RX-DP10VBK/BX-DP10VSL

RX-DP10RSL

3-15

Item

Parts number Parts name Ar

Electrical parts list

(Audio/video input & outpat board)

Remarks

Block No. 02

C 201 NCB31HK-331X C CAPACITOR

C 202 NCB31HK-331X C CAPACITOR

C 203 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V

C 204 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V

C 205 NCS31HJ-101X C CAPACITOR

C 206 NCS31HJ-101X C CAPACITOR

C 207 QFN31HJ-472Z M CAPACITOR 4700PF 5% 50V

C 208 QFN31HJ-472Z M CAPACITOR 4700PF 5% 50V

C 209 QFN31HJ-153Z M CAPACITOR 0.015MF 5% 50V

C 210 QFN31HJ-153Z M CAPACITOR 0.015MF 5% 50V

C 211 QCS31HJ-331Z C CAPACITOR 330PF 5% 50V

C 212 QCS31HJ-331Z C CAPACITOR 330PF 5% 50V

C 213 QFN31HJ-272Z M CAPACITOR 2700PF 5% 50V

C 214 QFN31HJ-272Z M CAPACITOR 2700PF 5% 50V

C 215 NCS31HJ-101X C CAPACITOR

C 216 NCS31HJ-101X C CAPACITOR

C 217 QETN1AM-227Z E CAPACITOR 220MF 20% 10V

C 218 QETN1AM-227Z E CAPACITOR 220MF 20% 10V

C 219 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V

C 220 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V

C 221 QFN31HJ-102Z M CAPACITOR 1000PF 5% 50V

C 222 QFN31HJ-102Z M CAPACITOR 1000PF 5% 50V

C 223 QETN1EM-476Z E CAPACITOR 47MF 20% 25V

C 224 QETN1EM-476Z E CAPACITOR 47MF 20% 25V

C 225 NCB31HK-223X C CAPACITOR

C 226 NCB31HK-223X C CAPACITOR

C 231 QETN1EM-226Z E CAPACITOR 22MF 20% 25V

C 232 QETN1EM-226Z E CAPACITOR 22MF 20% 25V

C 233 NCB31HK-223X C CAPACITOR

C 234 NCB31HK-223X C CAPACITOR

C 235 NCB31HK-561X C CAPACITOR

C 241 QTE1H46-106Z E CAPACITOR

C 242 QTE1H46-106Z E CAPACITOR

C 243 QTE1H46-106Z E CAPACITOR

C 244 QTE1H46-106Z E CAPACITOR

C 245 QETN1EM-476Z E CAPACITOR 47MF 20% 25V

C 246 QETN1EM-476Z E CAPACITOR 47MF 20% 25V

C 247 NCB31HK-223X C CAPACITOR

C 248 NCB31HK-223X C CAPACITOR

C 271 QETN1EM-226Z E CAPACITOR 22MF 20% 25V

C 272 QETN1EM-226Z E CAPACITOR 22MF 20% 25V

C 273 NCB31HK-223X C CAPACITOR

C 274 NCB31HK-223X C CAPACITOR

C 275 NCB31HK-561X C CAPACITOR

C 276 QETN1EM-226Z E CAPACITOR 22MF 20% 25V

C 277 QETN1EM-226Z E CAPACITOR 22MF 20% 25V

C 278 NCB31HK-223X C CAPACITOR

C 279 NCB31HK-223X C CAPACITOR

C 280 NCB31HK-561X C CAPACITOR

C 281 QETN1EM-226Z E CAPACITOR 22MF 20% 25V

C 282 QETN1EM-226Z E CAPACITOR 22MF 20% 25V

C 283 NCB31HK-223X C CAPACITOR

C 284 NCB31HK-223X C CAPACITOR

C 285 NCB31HK-561X C CAPACITOR

C 301 QETN1HM-226Z E CAPACITOR 22MF 20% 50V

C 311 NCS31HJ-221X C CAPACITOR

C 312 NCS31HJ-221X C CAPACITOR

C 313 NCS31HJ-221X C CAPACITOR

C 314 NCS31HJ-221X C CAPACITOR

C 315 NCS31HJ-221X C CAPACITOR

C 316 NCS31HJ-221X C CAPACITOR

C 341 QETN1EM-226Z E CAPACITOR 22MF 20% 25V

C 342 QETN1EM-226Z E CAPACITOR 22MF 20% 25V

