1-2 (No.MB364)
SPECIFICATION
* Corresponding to Linear PCM, Dolby Digital, and DTS (with sampling frequency -32 kHz, 44.1 kHz, 48 kHz).
Designs and specifications are subject to change without notice.
Amplifier
Output Power At stereo operation Front channels 100 W per channel, min. RMS, driven into 6
Ω at 40 Hz
to 20 kHz with no more than 0.8% total harmonic distor-
tion.
At surround operation Front channels 100 W per channel, min. RMS, driven into 6
Ω at 1 kHz
with no more than 0.8% total harmonic distortion.
Center channel 100 W, min. RMS, driven into 6
Ω at 1 kHz, with no more
than 0.8% total harmonic distortion.
Surround channels 100 W per channel, min. RMS, driven into 6
Ω at 1 kHz,
with no more than 0.8% total harmonic distortion.
Surround back channels 100 W per channel, min. RMS, driven into 6
Ω at 1 kHz,
with no more than 0.8% total harmonic distortion.
Audio Audio Input Sensitivity/Impedance DVR/DVD, VCR, DBS, TV:270 mV/47 k
Ω
Audio Input (DIGITAL IN)* Coaxial DIGITAL IN 1(DVR/DVD):0.5 V(p-p)/75 Ω
Optical DIGITAL IN 2(DBS):-21 dBm to -15 dBm (660 nm ±30
nm)
USB USB DIGITAL
Audio Output Level DVR, VCR:270 mV
Signal-to-Noise Ratio ('66 IHF/'78 IHF) 80 dB/62 dB
Frequency Response (6
Ω) 20 Hz to 20 kHz (±1 dB)
Bass Boost +4 dB ±1 dB at 100 Hz
Equalization (at DSP operation) Center frequency 63 Hz, 250 Hz, 1 kHz, 4 kHz, 16 kHz
Control range ±8 dB
Video Video Input Sensitivity/Impedance Composite video:DVR/DVD, VCR, DBS 1 V(p-p)/75
Ω
S-video:DVR/DVD, VCR, DBS Y (luminance):1 V(p-p)/75 Ω
C (chrominance, burst):0.286 V(p-p)/75 Ω
Component:DVR/DVD, VCR (DBS) Y (luminance):1 V(p-p)/75 Ω
PB, PR:0.7 V(p-p)/75 Ω
Video Output Level/Impedance Composite video:DVR/DVD, VCR, DBS 1 V(p-p)/75 Ω
S-video:DVR, VCR, MONITOR OUT Y (luminance):1 V(p-p)/75 Ω
C (chrominance, burst):0.286 V(p-p)/75 Ω
Component:MONITOR OUT Y (luminance):1 V(p-p)/75 Ω
PB, PR:0.7 V(p-p)/75 Ω
Synchronization Negative
FM tuner (IHF)
Tuning Range 87.5 MHz to 108.0 MHz
Usable Sensitivity Monaural 12.8 dBf (1.2
µV/75 Ω)
50 dB Quieting Sensitivity Monaural 16.0 dBf (1.7
µV/75 Ω)
Stereo 37.5 dBf (20.5
µV/75 Ω)
Stereo Separation at REC OUT 35 dB at 1 kHz
AM tuner
Tuning Range 530 kHz to 1 710 kHz
General
Power Requirements AC 120 V , 60 Hz
Power Consumption 150 W/200 VA (at operation)
0.9 W (in standby mode)
Dimensions (W
× H × D) 435 mm × 91.5 mm × 360 mm
(17 3/16 inches
× 3 5/8 inches × 14 3/16 inches)
Mass 6.7 kg (14.8 lbs)
