RX-7040B
3-11
Input board
Block No. [0][5][0][0]
R1723 QRE141J-332Y C RESISTOR 3.3k
Ω
1/4W J
R1724 QRE141J-332Y C RESISTOR 3.3k
Ω
1/4W J
R1725 QRE141J-332Y C RESISTOR 3.3k
Ω
1/4W J
R1731 QRE141J-911Y C RESISTOR 910
Ω
1/4W J
R1732 QRE141J-391Y C RESISTOR 390
Ω
1/4W J
R1733 QRE141J-271Y C RESISTOR 270
Ω
1/4W J
R1741 QRJ146J-221X UNF C RESISTOR 220
Ω
1/4W J
R1751 QRJ146J-100X UNF C RESISTOR 10
Ω
1/4W J
R1752 QRJ146J-100X UNF C RESISTOR 10
Ω
1/4W J
R1753 QRZ0218-R22 EMIT RESISTOR 0.22
Ω
R1761 QRJ125J-330 UNF C RESISTOR 33
Ω
1/2W J
R1762 QRL027J-100 OMF RESISTOR 10
Ω
2W J
R1771 QRE141J-391Y C RESISTOR 390
Ω
1/4W J
R1772 QRE141J-391Y C RESISTOR 390
Ω
1/4W J
R1773 QRE141J-201Y C RESISTOR 200
Ω
1/4W J
R1774 QRE141J-201Y C RESISTOR 200
Ω
1/4W J
R1791 QRE141J-102Y C RESISTOR 1k
Ω
1/4W J
R1793 QRE141J-183Y C RESISTOR 18k
Ω
1/4W J
R1795 QRE141J-473Y C RESISTOR 47k
Ω
1/4W J
R1801 QRE141J-222Y C RESISTOR 2.2k
Ω
1/4W J
R1802 QRE141J-222Y C RESISTOR 2.2k
Ω
1/4W J
R1803 QRE141J-683Y C RESISTOR 68k
Ω
1/4W J
R1804 QRE141J-683Y C RESISTOR 68k
Ω
1/4W J
R1805 QRE141J-202Y C RESISTOR 2k
Ω
1/4W J
R1806 QRE141J-202Y C RESISTOR 2k
Ω
1/4W J
R1809 QRE141J-123Y C RESISTOR 12k
Ω
1/4W J
R1810 QRE141J-123Y C RESISTOR 12k
Ω
1/4W J
R1811 QRE141J-331Y C RESISTOR 330
Ω
1/4W J
R1812 QRE141J-331Y C RESISTOR 330
Ω
1/4W J
R1813 QRE141J-563Y C RESISTOR 56k
Ω
1/4W J
R1814 QRE141J-563Y C RESISTOR 56k
Ω
1/4W J
R1821 QRJ146J-221X UNF C RESISTOR 220
Ω
1/4W J
R1822 QRJ146J-221X UNF C RESISTOR 220
Ω
1/4W J
R1823 QRE141J-332Y C RESISTOR 3.3k
Ω
1/4W J
R1824 QRE141J-332Y C RESISTOR 3.3k
Ω
1/4W J
R1825 QRE141J-332Y C RESISTOR 3.3k
Ω
1/4W J
R1826 QRE141J-332Y C RESISTOR 3.3k
Ω
1/4W J
R1827 QRE141J-332Y C RESISTOR 3.3k
Ω
1/4W J
R1828 QRE141J-332Y C RESISTOR 3.3k
Ω
1/4W J
R1829 QRE141J-332Y C RESISTOR 3.3k
Ω
1/4W J
R1830 QRE141J-332Y C RESISTOR 3.3k
Ω
1/4W J
R1831 QRE141J-911Y C RESISTOR 910
Ω
1/4W J
R1832 QRE141J-911Y C RESISTOR 910
Ω
1/4W J
R1833 QRE141J-391Y C RESISTOR 390
Ω
1/4W J
R1834 QRE141J-391Y C RESISTOR 390
Ω
1/4W J
R1835 QRE141J-271Y C RESISTOR 270
Ω
1/4W J
R1836 QRE141J-271Y C RESISTOR 270
Ω
1/4W J
R1841 QRJ146J-221X UNF C RESISTOR 220
Ω
1/4W J
R1842 QRJ146J-221X UNF C RESISTOR 220
Ω
1/4W J
R1851 QRJ146J-100X UNF C RESISTOR 10
Ω
1/4W J
R1852 QRJ146J-100X UNF C RESISTOR 10
Ω
1/4W J
R1853 QRJ146J-100X UNF C RESISTOR 10
Ω
1/4W J
R1854 QRJ146J-100X UNF C RESISTOR 10
Ω
1/4W J
R1855 QRZ0218-R22 EMIT RESISTOR 0.22
Ω
R1856 QRZ0218-R22 EMIT RESISTOR 0.22
Ω
R1861 QRJ125J-330 UNF C RESISTOR 33
Ω
1/2W J
R1862 QRJ125J-330 UNF C RESISTOR 33
Ω
1/2W J
R1863 QRL027J-100 OMF RESISTOR 10
Ω
2W J
R1864 QRL027J-100 OMF RESISTOR 10
Ω
2W J
R1871 QRE141J-391Y C RESISTOR 390
Ω
1/4W J
R1872 QRE141J-391Y C RESISTOR 390
Ω
1/4W J
R1873 QRE141J-391Y C RESISTOR 390
Ω
1/4W J
R1874 QRE141J-391Y C RESISTOR 390
Ω
1/4W J
R1875 QRE141J-201Y C RESISTOR 200
Ω
1/4W J
R1876 QRE141J-201Y C RESISTOR 200
Ω
1/4W J
R1877 QRE141J-201Y C RESISTOR 200
Ω
1/4W J
R1878 QRE141J-201Y C RESISTOR 200
Ω
1/4W J
R1891 QRE141J-102Y C RESISTOR 1k
Ω
1/4W J
R1892 QRE141J-102Y C RESISTOR 1k
Ω
1/4W J
R1893 QRE141J-183Y C RESISTOR 18k
Ω
1/4W J
R1894 QRE141J-183Y C RESISTOR 18k
Ω
1/4W J
R1895 QRE141J-473Y C RESISTOR 47k
Ω
1/4W J
R1896 QRE141J-473Y C RESISTOR 47k
Ω
1/4W J
R1901 QRE141J-222Y C RESISTOR 2.2k
Ω
1/4W J
R1902 QRE141J-683Y C RESISTOR 68k
Ω
1/4W J
R1903 QRE141J-202Y C RESISTOR 2k
Ω
1/4W J
R1905 QRE141J-123Y C RESISTOR 12k
Ω
1/4W J
R1911 QRE141J-331Y C RESISTOR 330
Ω
1/4W J
Symbol No.
