The soundtracks of the video software bearing
mark includes the same encoded surround information as found
in the Dolby Stereo films.
As the receiver incorporates a DOLBY PRO-LOGIC SURROUND
decoder circuit, you can get the Dolby Stereo theatre’s ambience
and effect, when watching these video sources at home.
Dolby Pro Logic Surround decoder provides:
@ Four primary sound channels — LEFT, RIGHT, SURROUND and
additional CENTER channel.
@ Adaptive Matrix to actively derive each channel.
The result is that Dolby Pro Logic Surround has the effect of widen-
ing the useful listening area and enhancing directional effects
Now you can fully enjoy ail the Dolby Surround software
available.
SPEAKER LAYOUT EXAMPLE
*{t is recommended that
antimagnetic speakers be
installed near the TV monitor.
FRONT SPEAKERS.
Center peng
¢No output is available from the
CENTER SPEAKER terminals
when sources are played back
in the HALL or STADIUM
mode.
*The center speaker is not
required if you have selected
the PHANTOM mode with the
CENTER MODE key
The rear speakers are not
required if you have selected “Nt i
DOLBY 3CH LOGIC with the s
MODE key WY 9
REAR SPEAKERS
20
Set the SURROUND key to ON
SURROUND
a
peay
Press the MODE key to select the Surround mode: DOLBY
PRO-LOGIC SURROUND, DOLBY 3CH LOGIC, HALL or
STADIUM.
4
* DOLBY PRO-LOGIC SURROUND
Select this mode when you use video software with the
DO (reir suaroone] mark.
BRO losie
* DOLBY 3CH LOGIC
Select this mode when you use video software with the
DO (botsv sunasins) mark with the rear speakers unconnected.
Ses: (er oar
:
:
:
For ordinary stereo sources use HALL or STADIUM
° HALL
— This mode produces the expanding surround sound
effect such as you would experience in a music hall.
¢ STADIUM
— This mode provides the powerful dynamic surround
sound effect of stadium music
Each time the MODE key is pressed, the Surround mode
changes as follows:
DOLBY PRO-LOGIC SURROUND ® DOLBY 3CH LOGIC >
HALL B® STADIUM P (back to the beginning)
<_REARLEVEL_>
3. Press the CENTER MODE key to select the center channel mode
when DOLBY PRO-LOGIC SURROUND is selected.
CENTER MODE Test
There are four center channel modes:
© PHANTOM: ped
Fane
Select this mode when not using the center speaker.
— Center channel signals are distributed between the front left and right
speakers with an equal level
¢ NORMAL:
Select this mode when using a compact speaker (which has
difficulty reproducing low frequencies) to reproduce center channel
signals.
— Center channel signals are reproduced through the center speaker, with
low frequencies being cut off
— Low-frequency center channel signais are reproduced from the front
left and right speakers
© WIDE:
Select this mode when using a speaker similar to the front speak-
ers to reproduce center channel signais.
— Center channel signals are reproduced reproduced through the center
speaker as they are.
* OFF:
The CENTER channel output can be set to off
Sa Sy Ce Fea |
<CENTER LEVEL?
CENTER MODE _TEST
Each time the CENTER MODE key is pressed, the center channel
mode changes as follows
PHANTOM PB NORMAL ® WIDE P OFF P (back to the
beginning)
4. Playback the source.
Notes:
¢ The input signal balance is adjusted to be equal automatically by
the Auto-Input Balance circuit incorporated in the receiver.
© Playing back with the center channel mode set to ‘‘OFF’' enables
you to check the left and right balance of the signals input to the
receiver.
« Even better surround sound effect can be enjoyed by making the
adjustment described on the next page.
DOLBY PRO-LOGIC SURROUND Oat emo]
FRO. coaré
¢ Manufactured under license from Dolby Laboratories Licens-
ing Corporation. Additionally licensed under one or more of the
following patents: U.S. Numbers 3,632,886, 3,746,792 and
3,959,590; Canadian Numbers 1,004,603 and 1,037,877
“DOLBY” and double D symbo! O0 are trademarks of Dolby
Laboratories Licensing Corporation.
