JVC RX-5022VSL

3-6
RX-5020VBK/RX-5022VSL
Item
Parts number Parts name Ar
e
a
Remarks
A
D 221 1SS133-T2 SI DIODE IM
D 301 1SS133-T2 SI DIODE IM
D 302 1SS133-T2 SI DIODE IM
D 303 SLR-342MC-T LED
D 304 SLR-342MC-T LED
D 305 1SS133-T2 SI DIODE IM
D 306 1SS133-T2 SI DIODE IM
D 307 1SS133-T2 SI DIODE IM
D 308 1SS133-T2 SI DIODE IM
D 309 1SS133-T2 SI DIODE IM
D 310 1SS133-T2 SI DIODE IM
D 801 1SS133-T2 SI DIODE IM
D 802 1SS133-T2 SI DIODE IM
D 805 1SS133-T2 SI DIODE IM
D 806 1SS133-T2 SI DIODE IM
D 807 1SS133-T2 SI DIODE IM
D 808 1SS133-T2 SI DIODE IM
D 809 1SS133-T2 SI DIODE IM
D 810 1SS133-T2 SI DIODE IM
D 901 1SS133-T2 SI DIODE IM
D 905 1SS133-T2 SI DIODE IM
D 907 1SS133-T2 SI DIODE IM
D 909 1SS133-T2 SI DIODE IM
EP 1 E409182-001SM GRAND TERMINAL
EP201 QNZ0136-001Z EARTH PLATE
FC211 QNG0020-001Z FUSE CLIP F201
FC212 QNG0020-001Z FUSE CLIP F201
FC221 QNG0020-001Z FUSE CLIP F202
FC222 QNG0020-001Z FUSE CLIP F202
FC231 QNG0020-001Z FUSE CLIP F203
FC232 QNG0020-001Z FUSE CLIP F203
FW201 QUM137-14Z4Z4 PARA RIBON WIRE
FW251 QUM133-08Z4Z4 PARA RIBON WIRE
IC501 NJM2246D IC
J 501 QNN0063-001 PIN JACK
J 502 QNN0063-001 PIN JACK VCR
(
R/P
)
