JVC RX-7032VSL Service Manual

3-20
J564 QNN0347-001 SURROUND JACK
K2261 NQR0007-003X FERRITE BEADS
K2262 NQR0007-003X FERRITE BEADS
K2263 NQR0007-003X FERRITE BEADS
K2264 NQR0007-003X FERRITE BEADS
K2606 NQR0269-004X FERRITE BEADS
LC505 NQR0450-001X EMI FILTER 0.022uF 50V M
LC506 NQR0450-001X EMI FILTER 0.022uF 50V M
LC507 NQR0450-001X EMI FILTER 0.022uF 50V M
UN560 GP1FA351TZ OPT TRANSMITTER
UN561 GP1FA351RZ OPT RECEIVER Fiber optic receiver
UN562 GP1FA351RZ OPT RECEIVER Fiber optic receiver
UN563 GP1FA351RZ OPT RECEIVER Fiber optic receiver
X581 NAX0275-001X C OSCILLATOR 6.144MHz
X2501 NAX0308-001X C RESONATOR 12.500MHz
X2701 NAX0435-001X CRYSTAL 24.576MHz
 Symbol No. Part No. Part Name Description Local
