EN
BLUETOOTH
• In Bluetooth mode, <BT LINK> will flash on the display. This means the unit is not paired
with any Bluetooth device.
• Activate Bluetooth of mobile phone and search for device name RD-E861B-DAB then
connect it. If the pairing is successful, <BT LINK> will be solid on the display.
Playback
• Adjust the volume to your desired level.
• Press
to play/pause the playback.
• Press / to skip to the previous/next track.
NOTE: The operational range between the unit and the device is approximately 8 meters.
If the signal strength is weak, your Bluetooth receiver may disconnect, but it will re-enter pairing mode
automatically.
For better signal reception, remove any obstacles between the unit and the Bluetooth device.
Compatibility with all devices and media types is not guaranteed.
Some mobile phones with Bluetooth functions may connect and disconnect as you make and end calls.
This is not an indication of a problem with the unit.
SPECIFICATIONS
GENERAL
Power Supply AC 100 ~ 240 V; 50/60 Hz
Power consumption < 32 W
Standby Power consumption < 1 W
Weight Approx. 2,6 kg
Dimensions 350 x 120 X 210 mm
Operation temperature +5°C ~ +35°C
RADIO SECTION
FM Frequency Range 87,5 – 108 MHz
DAB+ Frequency Range 174 – 240 MHz
Presets DAB+ 30 / FM 30
CD SECTION
Frequency Response 20 Hz – 20 kHz
BLUETOOTH SECTION
Bluetooth V 5.0 - Supports A2DP, AVRCP proles
BT Frequency Range 2402 – 2480 MHz
EIRP 4 dBm
AUDIO SECTION
Power output 2 x 5 Watts RMS
WE RESERVE THE RIGHT TO CHANGE TECHNICAL SPECIFICATIONS.
PACKAGE CONTENTS
DAB+ All-in-one Audio System, Remote Control, User manual
