ustment  method
Measurement  instruments  required  for Tuner  section
adjustment
1
Low  frequency  oscillator   Voltage  applied  to  tuner ---------- +B:DC 4.9V
This  oscillator  should  have  a  capacity  to  output           VT:DC 12V
0dBs  to  600   at  an  oscillation  frequency  of Reference  measurement ----- 26.1mV(0.28V)/3
50Hz-20KHz output
Input  positions ----- AM : Standard  loop  antenna
2
Electronic  voltmeter                              FM : TP1 (hot)  and  TP2 (GND)
3
Distortion  meter
4
Frequency  counter Standard  measurement  position  of  volume
5
Wow  &  flutter  meter
6
Test  tape Bass ----------------------------------------------------- Off
TCC-112 : Tape  speed  and  running  unevenness (3KHz) Active  hoper  bass  pro ------------------------ Off
TCC-140 : Reference  level (1KHz) Up  and  down  adjustment  of  volume ----- Vol : 23
TCC-182A : Head  angle (8KHz) , playback  frequency
                     characteristics (1KHz)  and  dubbing  frequency Precautions  for  measurement
                     characteristics (125Hz  and  8KHz) 1 Apply  30PF  and  33 Kohm  to  the  IF  sweeper  output
Because  of  frequency - mixed  tape  with 63 , 1 , 10  and side  and  0.082UF  and  100 Kohm  in  series  to  the
14KHz (250nWb/m -24dB) , use  this  tape  together sweeper  input  side .
with  a  filter . 2 The  IF  sweeper  output  level  should  be  made  as
7
Black  tape low  as  possible  within  the  adjustable  range .
TYPE I : AC - 225 3 Since  the  IF  sweeper  is  a  fixed  device , there  is  no
TYPE II : AC - 514 need  to  adjust  this  sweeper .
8 Torque  gauge : For  play  and  back  tension 4 Since  a  ceramic  oscillator  is  used , there  is  no  need
FWD(TW2111A) , REV(TW2121a)  and  FF/REW(TW2231A) to  perform  any  MIX  adjustment .
5 Since  a  fixed  coil  is  used , there  is  no  need  to
Measurement  conditions adjust  the  FM  tracking .
6 The  input  and  output  earth  systems  are  separated .
Power  supply  voltage ---------------- AC 120V (60Hz) In  case  of  simultaneously  measuring  the  voltage  in
Reference  output -------------- Speaker : 0.866V/3 both  of  the  input  and  output  systems  with  an
                                           Headphone : 0.245V/32 electronic  voltmeter  for  two  channels , therefore , the
Reference  frequency  and ----- 1KHz , AUX : 450~500mV earth  should  be  connected  particularly  carefully .
input  level 7 In  the  case  of  BTL  connection  amp. , the  minus
Input  for  confirming  recording  and ------- AUX : -28dBs terminal  of  speaker  is  not  for  earthing . Therefore , be
playback  characteristics sure  not  to  connect  any  other  earth  terminal  to  this
Measurement  output  terminal ---------- Speaker J3002 terminal . This  system  is  of  an  BTL  system .
* Load  resistance ---------------------------  3 8 For  connecting  a  dummy  resistor  when  measuring
the  output , use  the  wire  with  a  greater  code  size .
Radio  Input  signal 9 Whenever  any  mixed  tape  is  used , use  the  band
pass  filter (DV-12V)
AM  frequency  -------------------------------- 400Hz
AM  modulation ---------------------------------- 30%
FM  frequency --------------------------------- 1 KHz
FM  frequency  deviation ------------------------ 22.5KHz
PC-X250
1 - 6