C 343 NCB31HK-223X C CAPACITOR

C 344 NCB31HK-223X C CAPACITOR

C 345 NCB31HK-561X C CAPACITOR

C 363 QETN1HM-226Z E CAPACITOR 22MF 20% 50V

C 365 QETN1HM-226Z E CAPACITOR 22MF 20% 50V

C 369 QETN1HM-226Z E CAPACITOR 22MF 20% 50V

C 401 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V

C 402 QETN0JM-477Z E CAPACITOR 470MF 20% 6.3V

C 403 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V

C 404 QETN0JM-477Z E CAPACITOR 470MF 20% 6.3V

C 405 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V

C 406 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V

C 407 QETN0JM-477Z E CAPACITOR 470MF 20% 6.3V

C 408 QETN1EM-476Z E CAPACITOR 47MF 20% 25V

C 409 NCB31HK-103X C CAPACITOR

C 410 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V

C 411 QETN1HM-107Z E CAPACITOR 100MF 20% 50V

C 412 NCF21CZ-225X C CAPACITOR

C 413 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V

C 414 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V

C 415 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V

C 416 NCF31HZ-473X C CAPACITOR

C 417 QETN1AM-477Z E CAPACITOR 470MF 20% 10V

C 418 NCB31HK-103X C CAPACITOR

C 419 NCS31HJ-150X C CAPACITOR

C 420 NCS31HJ-100X C CAPACITOR

C 421 NCS31HJ-470X C CAPACITOR

C 422 NCS31HJ-270X C CAPACITOR

C 423 NCB31HK-102X C CAPACITOR

C 424 NCS31HJ-271X C CAPACITOR

C 425 NCS31HJ-121X C CAPACITOR

C 426 NCS31HJ-470X C CAPACITOR

C 427 NCS31HJ-470X C CAPACITOR

C 428 NCS31HJ-470X C CAPACITOR

C 431 NCF31HZ-473X C CAPACITOR

C 432 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V

C 433 NCF31HZ-473X C CAPACITOR

C 434 QETN0JM-477Z E CAPACITOR 470MF 20% 6.3V

C 435 NCF31HZ-473X C CAPACITOR

C 436 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V

C 437 NCF31HZ-473X C CAPACITOR

C 438 QETN0JM-477Z E CAPACITOR 470MF 20% 6.3V

C 439 NCF31HZ-473X C CAPACITOR

C 440 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V

C 441 NCF31HZ-473X C CAPACITOR

C 442 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V

C 443 NCF31HZ-473X C CAPACITOR

C 444 QETN0JM-477Z E CAPACITOR 470MF 20% 6.3V

C 445 NCF31HZ-473X C CAPACITOR

C 446 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V

C 447 QETN1EM-476Z E CAPACITOR 47MF 20% 25V

C 448 QETN1EM-476Z E CAPACITOR 47MF 20% 25V

C 449 NCB31HK-103X C CAPACITOR

C 450 NCB31HK-103X C CAPACITOR

C 451 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V

C 452 NCF31HZ-473X C CAPACITOR

C 453 NCS31HJ-470X C CAPACITOR

C 454 NCS31HJ-470X C CAPACITOR

C 455 NCS31HJ-470X C CAPACITOR

C 456 NCS31HJ-470X C CAPACITOR

C 457 NCS31HJ-101X C CAPACITOR

C 458 NCS31HJ-101X C CAPACITOR

C 461 NCF31HZ-473X C CAPACITOR
