTOR 1K
Ω
1/10W
R124 BIRC1020105A00 C RESISTOR 1K
Ω
1/10W
R600 BIRC8210105A00 C RESISTOR 820
Ω
1/10W
R601 BIRC4720105A00 C RESISTOR 4.7K
Ω
1/10W
R602 BIRC5600105A00 C RESISTOR 56
Ω
1/10W
R605 BIRC1020105A00 C RESISTOR 1K
Ω
1/10W
R606 BIRC3320105A00 C RESISTOR 3.3K
Ω
1/10W
R607 BIRC2220105A00 C RESISTOR 2.2K
Ω
1/10W
R608 BIRC1010085N00 C RESISTOR 100
Ω
1/8W
R609 BIRC1010085N00 C RESISTOR 100
Ω
1/8W
R610 BIRC1540105A00 C RESISTOR 150K
Ω
1/10W
R611 BIRC5630105A00 C RESISTOR 56K
Ω
1/10W
R612 BIRC4720105A00 C RESISTOR 4.7K
Ω
1/10W
R613 BIRF1010025N00 FUSE RESISTOR 100
Ω
1/2W
R614 BIRF1010025N00 FUSE RESISTOR 100
Ω
1/2W
R615 BIRC1520025N00 C RESISTOR 1.5K
Ω
1/2W
R616 BIRC1520025N00 C RESISTOR 1.5K
Ω
1/2W
R617 BIRC5610105A00 C RESISTOR 560
Ω
1/10W
R618 BIRC0000105A00 C RESISTOR 0
Ω
1/10W
R619 BIRC3330105A00 C RESISTOR 33K
Ω
1/10W
R620 BIRC3330105A00 C RESISTOR 33K
Ω
1/10W
R621 BIRC5610105A00 C RESISTOR 560
Ω
1/10W
R622 BIRC0000105A00 C RESISTOR 0
Ω
1/10W
R623 BIRC3330105A00 C RESISTOR 33K
Ω
1/10W
R624 BIRC5630105A00 C RESISTOR 56K
Ω
1/10W
R625 BIRC5630105A00 C RESISTOR 56K
Ω
1/10W
R626 BIRC4720105A00 C RESISTOR 4.7K
Ω
1/10W
R627 BIRC4720105A00 C RESISTOR 4.7K
Ω
1/10W
R628 BIRC2220105A00 C RESISTOR 2.2K
Ω
1/10W
R629 BIRC2220105A00 C RESISTOR 2.2K
Ω
1/10W
R630 BIRC3920105A00 C RESISTOR 3.9K
Ω
1/10W
R631 BIRC3920105A00 C RESISTOR 3.9K
Ω
1/10W
R632 BIRM001530V M RESISTOR 0.15
Ω
3W
R633 BIRM001530V M RESISTOR 0.15
Ω
3W
R634 BIRM001530V M RESISTOR 0.15
Ω
3W
R635 BIRM001530V M RESISTOR 0.15
Ω
3W
R636 BIRC1020105A00 C RESISTOR 1K
Ω
1/10W
R637 BIRC1020105A00 C RESISTOR 1K
Ω
1/10W
R638 BIRC1530105A00 C RESISTOR 15K
Ω
1/10W
R639 BIRC1530105A00 C RESISTOR 15K
Ω
1/10W
R640 BIRC0470045N00 C RESISTOR 4.7
Ω
1/4W
R641 BIRC0470045N00 C RESISTOR 4.7
Ω
1/4W
R642 BIRC1020105A00 C RESISTOR 1K
Ω
1/10W
R643 BIRC1020105A00 C RESISTOR 1K
Ω
1/10W
R644 BIRC1030105A00 C RESISTOR 10K
Ω
1/10W
R645 BIRC1030105A00 C RESISTOR 10K
Ω
1/10W
R646 BIRC4710105A00 C RESISTOR 470
Ω
1/10W
R647 BIRC4740105A00 C RESISTOR 470K
Ω
1/10W
R648 BIRC0470045N00 C RESISTOR 4.7
Ω
1/4W
R649 BIRC0470045N00 C RESISTOR 4.7
Ω
1/4W
Symbol
No.
