32
English
Specifications
Amplifier
Output Power
At Stereo operation:
Front channels:
100 W per channel, min. RMS, driven into 8 Ω
40 Hz to 20 kHz with no more than 0.8% total
harmonic distortion.
At Surround operation:
Front channels: 100 W per channel, min. RMS, driven into 8 Ω at 1 kHz with no
more than 0.8% total harmonic distortion.
Center channel: 100 W, min. RMS, driven into 8 Ω at 1 kHz, with no more than
0.8% total harmonic distortion.
Rear channels: 100 W per channel, min. RMS, driven into 8 Ω at 1 kHz, with no
more than 0.8% total harmonic distortion.
Audio
Audio Input Sensitivity/Impedance (1 kHz): PHONO (MM): 2.7 mV/47 k Ω
CD, TAPE/MD, TV SOUND/DBS, VCR, DVD:
220 mV/47 k Ω
Audio Input (DIGITAL IN)* : Coaxial: DIGITAL 1 (DVD): 0.5 V (p-p)/75 Ω
Optical: DIGITAL 2 (CD): –21 dBm to –15 dBm (660 nm ±30 nm)
* Corresponding to Linear PCM, Dolby Digital, and DTS Digital Surround (with
sampling frequency — 32 kHz, 44.1 kHz, 48 kHz).
Audio Output Level: TAPE/MD, VCR: 220 mV
Signal-to-Noise Ratio (’66 IHF/’78 IHF): PHONO: 70 dB/78 dB (at REC OUT)
CD, TAPE/MD, TV SOUND/DBS, VCR, DVD:
87 dB/80 dB
Frequency Response (8 ohms): PHONO: 20 Hz to 20 kHz (±1 dB)
CD, TAPE/MD, TV SOUND/DBS, VCR, DVD:
20 Hz to 20 kHz (±1 dB)
RIAA Phono Equalization: ±1 dB (20 Hz to 20 kHz)
Bass Boost: +3 dB ±1
dB at 100 Hz
Tone Control: Bass (100 Hz): ±10 dB ±2 dB
Treble (10 kHz): ±10 dB ±2 dB
Video
Video Input Sensitivity/Impedance:
Composite video: DBS, VCR, DVD: 1 V (p-p)/75 Ω
S-video: DVD: (Y: luminance): 1 V (p-p)/75 Ω
(C: chrominance, burst): 0.286 V (p-p)/75 Ω
Video Output Level:
Composite video: VCR, MONITOR OUT: 1 V (p-p)/75 Ω
S-video: MONITOR OUT: (Y: luminance): 1 V (p-p)/75 Ω
(C: chrominance, burst): 0.286 V (p-p)/75 Ω
Synchronization: Negative
Signal-to-Noise Ratio: 45 dB
