JVC RX-DP10VBK User Manual

RX-DP10VBK/BX-DP10VSL
RX-DP10RSL
3-17
Item
Parts number Parts name Ar
e
a
Electrical parts list
(Audio/video input & outpat board)
Remarks
Block No. 02
A
Item
Parts number Parts name Ar
e
a
Remarks
A
C2401 QTE1H46-106Z E CAPACITOR
C2402 QTE1H46-106Z E CAPACITOR
C2403 QTE1H46-106Z E CAPACITOR
C2404 QTE1H46-106Z E CAPACITOR
C2405 QETN1EM-476Z E CAPACITOR 47MF 20% 25V
C2406 QETN1EM-476Z E CAPACITOR 47MF 20% 25V
C2407 NCB31HK-223X C CAPACITOR
C2408 NCB31HK-223X C CAPACITOR
C2411 QETN1HM-106Z E CAPACITOR 10MF 20% 50V
C2412 QETN1HM-106Z E CAPACITOR 10MF 20% 50V
C2413 QETN1HM-106Z E CAPACITOR 10MF 20% 50V
C2414 QETN1HM-106Z E CAPACITOR 10MF 20% 50V
C2415 QETN1EM-476Z E CAPACITOR 47MF 20% 25V
C2416 QETN1EM-476Z E CAPACITOR 47MF 20% 25V
C2417 NCB31HK-223X C CAPACITOR
C2418 NCB31HK-223X C CAPACITOR
C2421 QETN1HM-106Z E CAPACITOR 10MF 20% 50V
C2422 QETN1HM-106Z E CAPACITOR 10MF 20% 50V
C2423 QETN1HM-106Z E CAPACITOR 10MF 20% 50V
C2424 QETN1HM-106Z E CAPACITOR 10MF 20% 50V
C2425 QETN1EM-476Z E CAPACITOR 47MF 20% 25V
C2426 QETN1EM-476Z E CAPACITOR 47MF 20% 25V
C2427 NCB31HK-223X C CAPACITOR
C2428 NCB31HK-223X C CAPACITOR
C2501 NCF21CZ-225X C CAPACITOR
C2502 NCF21CZ-225X C CAPACITOR
C2503 NCF21CZ-105X C CAPACITOR
C2504 NCF21CZ-105X C CAPACITOR
C4001 QETN0JM-477Z E CAPACITOR 470MF 20% 6.3V
C4002 QETN1EM-476Z E CAPACITOR 47MF 20% 25V
C4003 NCB31HK-103X C CAPACITOR
C4004 QETN1HM-107Z E CAPACITOR 100MF 20% 50V
C4005 NCF21CZ-225X C CAPACITOR
C4006 NCS31HJ-470X C CAPACITOR
C4031 NCF31HZ-473X C CAPACITOR
C4032 QETN0JM-477Z E CAPACITOR 470MF 20% 6.3V
C4033 QETN1EM-476Z E CAPACITOR 47MF 20% 25V
C4034 QETN1EM-476Z E CAPACITOR 47MF 20% 25V
C4035 NCB31HK-103X C CAPACITOR
C4036 NCB31HK-103X C CAPACITOR
C4037 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C4038 NCF31HZ-473X C CAPACITOR
C4039 NCS31HJ-101X C CAPACITOR
C4040 NCS31HJ-101X C CAPACITOR
D 240 1SS355-X DIODE
D 351 1SS355-X DIODE
D 401 1SS133-T2 SI DIODE
D 402 1SS133-T2 SI DIODE
D2041 1SS133-T2 SI DIODE
D2042 1SS133-T2 SI DIODE
D2111 1SS355-X DIODE
D2121 1SS355-X DIODE
D2122 1SS355-X DIODE
D2123 MTZJ5.1C-T2 ZENER DIODE
D2311 1SS133-T2 SI DIODE
D2501 1SS355-X DIODE
D2502 1SS355-X DIODE
D2503 1SS355-X DIODE
D2504 1SS355-X DIODE
D2505 1SS355-X DIODE
D2506 1SS355-X DIODE
D2507 1SS355-X DIODE
D2508 1SS355-X DIODE
FL301 QQR0590-001 FILTER
FL302 QQR0590-001 FILTER
IC201 NJM4580E-W IC
IC202 TC9164AF-X IC
IC203 TC9164AF-X IC
IC204 NJM4580E-W IC
IC211 TC9162AF-X IC
IC212 TC9162AF-X IC
IC213 TC9162AF-X IC
IC221 TC9459F-X IC
IC222 TC9459F-X IC
IC223 TC9459F-X IC
IC224 TC9459F-X IC
IC241 NJM4580E-W IC
IC242 NJM4580E-W IC
IC251 NJM4580E-W IC
IC252 NJM4580E-W IC
IC253 NJM4580E-W IC
IC254 NJM4580E-W IC
IC261 NJM4580E-W IC
IC262 TC9459F-X IC
IC263 NJM4580E-W IC
IC271 NJM4580E-W IC
IC272 NJM4580E-W IC
IC273 NJM4580E-W IC
IC281 NJM4580E-W IC
IC282 NJM2903M-XE IC
IC283 NJM78L05A-T IC
IC321 TC9163AF-X IC
IC322 TC9163AF-X IC
IC381 BA15218N IC
IC382 BA15218N IC
IC401 BA7625 IC
IC402 NJM2285V-W IC
IC403 MB90088PF-131 IC
IC431 BA7625 IC
IC432 BA7626 IC
IC451 BA7625 IC
IC452 NJM2285V-W IC
IC461 BU4051BC IC
IC471 BA7625 IC
IC472 BA7626 IC
J 201 QNN0392-001 PIN JACK
J 202 QNN0392-001 PIN JACK
J 203 QNN0396-001 PIN JACK
J 321 QNN0392-001 PIN JACK
J 322 QNN0393-001 PIN JACK
J 323 QNN0396-001 PIN JACK
J 324 QNN0394-001 PIN JACK
J 401 QNN0402-001 PIN JACK
J 402 QNN0403-001 PIN JACK
J 403 QNN0403-001 PIN JACK
J 431 QND0090-001 S JACK
J 432 QND0029-001 DIN CONNECTOR
J 433 QND0029-001 DIN CONNECTOR
J 434 QND0089-001 S JACK
J4001 QNN0405-001 PIN JACK
J4002 QNN0407-001 PIN JACK
J4031 QND0027-001 DIN CONNECTOR
J4032 QNN0406-001 PIN JACK
L 321 QQL231K-121Y INDUCTOR
L 322 QQL231K-121Y INDUCTOR
L 401 QQL231K-220Y INDUCTOR
