38
Specifications
Amplifier
Output Power
At Stereo operation
Front channels:
100 W per channel, min. RMS, driven into 8 Ω,
40 Hz to 20 kHz with no more than 0.8% total
harmonic distortion.
At Surround operation
Front channels: 100 W per channel, min. RMS, driven into 8 Ω, at 1 kHz with no
more than 0.8% total harmonic distortion.
Center channel: 100 W, min. RMS, driven into 8 Ω, at 1 kHz with no more than 0.8%
total harmonic distortion.
Surround channels: 100 W per channel, min. RMS, driven into 8 Ω, at 1 kHz with no
more than 0.8% total harmonic distortion.
Audio
Audio Input Sensitivity/Impedance (1 kHz)
CD, TAPE/CDR, VCR, TV SOUND, DVD: 220 mV/47 kΩ
Audio Input (DIGITAL IN)*
Coaxial DIGITAL 1 (DVD): 0.5 V(p-p)/75 Ω
Optical RX-6040B/RX-6042S
DIGITAL 2 (CD), DIGITAL 3 (TV): –21 dBm to –15 dBm (660 nm ±30 nm)
RX-5040B/RX-5042S/RX-5045B
DIGITAL 2 (CD): –21 dBm to –15 dBm (660 nm ±30 nm)
* Corresponding to Linear PCM, Dolby Digital, and DTS Digital Surround (with sampling frequency—32 kHz, 44.1 kHz,
48 kHz)
Recording Output Level TAPE/CDR, VCR: 220 mV
Signal-to-Noise Ratio (’66 IHF/’78 IHF)
CD, TAPE/CDR, VCR, TV SOUND, DVD: 87 dB/74 dB
Frequency Response (8 Ω)
CD, TAPE/CDR, VCR, TV SOUND, DVD: 20 Hz to 50 kHz (+1 dB, –3 dB)
Bass Boost—Only for RX-6040B/RX-6042S: +3 dB ±1 dB at 100 Hz
Equalization (5 bands) 63 Hz, 250 Hz, 1 kHz, 4 kHz, 16 kHz: ±8 dB (in 2 dB steps)
Video
Video Input Sensitivity/Impedance
Composite video DVD, VCR: 1 V(p-p)/75 Ω
S-video—Only for RX-6040B/RX-6042S
DVD, VCR (Y: luminance): 1 V(p-p)/75 Ω
(C: chrominance, burst): 0.286 V(p-p)/75 Ω
Component—Only for RX-6040B/RX-6042S
DVD, VCR (Y: luminance): 1 V(p-p)/75 Ω
(P
B, PR): 0.7 V(p-p)/75 Ω
Video Output Level
Composite video VCR, MONITOR OUT: 1 V(p-p)/75 Ω
S-video—Only for RX-6040B/RX-6042S
VCR, MONITOR OUT (Y: luminance): 1 V(p-p)/75 Ω
(C: chrominance, burst): 0.286 V(p-p)/75 Ω
Component—Only for RX-6040B/RX-6042S
MONITOR OUT (Y: luminance): 1 V(p-p)/75 Ω
(P
B, PR): 0.7 V(p-p)/75 Ω
Synchronization: Negative
Signal-to-Noise Ratio: 45 dB
