Page #10 background imageLoading...
Page #10 background image
‘AMP_ +/-B’ switch regulator-1a
The CEMF current (via D1107/8) loop
after Q1101/1102 switch off.
IC101
+B
AMP_+B
-B
AMP_-B
-B +12V
+12V
V. feedback
V.out_det.
POWER SUPPLY 3/5
