RX-DP10VBK/RX-DP10VSL

RX-DP10RSL

3-8

Item

Parts number Parts name Ar

Electrical parts list (Amp. board)

Remarks

Block No. 01

Item

Parts number Parts name Ar

Remarks

Item

Parts number Parts name Ar

Remarks

C 701 QEZ0538-106Z E CAPACITOR 10MF

C 702 QCS32HJ-101Z C CAPACITOR 100PF 5% 500V

C 703 QCS32HJ-101Z C CAPACITOR 100PF 5% 500V

C 704 QFN31HJ-152Z M CAPACITOR 1500PF 5% 50V

C 705 QCS32HJ-220Z C CAPACITOR 22PF 5% 500V

C 707 QCS32HJ-221Z C CAPACITOR 220PF 5% 500V

C 708 QFN31HJ-472Z M CAPACITOR 4700PF 5% 50V

C 709 QCS32HJ-470Z C CAPACITOR 47PF 5% 500V

C 710 QCS32HJ-470Z C CAPACITOR 47PF 5% 500V

C 711 QEZ0539-476Z E CAPACITOR 47MF

C 712 QEZ0539-476Z E CAPACITOR 47MF

C 715 QCS32HJ-330Z C CAPACITOR 33PF 5% 500V

C 721 NCF21EZ-224X E CAPACITOR

C 731 QEZ0539-476Z E CAPACITOR 47MF

C 735 QFLC1HJ-473Z M CAPACITOR 0.047MF 5% 50V

C 736 QFLC1HJ-473Z M CAPACITOR 0.047MF 5% 50V

C 741 QCS32HJ-100Z C CAPACITOR 10PF 5% 500V

C 742 QEZ0538-226Z E CAPACITOR 22MF

C 745 QEZ0544-338 E CAPACITOR 3300MF

C 746 QEZ0544-338 E CAPACITOR 3300MF

C 751 QEZ0538-106Z E CAPACITOR 10MF

C 752 QCS32HJ-101Z C CAPACITOR 100PF 5% 500V

C 753 QCS32HJ-101Z C CAPACITOR 100PF 5% 500V

C 754 QFN31HJ-152Z M CAPACITOR 1500PF 5% 50V

C 755 QCS32HJ-220Z C CAPACITOR 22PF 5% 500V

C 757 QCS32HJ-221Z C CAPACITOR 220PF 5% 500V

C 758 QFN31HJ-472Z M CAPACITOR 4700PF 5% 50V

C 759 QCS32HJ-470Z C CAPACITOR 47PF 5% 500V

C 760 QCS32HJ-470Z C CAPACITOR 47PF 5% 500V

C 761 QEZ0539-476Z E CAPACITOR 47MF

C 762 QEZ0539-476Z E CAPACITOR 47MF

C 765 QCS32HJ-330Z C CAPACITOR 33PF 5% 500V

C 771 NCF21EZ-224X E CAPACITOR

C 773 QFV72AJ-104Z MF CAPACITOR 0.1MF 5% 100V

C 774 QFV72AJ-104Z MF CAPACITOR 0.1MF 5% 100V

C 775 QFV72AJ-104Z MF CAPACITOR 0.1MF 5% 100V

C 776 QFV72AJ-104Z MF CAPACITOR 0.1MF 5% 100V

C 781 QEZ0539-476Z E CAPACITOR 47MF

C 785 QFLC1HJ-473Z M CAPACITOR 0.047MF 5% 50V

C 786 QFLC1HJ-473Z M CAPACITOR 0.047MF 5% 50V

C 791 QCS32HJ-100Z C CAPACITOR 10PF 5% 500V

C 792 QEZ0538-226Z E CAPACITOR 22MF

C 795 QEZ0544-338 E CAPACITOR 3300MF

C 796 QEZ0544-338 E CAPACITOR 3300MF

C 801 QEZ0538-106Z E CAPACITOR 10MF

C 802 QCS32HJ-101Z C CAPACITOR 100PF 5% 500V

C 803 QCS32HJ-101Z C CAPACITOR 100PF 5% 500V

C 804 QFN31HJ-152Z M CAPACITOR 1500PF 5% 50V

C 805 QCS32HJ-220Z C CAPACITOR 22PF 5% 500V

C 807 QCS32HJ-221Z C CAPACITOR 220PF 5% 500V

C 808 QFN31HJ-472Z M CAPACITOR 4700PF 5% 50V

C 809 QCS32HJ-470Z C CAPACITOR 47PF 5% 500V

C 810 QCS32HJ-470Z C CAPACITOR 47PF 5% 500V

C 811 QEZ0539-476Z E CAPACITOR 47MF

C 812 QEZ0539-476Z E CAPACITOR 47MF

C 815 QCS32HJ-330Z C CAPACITOR 33PF 5% 500V

