3-28
Wiring
Block No. [1][3]
CW902 BI12P60176X CONNECTOR WIRE 6P to AMP CN902
CW903 BI12P80121X CONNECTOR WIRE 8P to AMP CN903
 PT902 BI211011151001 POWER TRANS EI28SI
 RY901 BI8RL00331X RELAY RELAYDC9V
 S901 BI805220X POWER SWITCH SDKPA40700
XXXXX BI11W080H2Y 80MM WIRE UL1672 F1A to F1B RED
XXXXX BI11W080H3Y 80MM WIRE UL1672
F2A to F2B
ORANGE
XXXXX BI11W080H4Y 80MM WIRE UL1672
F3A to F3B
YELLOW
XXXXX BI11W080H6Y 80MM WIRE UL1672 F4A to F4B BLUE

Symbol
No.
Part No. Part Name Description Local
XXXXX BI1205291Y FFC CABLE
16P for MAIN
CN701 to CD
MECH CW701
XXXXX BI1207231Y FFC CABLE
18P for MAIN
CN201 to FRONT
CW201
XXXXX BI1207241Y FFC CABLE
9P for MAIN CN303
to CASS MACHA
XXXXX BI1207251Y FFC CABLE
24P for MAIN
CN601 to AMP
CW601
XXXXX BI1207451Y FFC CABLE
12P for MAIN
CN306 to TUNER
E,EN
XXXXX BI12P20205V CONNECTOR ASSY 2P
XXXXX BI12P30269Y CONNECTOR WIRE
3P for MAIN CN301
to CASS MECHA
XXXXX BI12P80123Y CONNECTOR WIRE
8P for MAIN CN302
to CASS MECHA
XXXXX BIRT103THMSP01 THERMISTOR 10K
XXXXX BI1207271Y FFC CABLE
12P for MAIN
CN306 to TUNER
A,UW,
UY,UJ

Symbol
No.
Part No. Part Name Description Local
