RX-7010RBK/RX-7012RSL
3-4
Item Parts number Parts name Area
A
Parts list
Q'ty Description
Block No. M1MM
1 LV10457-004A FRONT PANEL 1 RX-7012RSL
LV10457-003A FRONT PANEL 1 RX-7010RBK
2 VJD5429-001SS JVC MARK 1 RX-7010RBK
VJD5429-002SS JVC MARK 1 RX-7012RSL
3 LV20950-002A LENS 1
4 LV10459-002A SUB PANEL 1 RX-7012RSL
LV10459-001A SUB PANEL 1 RX-7010RBK
5 LV32431-004A POWER BUTTON 1 RX-7010RBK
LV32431-002A POWER BUTTON 1 RX-7012RSL
6 LV42096-001A INDICATOR 1 POWER
7 LV20951-001A PUSH BUTTON 1 TUNER
8 LV20919-002A PUSH BUTTON
(
C
)
1 RX-7012RSL
LV20919-001A PUSH BUTTON
(
C
)
1 RX-7010RBK
9 LV20917-001A PUSH BUTTON
(
E
)
1 RX-7010RBK
LV20917-002A PUSH BUTTON
(
E
)
1 RX-7012RSL
10 LV32430-001A PUSH BUTTON
(
F
)
1 RX-7010RBK
LV32430-002A PUSH BUTTON
(
F
)
1 RX-7012RSL
11 LV42095-001A FL SCREEN 1
12 QYSBSF2610Z SCREW 2 FRONT C.B
13 QYSBSF2610Z SCREW 6 FRONT C.B FL
14 QUQ412-1415CJ FFC WIRE 1
15 QUQ412-2538CJ FFC WIRE 1
16 QYSDSG3006Z SCREW 4 FRONT D
17 QYSBSG3006Z T.SCREW 3 FRONT U
18 LV10019-003A CHASSIS BASE 1
19 EXO150010H09S11 FELT SPACER 1 FOR C.BASE
20 LV10458-002A FRONT BRACKET 1
21 QYSDSG3006Z SCREW 7 C.B-F.B
22 LV42094-002A H.P. BKT 1
23 QYSBSG3006Z T.SCREW 1 H.P BKT-F.B
24 VKZ4150-001 SPECIAL NUT 1
25 E68587-223SM CB BKT 3
26 QYSBST3006Z T.SCREW 3 C.B-BKT
27 QZF6018-003 FOOT 4 RX-7012RSL
QZF6018-001 FOOT 4 RX-7010RBK
28 QYSBST3010Z T.SCREW 4 FOOT
29 LV20916-002A HEAT SINK 1
30 E73525-003SS SCREW 10 TR
31 LV42098-001A C.B BKT 1 PRI/SEC C.B
32 QYSBST3006Z T.SCREW 1 C.B BKT
33 LV32433-001A H.S BRACKET
(
R
)
1
34 LV32434-001A H.S BRACKET
(
L
)
1
35 QYSBSG3008Z T.SCREW 4 H.S-BKT
36 QYSBSG3006Z T.SCREW 2 H.S BKT-F.BKT
37 QYSBSG3006Z T.SCREW 2 H.S BKT
38 QYSBST3006Z T.SCREW 2 H.S BKT-CHASSIS
39 QYSBSG3006Z T.SCREW 2 M.C.B
40 E65923-003 TAPPING SCREW 1 M.C.B
(General assembly)
Item Parts number Parts name Area
A
Parts list
Q'ty Description
Block No. M1MM
41 QYSBSG3006Z T.SCREW 3 H.S-C.B
42 QYSBSG3006Z T.SCREW 3 P.C.B-CHASSIS
43 QYSBSG3006Z T.SCREW 1 C.B-CHASSIS
44 QQT0316-001 POWER TRANSF
A
1 BANDO
45 QYSDSTL4008Z SPECIAL SCREW 4 P.TRANS
46 LV20915-020A REAR PANEL 1 RX-7012RSL
LV20915-019A REAR PANEL 1 RX-7010RBK
47 QYSBSGY3008M SPECIAL SCREW 3 R.P-C.BASE
48 QYSBSGY3008M SPECIAL SCREW 1 R.P-ud---
49 QYSBSGY3008M SPECIAL SCREW 2 TUNER
50 QYSBSGY3008M SPECIAL SCREW 5 INPUT
51 QYSBSGY3008M SPECIAL SCREW 3 V AUDIO
52 QYSBSGY3008M SPECIAL SCREW 3 VIDEO
53 QYSBSGY3008M SPECIAL SCREW 3 S VIDEO
54 QYSBSGY3008M SPECIAL SCREW 5 DIGITAL
55 QYSBSGY3008M SPECIAL SCREW 1 COMP C.B
56 QYSBSGY3008M SPECIAL SCREW 5 SPK C.B
57 QMPK150-200-JD POWER CORD
A
1
58 QZW0033-001 STRAIN RELIEF
A
1
59 LE20131-010A/S/ TOP COVER 1 RX-7010RBK
LE20131-011A/S/ METAL COVER 1 RX-7012RSL
60 QYSBSGY3008M SPECIAL SCREW 3
61 E406308-004 SPECIAL SCREW 4 RX-7012RSL
E406308-003 SPECIAL SCREW 4 RX-7010RBK
62 LV32435-004A VOLUME KNOB 1 RX-7012RSL
LV32435-003A VOL KNOB 1 RX-7010RBK
63 QMF51E2-2R5-J1 FUSE
A
1 F201
64 QMF51E2-2R0-J1 FUSE
A
2 F202 F203
65 E409396-001 CAUTION LABEL 1
66 QYSBSG3008E T.SCREW 1
67 QYSBSG3008E T.SCREW 1
68 QYSBSG3008E T.SCREW 1
69 QYSBSG3008E T.SCREW 2
70 QYSBSG3008E T.SCREW 2
71 LV30225-097A SPACER 2
76 LV20952-001A PUSH BUTTON 1 RDS
77 LV30077-006A PROTECT SHEET 1 RX-7012RSL
LV30077-004A PROTECT SHEET 1 RX-7010RBK
78 QMF51E2-R10-J1 FUSE
A
1 F205
79 E307572-001 FASTENER 1
(General assembly)
