JVC RX-558RBK - Technical Specifications; Amplifier Output and Performance

27
English
Specifications
Amplifier
Output Power
At Stereo operation: 55 watts per channel, min. RMS, both
channels driven into 4 ohms at 1kHz, with
no more than 0.9 % total harmonic
distortion. (IEC268-3/DIN)
At Surround operation:
Front Channel: 50 watts per channel, min. RMS, driven into
4 ohms at 1 kHz, with no more than 0.8 %
total harmonic distortion.
Center channel: 50 watts, min. RMS, driven into 4 ohms at 1
kHz, with no more than 0.8 % total
harmonic distortion.
Rear channel: 50 watts per channel, min. RMS, driven into
4 ohms at 1 kHz, with no more than 0.8 %
total harmonic distortion.
Total Harmonic Distortion (4 ohms, 1 kHz):
0.8 %* at 55 watts output
(* Measured by JVC Audio Analysis
System)
Audio Input Sensitivity/Impedance (1 kHz):
PHONO (MM): 1.5 mV/47 k ohms
CD, TAPE/MD, VCR, DVD:
120 mV/47 k ohms
Audio Output Level: TAPE/MD, VCR 120 mV
Signal-to-Noise Ratio (’66 IHF/DIN):
PHONO: 70 dB/66 dB
CD, TAPE/MD, VCR, DVD:
87 dB/67 dB
Frequency Response (8 ohms):
PHONO: 20 Hz to 20 kHz (±1 dB)
CD, TAPE/MD, VCR, DVD:
20 Hz to 20 kHz (±1 dB)
RIAA Phono Equalization: ±1.0 dB (20 Hz to 20 kHz)