Part No. Part Name Description Local
R1912 QRE141J-563Y C RESISTOR 56k
Ω
1/4W J
R1921 QRJ146J-221X UNF C RESISTOR 220
Ω
1/4W J
R1922 QRE141J-332Y C RESISTOR 3.3k
Ω
1/4W J
R1923 QRE141J-332Y C RESISTOR 3.3k
Ω
1/4W J
R1924 QRE141J-332Y C RESISTOR 3.3k
Ω
1/4W J
R1925 QRE141J-332Y C RESISTOR 3.3k
Ω
1/4W J
R1931 QRE141J-911Y C RESISTOR 910
Ω
1/4W J
R1932 QRE141J-391Y C RESISTOR 390
Ω
1/4W J
R1933 QRE141J-271Y C RESISTOR 270
Ω
1/4W J
R1941 QRJ146J-221X UNF C RESISTOR 220
Ω
1/4W J
R1951 QRJ146J-100X UNF C RESISTOR 10
Ω
1/4W J
R1952 QRJ146J-100X UNF C RESISTOR 10
Ω
1/4W J
R1953 QRZ0218-R22 EMIT RESISTOR 0.22
Ω
R1961 QRJ125J-330 UNF C RESISTOR 33
Ω
1/2W J
R1962 QRL027J-100 OMF RESISTOR 10
Ω
2W J
R1971 QRE141J-391Y C RESISTOR 390
Ω
1/4W J
R1972 QRE141J-391Y C RESISTOR 390
Ω
1/4W J
R1973 QRE141J-201Y C RESISTOR 200
Ω
1/4W J
R1991 QRE141J-102Y C RESISTOR 1k
Ω
1/4W J
R1993 QRE141J-183Y C RESISTOR 18k
Ω
1/4W J
R1994 QRE141J-201Y C RESISTOR 200
Ω
1/4W J
R1995 QRE141J-473Y C RESISTOR 47k
Ω
1/4W J
VR787 QVP0008-501Z TRIM RESISTOR 500
Ω
VR788 QVP0008-501Z TRIM RESISTOR 500
Ω
L791 QQLZ003-1R0 COIL 1uH
L792 QQLZ003-1R0 COIL 1uH
L1761 QQLZ005-R45 COIL 0.45uH
L1861 QQLZ005-R45 COIL 0.45uH
L1862 QQLZ005-R45 COIL 0.45uH
L1961 QQLZ005-R45 COIL 0.45uH
CN711 QGB2510K1-12 CONNECTOR B-B (1-12)
CN712 QGB2510K1-12 CONNECTOR B-B (1-12)
CN713 QGB2510K1-10 CONNECTOR B-B (1-10)
CN714 QGA2501F1-02 CONNECTOR W-B (1-2)
CN715 QGB2510K1-12 CONNECTOR B-B (1-12)
CN716 QGB2510K1-12 CONNECTOR B-B (1-12)
CN717 QGA2001F1-03 CONNECTOR W-B (1-3)
CN718 QGB2510K1-10 CONNECTOR B-B (1-10)
CN719 QGA2501F1-03 CONNECTOR W-B (1-3)
CN722 QGA2001F1-02 CONNECTOR W-B (1-2)
TH731 QAD0012-202 THERMISTOR 2k
Ω
L
TH783 QAD0012-202 THERMISTOR 2k
Ω
L
TH784 QAD0012-202 THERMISTOR 2k
Ω
L
TH831 QAD0012-202 THERMISTOR 2k
Ω
L
TH832 QAD0012-202 THERMISTOR 2k
Ω
L
TH901 QAD0012-202 THERMISTOR 2k
Ω
L
Symbol No.
Part No. Part Name Description Local
IC304 HA17558AF-X IC
IC380 TC9162AF-X IC
IC381 TC9459F-X IC
IC382 TC9459F-X IC
IC383 TC9459F-X IC
IC384 TC9459F-X IC
IC386 HA17558AF-X IC
IC389 MM74HC4053SJ-X IC
IC390 NJM2580M-X IC
IC397 HA17558AF-X IC
IC399 HA17558AF-X IC
Q1310 KRA104S-X DIGI TRANSISTOR
Q1313 2SC3576-JVC-T TRANSISTOR
Q1314 2SC3576-JVC-T TRANSISTOR
Q1324 2SC3576-JVC-T TRANSISTOR
Q1333 2SC3576-JVC-T TRANSISTOR
Q1334 2SC3576-JVC-T TRANSISTOR
Q1441 2SC3576-JVC-T TRANSISTOR
Q1445 2SC3576-JVC-T TRANSISTOR
Symbol No.
Part No. Part Name Description Local
