Item
Parts number Parts name Area
A
Parts list (General assembly)
Q'ty
Description
Block No. M1MM
167 QMF51U1-1R0-J8
FUSE
A
1
F41
168 QMF51U1-2R0-J8
FUSE
A
1
F42
169 QMF51U1-2R0-J8
FUSE
A
2
F61,F62
170 E409396-002
CAUTION LABEL
C
1
E409396-001
CAUTION LABEL
J
1
171 QWTJ809-240
GLASS TUBE
1
172 QYSBSG3008E
T.SCREW
1
HS41
173 QYSBSG3008E
T.SCREW
1
HS42
174 QYSBSG3008E
T.SCREW
1
HS61
175 QYSBSG3008E
T.SCREW
1
HS62
176 QYSBSG3008E
T.SCREW
1
HS63
179 LV32827-002A
LED HOLDER
3
D1032-D1034
180 LV42783-001A
EARTH PLATE
1
181 LV30225-0D3A
SPACERW
1
182 LV30225-0D4A
SPACER
1
183 QAU0237-002
RF MODULE UNIT
1
184
185
LV30226-029A
EXO150010H09S11
SPACER
FELT SPACER
1
186 LV30225-074A
SPACER
1
1
