JVC RX-DP10VBK User Manual

RX-DP10VBK/RX-DP10VSL
RX-DP10RSL
3-6
Item
Parts number Parts name Area
A
Parts list (General assembly)
Q'ty
Description
Block No. M1MM
124 LV30225-0C7A
SPACER
1
125 QAU0233-001
TUNER
1
126 E310244-003
FASTNER
1
127 QYSBSGG3008E
T.SCREW
4
PRIMARY
128 QYSBSGG3008E
T.SCREW
4
ANALOG P.SUPPLY
129 LV41603-001A
LEAF SPRING
1
130 QYSDSG3008E
T.SCREW
1
LEAF SPRING
131 QQT0336-001
POWER TRANSF
A
1
T41
132 QYSDSTL4008E
SPECIAL SCREW
4
TRANS.
133 QQT0338-002
POWER TRANSF
A
1
T1
134 QYSDSTL4008E
SPECIAL SCREW
4
TRANS.
135 LV10540-008A
REAR PANEL
C
1
LV10540-014A
REAR PANEL
J
1
136 QYSBSGY3008E
SPECIAL SCREW
8
S.BKT/C.BKT
137 QYSBSGY3008E
SPECIAL SCREW
4
BOTTOM
138 QYSBSGY3008E
SPECIAL SCREW
7
DSP
139 QYSBSGY3008E
SPECIAL SCREW
1
SHIELD
140 QYSBSGY3008E
SPECIAL SCREW
3
AUDIO
141 QYSBSGY3008E
SPECIAL SCREW
4
V-AUDIO
142 QYSBSGY3008E
SPECIAL SCREW
5
C-V
143 QYSBSGY3008E
SPECIAL SCREW
6
S-V
144 QYSBSGY3008E
SPECIAL SCREW
3
COMP-V
145 QYSBSGY3008E
SPECIAL SCREW
2
TUNER
146 QYSBSGY3008E
SPECIAL SCREW
3
DCS
147 QYSBSGY3008E
SPECIAL SCREW
5
SPK
148 E409257-001
GND TERMINAL
1
149 QMPD220-200-JD
POWER CORD
A
1
150 QZW0033-001
STRAIN RELIEF
A
1
151 LV40911-001A
LABEL
1
152 LV10538-004A/S/
TOP COVER
J
1
LV10538-003A/S/
TOP COVER
C
1
153 QYSBSGY3008E
SPECIAL SCREW
3
TOP COVER
154 E406308-004
SPECIAL SCREW
C
8
TOP SL-MODEL
E406308-003
SPECIAL SCREW
J
8
TOP SL-MODEL
155 LV32819-001A
VOL KNOB
C
1
LV32819-002A
VOL KNOB
J
1
156 LV33243-001A
PROTECT SHEET
1
157 LV42405-001A
VOL RING
C
1
LV42405-002A
VOL RING
J
1
158 QUQ412-1619DJ
FFC WIRE
1
FRONT1-MOTHER
159 QUQ412-2019DJ
FFC WIRE
1
FRONT1-MOTHER
160 QUQ412-1513DJ
FFC WIRE
1
TUNER-AUDIO2
161 QUQ412-1605DJ
FFC WIRE
1
VIDEO1-VIDEO2
162 VKZ4001-018
WIRE HOLDER
1
163 VKZ4001-111S
WIRE CLAMP
2
164 LV33163-001A
BARRIER
2
165 QYSBSGG3008E
T.SCREW
3
166 QMF51U1-8R0-J8
FUSE
A
1
F21
