RX-DP10VBK/RX-DP10VSL
RX-DP10RSL
3-16
Item
Parts number Parts name Ar
e
a
Electrical parts list
(Audio/video input & outpat board)
Remarks
Block No. 02
A
Item
Parts number Parts name Ar
e
a
Remarks
A
C 462 NCB31HK-103X C CAPACITOR
C 463 NCF31HZ-473X C CAPACITOR
C 464 NCB31HK-103X C CAPACITOR
C 465 NCF31HZ-473X C CAPACITOR
C 466 NCB31HK-103X C CAPACITOR
C 467 NCF31HZ-473X C CAPACITOR
C 468 NCB31HK-103X C CAPACITOR
C 469 NCB31HK-103X C CAPACITOR
C 470 QETN1EM-476Z E CAPACITOR 47MF 20% 25V
C 471 NCB31HK-103X C CAPACITOR
CN203 QGA2001F1-15 15P PLUG ASSY
CN205 QGA2001F1-09 9P SOCKET
CN206 QGB2510K1-04 CONNECTOR
CN207 QGA2501F1-03 CONNECTOR
CN208 QGA2001F1-08 CONNECTOR
CN218 QGA2001F1-03 CONNECTOR
CN221 QGB2510K1-20 B TO B CONNE
CN223 QGA2001F1-11 11P CN RIG
CN224 QGA2001F1-07 CONNECTOR
CN234 QGA2001F1-06 6P PLUG ASSY
CN321 QGB1214K1-20S CONNECTOR
CN323 QGF1205F1-15 CONNECTOR
CN324 QGA2001F1-09 9P SOCKET
CN325 QGB2510K2-07 CONNECTOR
CN401 QGB1214K1-16S CONNECTOR
CN402 QGF1205F1-16 CONNECTOR
CN431 QGB2510K2-15 CONNECTOR
CN432 QGF1205F1-16 CONNECTOR
C2001 QETN1EM-226Z E CAPACITOR 22MF 20% 25V
C2002 QETN1EM-226Z E CAPACITOR 22MF 20% 25V
C2003 NCB31HK-223X C CAPACITOR
C2004 NCB31HK-223X C CAPACITOR
C2005 NCB31HK-561X C CAPACITOR
C2011 QETN1HM-106Z E CAPACITOR 10MF 20% 50V
C2012 QETN1HM-106Z E CAPACITOR 10MF 20% 50V
C2013 QETN1HM-106Z E CAPACITOR 10MF 20% 50V
C2014 QETN1HM-106Z E CAPACITOR 10MF 20% 50V
C2015 QETN1EM-476Z E CAPACITOR 47MF 20% 25V
C2016 QETN1EM-476Z E CAPACITOR 47MF 20% 25V
C2017 NCB31HK-223X C CAPACITOR
C2018 NCB31HK-223X C CAPACITOR
C2025 NCB31HK-223X C CAPACITOR
C2026 NCB31HK-223X C CAPACITOR
C2028 QETN1HM-226Z E CAPACITOR 22MF 20% 50V
C2031 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C2032 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C2033 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C2034 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C2035 QETN1EM-227Z E CAPACITOR 220MF 20% 25V
C2036 QETN1EM-227Z E CAPACITOR 220MF 20% 25V
C2037 NCB31HK-223X C CAPACITOR
C2038 NCB31HK-223X C CAPACITOR
C2042 QETN1HM-226Z E CAPACITOR 22MF 20% 50V
C2051 QTE1H46-475Z E CAPACITOR
C2052 QTE1H46-475Z E CAPACITOR
C2053 QTE1H46-475Z E CAPACITOR
C2054 QTE1H46-475Z E CAPACITOR
C2055 QETN1EM-227Z E CAPACITOR 220MF 20% 25V
C2056 QETN1EM-227Z E CAPACITOR 220MF 20% 25V
C2057 NCB31HK-223X C CAPACITOR
C2058 NCB31HK-223X C CAPACITOR
C2059 QTE1H46-475Z E CAPACITOR
C2060 QTE1H46-475Z E CAPACITOR
C2061 QTE1H46-475Z E CAPACITOR
C2062 QTE1H46-475Z E CAPACITOR
C2063 QETN1EM-227Z E CAPACITOR 220MF 20% 25V
C2064 QETN1EM-227Z E CAPACITOR 220MF 20% 25V
C2065 NCB31HK-223X C CAPACITOR
C2066 NCB31HK-223X C CAPACITOR
C2067 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C2068 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C2069 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C2070 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C2071 QETN1EM-227Z E CAPACITOR 220MF 20% 25V
C2072 QETN1EM-227Z E CAPACITOR 220MF 20% 25V
C2073 NCB31HK-223X C CAPACITOR
C2074 NCB31HK-223X C CAPACITOR
C2075 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C2076 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C2077 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C2078 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C2079 QETN1EM-227Z E CAPACITOR 220MF 20% 25V
C2080 QETN1EM-227Z E CAPACITOR 220MF 20% 25V
C2081 NCB31HK-223X C CAPACITOR
C2082 NCB31HK-223X C CAPACITOR
C2101 QETN1EM-226Z E CAPACITOR 22MF 20% 25V
C2102 QETN1EM-226Z E CAPACITOR 22MF 20% 25V
C2103 NCB31HK-223X C CAPACITOR
C2104 NCB31HK-223X C CAPACITOR
C2105 NCB31HK-561X C CAPACITOR
C2111 QETN1EM-106Z E CAPACITOR 10MF 20% 25V
C2112 QETN1EM-106Z E CAPACITOR 10MF 20% 25V
C2113 QETN1EM-106Z E CAPACITOR 10MF 20% 25V
C2114 QETN1EM-106Z E CAPACITOR 10MF 20% 25V
C2115 QETN1EM-106Z E CAPACITOR 10MF 20% 25V
C2116 QETN1EM-106Z E CAPACITOR 10MF 20% 25V
C2203 NCB31HK-223X C CAPACITOR
C2204 NCB31HK-223X C CAPACITOR
C2207 QTE1H46-475Z E CAPACITOR
C2208 QTE1H46-475Z E CAPACITOR
C2212 NCB31HK-223X C CAPACITOR
C2213 NCB31HK-223X C CAPACITOR
C2221 NCB31HK-223X C CAPACITOR
C2222 NCB31HK-223X C CAPACITOR
C2230 NCB31HK-223X C CAPACITOR
C2231 NCB31HK-223X C CAPACITOR
C2253 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C2254 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C2255 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C2256 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C2257 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C2258 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C2259 NCS31HJ-330X C CAPACITOR
C2260 NCS31HJ-330X C CAPACITOR
C2265 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C2266 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C2267 QETN1EM-227Z E CAPACITOR 220MF 20% 25V
C2268 QETN1EM-227Z E CAPACITOR 220MF 20% 25V
C2269 NCB31HK-223X C CAPACITOR
C2270 NCB31HK-223X C CAPACITOR
C2273 NCB31HK-223X C CAPACITOR
C2274 NCB31HK-223X C CAPACITOR
C2301 NCB31HK-562X C CAPACITOR
C2302 NCB31HK-562X C CAPACITOR
C2319 NCS31HJ-101X C CAPACITOR
C2320 NCS31HJ-101X C CAPACITOR