J 521 QNS0073-001 JACK
J1331 QNS0022-001 JACK
L 301 QQLZ005-R45 INDUCTOR
L 302 QQLZ005-R45 INDUCTOR
L 801 QQLZ005-R45 INDUCTOR
L 802 QQLZ005-R45 INDUCTOR
L 901 QQLZ005-R45 INDUCTOR
Q
202 KRC105M-T D.TR.I.M.
Q
203 KTC3203/OY/-T TRANSISTOR
Q
205 KTC3200/GL/-T TRANSISTOR
Q
206 KRC105M-T D.TR.I.M.
Q
207 KRC105M-T D.TR.I.M.
Q
208 KRC105M-T D.TR.I.M.
Q
209 KRC105M-T D.TR.I.M.
Q
210 KRC105M-T D.TR.I.M.
Q
301 2SC2240/L/-T TR.I/M
Q
302 2SC2240/L/-T TR.I/M
Q
303 2SC2240/L/-T TR.I/M
Q
304 2SC2240/L/-T TR.I/M
Q
305 KTA1268/GL/-T TRANSISTOR
Q
306 KTA1268/GL/-T TRANSISTOR
Q
307 KTC3200/GL/-T TRANSISTOR
Q
308 KTC3200/GL/-T TRANSISTOR
Q
309 2SD637/QR/ TRANSISTOR
Q
310 2SD637/QR/ TRANSISTOR
Q
311 KTC3200/GL/-T TRANSISTOR
Q
312 KTC3200/GL/-T TRANSISTOR
Q
313 KTA1268/GL/-T TRANSISTOR
Q
314 KTA1268/GL/-T TRANSISTOR
Q
315 2SD2389/OPY/-F6 TRANSISTOR
A
Q
316 2SD2389/OPY/-F6 TRANSISTOR
A
Q
317 2SB1559/OPY/-F6 TRANSISTOR
A
Q
318 2SB1559/OPY/-F6 TRANSISTOR
A
Q
319 KTA1268/GL/-T TRANSISTOR
Q
320 KTA1268/GL/-T TRANSISTOR
Q
501 KTA1267/YG/-T TRANSISTOR
Q
502 KTC3199/GL/-T TRANSISTOR
Q
503 KRC101M-T TR I/M
Q
504 KTA1267/YG/-T TRANSISTOR
Q
505 KTC3199/GL/-T TRANSISTOR
Q
801 2SC2240/L/-T TR.I/M
Q
802 2SC2240/L/-T TR.I/M
Q
803 2SC2240/L/-T TR.I/M
Q
804 2SC2240/L/-T TR.I/M
Q
805 KTA1268/GL/-T TRANSISTOR
Q
806 KTA1268/GL/-T TRANSISTOR
Q
809 2SD637/QR/ TRANSISTOR
Q
810 2SD637/QR/ TRANSISTOR
Q
811 KTC3200/GL/-T TRANSISTOR
Q
812 KTC3200/GL/-T TRANSISTOR
Q
813 KTA1268/GL/-T TRANSISTOR
Q
814 KTA1268/GL/-T TRANSISTOR
Q
815 2SD2389/OPY/-F6 TRANSISTOR
A
Q
816 2SD2389/OPY/-F6 TRANSISTOR
A
Q
817 2SB1559/OPY/-F6 TRANSISTOR
A
Q
818 2SB1559/OPY/-F6 TRANSISTOR
A
Q
819 KTA1268/GL/-T TRANSISTOR
Q
820 KTA1268/GL/-T TRANSISTOR
Q
901 2SC2240/L/-T TR.I/M
Q
903 2SC2240/L/-T TR.I/M
Q
905 KTA1268/GL/-T TRANSISTOR
Q
909 2SD637/QR/ TRANSISTOR
Q
911 KTC3200/GL/-T TRANSISTOR
Q
913 KTA1268/GL/-T TRANSISTOR
Q
915 2SD2389/OPY/-F6 TRANSISTOR
A
Q
917 2SB1559/OPY/-F6 TRANSISTOR
A
Q
919 KTA1268/GL/-T TRANSISTOR
R 1 QRZ9044-335 F RESISTOR
A
3.3M 1/4W
R 201 QRJ146J-2R7X UNF C RESISTOR
A
2.7 5% 1/4W
R 203 QRJ146J-100X UNF C RESISTOR
A
10 5% 1/4W
R 204 QRJ146J-821X UNF C RESISTOR
A
820 5% 1/4W
R 208 QRJ146J-100X UNF C RESISTOR
A
10 5% 1/4W
R 209 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 210 QRJ146J-680X UNF C RESISTOR
A
68 5% 1/4W
R 221 QRJ146J-100X UNF C RESISTOR
A
10 5% 1/4W
R 301 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R 302 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R 303 QRE141J-563Y C RESISTOR 56K 5% 1/4W
R 304 QRE141J-563Y C RESISTOR 56K 5% 1/4W
R 305 QRE141J-123Y C RESISTOR 12K 5% 1/4W
R 306 QRE141J-123Y C RESISTOR 12K 5% 1/4W
R 307 QRE141J-272Y C RESISTOR 2.7K 5% 1/4W
R 308 QRE141J-272Y C RESISTOR 2.7K 5% 1/4W
R 309 QRE141J-101Y C RESISTOR 100 5% 1/4W
R 310 QRE141J-101Y C RESISTOR 100 5% 1/4W
R 311 QRJ146J-391X UNF C RESISTOR 390 5% 1/4W
R 312 QRJ146J-391X UNF C RESISTOR 390 5% 1/4W
R 313 QRE141J-563Y C RESISTOR 56K 5% 1/4W
R 314 QRE141J-563Y C RESISTOR 56K 5% 1/4W
R 315 QRJ146J-331X UNF C RESISTOR
A
330 5% 1/4W
Electrical parts list (Power amp board)
Block No. 01
Item
Parts number Parts name Ar
e
a
Remarks
A