C 821 NCF21EZ-224X E CAPACITOR

C 831 QEZ0539-476Z E CAPACITOR 47MF

C 835 QFLC1HJ-473Z M CAPACITOR 0.047MF 5% 50V

C 836 QFLC1HJ-473Z M CAPACITOR 0.047MF 5% 50V

C 841 QCS32HJ-100Z C CAPACITOR 10PF 5% 500V

C 842 QEZ0538-226Z E CAPACITOR 22MF

C 895 QEZ0544-338 E CAPACITOR 3300MF

C 896 QEZ0544-338 E CAPACITOR 3300MF

CN711 QGB2510K2-07 CONNECTOR

CN712 QGB2012K1-06 CONNECTOR

CN713 QGB2012K1-06 CONNECTOR

CN721 QGB2510J1-07 CONNECTOR

CN722 QGB2012J1-06 CONNECTOR

CN723 QGB2012J1-06 CONNECTOR

CN738 QGA2501C1-03 3P CONNECTOR

CN741 QGA3901C1-10 10P CONNECTOR

CN742 QGA3901C1-04 4P CONNECTOR

CN743 QGA2001C1-10 10P PLUG ASSY

CN751 QGB2510K2-06 CONNECTOR

CN752 QGB2012K1-06 CONNECTOR

CN753 QGB2012K1-06 CONNECTOR

CN761 QGB2510J1-06 CONNECTOR

CN762 QGB2012J1-06 CONNECTOR

CN763 QGB2012J1-06 CONNECTOR

CN771 QGB2510K2-05 CONNECTOR

CN772 QGB2012K1-06 CONNECTOR

CN773 QGB2012K1-06 CONNECTOR

CN781 QGB2510J1-05 CONNECTOR

CN782 QGB2012J1-06 CONNECTOR

CN783 QGB2012J1-06 CONNECTOR

CN811 QGB2510K2-06 CONNECTOR

CN812 QGB2012K1-06 CONNECTOR

CN813 QGB2012K1-06 CONNECTOR

CN821 QGB2510J1-06 CONNECTOR

CN822 QGB2012J1-06 CONNECTOR

CN823 QGB2012J1-06 CONNECTOR

C1601 QEZ0538-106Z E CAPACITOR 10MF

C1602 QCS32HJ-101Z C CAPACITOR 100PF 5% 500V

C1603 QCS32HJ-101Z C CAPACITOR 100PF 5% 500V

C1604 QFN31HJ-152Z M CAPACITOR 1500PF 5% 50V

C1605 QCS32HJ-220Z C CAPACITOR 22PF 5% 500V

C1607 QCS32HJ-221Z C CAPACITOR 220PF 5% 500V

C1608 QFN31HJ-472Z M CAPACITOR 4700PF 5% 50V

C1609 QCS32HJ-470Z C CAPACITOR 47PF 5% 500V

C1610 QCS32HJ-470Z C CAPACITOR 47PF 5% 500V

C1611 QEZ0539-476Z E CAPACITOR 47MF

C1612 QEZ0539-476Z E CAPACITOR 47MF

C1615 QCS32HJ-330Z C CAPACITOR 33PF 5% 500V

C1621 NCF21EZ-224X E CAPACITOR

C1631 QEZ0539-476Z E CAPACITOR 47MF

C1635 QFLC1HJ-473Z M CAPACITOR 0.047MF 5% 50V

C1636 QFLC1HJ-473Z M CAPACITOR 0.047MF 5% 50V

C1641 QCS32HJ-100Z C CAPACITOR 10PF 5% 500V

C1642 QEZ0538-226Z E CAPACITOR 22MF

C1645 QEZ0544-338 E CAPACITOR 3300MF

C1646 QEZ0544-338 E CAPACITOR 3300MF

C1651 QEZ0538-106Z E CAPACITOR 10MF

C1652 QCS32HJ-101Z C CAPACITOR 100PF 5% 500V

C1653 QCS32HJ-101Z C CAPACITOR 100PF 5% 500V

C1654 QFN31HJ-152Z M CAPACITOR 1500PF 5% 50V

C1655 QCS32HJ-220Z C CAPACITOR 22PF 5% 500V

C1657 QCS32HJ-221Z C CAPACITOR 220PF 5% 500V

C1658 QFN31HJ-472Z M CAPACITOR 4700PF 5% 50V

C1659 QCS32HJ-470Z C CAPACITOR 47PF 5% 500V

C1660 QCS32HJ-470Z C CAPACITOR 47PF 5% 500V

C1661 QEZ0539-476Z E CAPACITOR 47MF

C1662 QEZ0539-476Z E CAPACITOR 47MF

C1665 QCS32HJ-330Z C CAPACITOR 33PF 5% 500V

C1671 NCF21EZ-224X E CAPACITOR

C1685 QFLC1HJ-473Z M CAPACITOR 0.047MF 5% 50V