Part No. Part Name Description Local
R650 BIRC1040105A00 C RESISTOR 100K
Ω
1/10W
R651 BIRC1040105A00 C RESISTOR 100K
Ω
1/10W
R652 BIRC1040105A00 C RESISTOR 100K
Ω
1/10W
R653 BIRC0000105A00 C RESISTOR 0
Ω
1/10W
R654 BIRC1020105A00 C RESISTOR 1K
Ω
1/10W
R655 BIRC1030105A00 C RESISTOR 10K
Ω
1/10W
R656 BIRC1500085M00 C RESISTOR 15
Ω
1/8W
R657 BIRC6840105A00 C RESISTOR 680K
Ω
1/10W
R658 BIRC4730105A00 C RESISTOR 47K
Ω
1/10W
R659 BIRC2220105A00 C RESISTOR 2.2K
Ω
1/10W
R660 BIRC3920105A00 C RESISTOR 3.9K
Ω
1/10W
R661 BIRC1030105A00 C RESISTOR 10K
Ω
1/10W
R662 BIRC1020105A00 C RESISTOR 1K
Ω
1/10W
R663 BIRC1030105A00 C RESISTOR 10K
Ω
1/10W
R664 BIRC1020105A00 C RESISTOR 1K
Ω
1/10W
R665 BIRM1020N25N00 M RESISTOR 1K
Ω
2W
R666 BIRM1020N25N00 M RESISTOR 1K
Ω
2W
R669 BIRC1220105A00 C RESISTOR 1.2K
Ω
1/10W
R671 BIRC1030085M00 C RESISTOR 10K
Ω
1/8W J
R672 BIRC3300045M00 C RESISTOR 33
Ω
1/4W
R679 BIRC0000105A00 C RESISTOR 0
Ω
1/10W
R681 BIRC3330085M00 C RESISTOR 33K
Ω
1/8W
R682 BIRC3330085M00 C RESISTOR 33K
Ω
1/8W
R683 BIRC4730085M00 C RESISTOR 47K
Ω
1/8W
R684 BIRC4730105A00 C RESISTOR 47K
Ω
1/10W
L601 BI2601141 COIL 3.0uH
L602 BI2601141 COIL 3.0uH
CN202 BI12S40047 CONNECTOR 4P
CN602 BI12S20016 CONNECTOR 2P
CN603 BI12S300471V CONNECTOR 3P
CN902 BI12S60127X CONNECTOR 6P
CN903 BI12S80060V CONNECTOR 8P
CW601 BI12S240004V FFC CONNECTOR 24P
JK601 BI2301571X TERMINAL SPK 4P
RF601 BIRF3300025N00 FUSE RESISTOR 33
Ω
1/2W
RY601 BI8RL00191V RELAY
DC12V ME-7C-
012-3H
Symbol
No.
Part No. Part Name Description Local
Q901 DTC114YS DIGI TRANSISTOR BI2DTC114YKA011
D901 1SS133 FR DIODE
BI31SS133M000V
7
D902 1SS133 FR DIODE
BI31SS133M000V
7
D903 1SS133 FR DIODE
BI31SS133M000V
7
D904 1SS133 FR DIODE
BI31SS133M000V
7
D905 1SS133 FR DIODE
BI31SS133M000V
7
D906 1SS133 FR DIODE
BI31SS133M000V
7
C901 BICH223250ZM01 C CAPACITOR 0.022uF 25V
C902 BICH223250ZM01 C CAPACITOR 0.022uF 25V
C903 BICH223250ZM01 C CAPACITOR 0.022uF 25V
C904 BICH223250ZM01 C CAPACITOR 0.022uF 25V
C905 BICE477250MP01 E CAPACITOR 470uF 25V
C907 BICE335500MP01 E CAPACITOR 3.3uF 50V
C951 BICT224275MX TA CAPACITOR 0.22uF 275V
R901 BIRC1000085M00 C RESISTOR 10
Ω
1/8W
R902 BIRC4720085M00 C RESISTOR 4.7K
Ω
1/8W
Symbol
No.
Part No. Part Name Description Local
