JVC RX-DP10VBK User Manual

RX-DP10VBK/RX-DP10VSL
RX-DP10RSL
3-18
Item
Parts number Parts name Ar
e
a
Electrical parts list
(Audio/video input & outpat board)
Remarks
Block No. 02
A
Item
Parts number Parts name Ar
e
a
Remarks
A
Q
201 KRA104M-T D TRANSISTOR
Q
211 2SC3576-JVC-T TRANSISTOR
Q
212 2SC3576-JVC-T TRANSISTOR
Q
213 2SC3576-JVC-T TRANSISTOR
Q
214 2SC3576-JVC-T TRANSISTOR
Q
215 2SC3576-JVC-T TRANSISTOR
Q
216 2SC3576-JVC-T TRANSISTOR
Q
217 2SC3576-JVC-T TRANSISTOR
Q
218 2SC3576-JVC-T TRANSISTOR
Q
219 2SC3576-JVC-T TRANSISTOR
Q
240 KRC105M-T D TRANSISTOR
Q
323 2SC3576-JVC-T TRANSISTOR
Q
324 2SC3576-JVC-T TRANSISTOR
Q
325 2SC3576-JVC-T TRANSISTOR
Q
329 2SC3576-JVC-T TRANSISTOR
Q
330 2SC3576-JVC-T TRANSISTOR
Q
332 DTC114YKA-X CHIP D TRANSISTOR
Q
334 DTC114YKA-X CHIP D TRANSISTOR
Q
342 DTA114YKA-X TRANSISTOR
Q
343 DTA114YKA-X TRANSISTOR
Q
345 DTA114YKA-X TRANSISTOR
Q
351 KRC105M-T D TRANSISTOR
Q
401 KTA1267/YG/-T TRANSISTOR
Q
402 KTA1267/YG/-T TRANSISTOR
Q
403 KRC110M-T TRANSISTOR
Q
404 KRC107M-T D TRANSISTOR
Q
405 KTA1267/YG/-T TRANSISTOR
Q
406 KTA1267/YG/-T TRANSISTOR
Q
407 KTA1267/YG/-T TRANSISTOR
Q
408 KTA1267/YG/-T TRANSISTOR
Q
431 KTA1267/YG/-T TRANSISTOR
Q
432 KTA1267/YG/-T TRANSISTOR
Q
433 KTA1267/YG/-T TRANSISTOR
Q
434 KTA1267/YG/-T TRANSISTOR
Q
461 DTC114EKA-X TRANSISTOR
Q
462 DTC114EKA-X TRANSISTOR
Q
463 DTC114EKA-X TRANSISTOR
Q
464 KTC3199/GL/-T TRANSISTOR
Q
465 KTC3199/GL/-T TRANSISTOR
Q
466 KTC3199/GL/-T TRANSISTOR
Q
467 KTA1267/YG/-T TRANSISTOR
Q
2011 2SC3576-JVC-T TRANSISTOR
Q
2012 2SC3576-JVC-T TRANSISTOR
Q
2013 KRA104M-T D TRANSISTOR
Q
2041 2SC3576-JVC-T TRANSISTOR
Q
2042 2SC3576-JVC-T TRANSISTOR
Q
2043 KRA104M-T D TRANSISTOR
Q
2111 KTC3199/GL/-T TRANSISTOR
Q
2112 DTC144ESA-T D TRANSISTOR
Q
2501 KTC3199/GL/-T TRANSISTOR
Q
4001 KTA1267/YG/-T TRANSISTOR
Q
4002 KTA1267/YG/-T TRANSISTOR
Q
4003 KTA1267/YG/-T TRANSISTOR
R 201 NRSA63J-222X MG RESISTOR
R 202 NRSA63J-222X MG RESISTOR
R 203 NRSA63J-473X MG RESISTOR
R 204 NRSA63J-473X MG RESISTOR
R 205 NRSA63J-221X MG RESISTOR
R 206 NRSA63J-221X MG RESISTOR
R 207 NRSA63J-153X MG RESISTOR
R 208 NRSA63J-153X MG RESISTOR
R 209 NRSA63J-184X MG RESISTOR
R 210 NRSA63J-184X MG RESISTOR
R 211 NRSA63J-103X MG RESISTOR
R 212 NRSA63J-103X MG RESISTOR
R 213 NRSA63J-104X MG RESISTOR
R 214 NRSA63J-104X MG RESISTOR
R 215 NRSA63J-101X MG RESISTOR
R 216 NRSA63J-101X MG RESISTOR
R 217 QRJ146J-331X UNF C RESISTOR
A
330 5% 1/4W
R 218 QRJ146J-331X UNF C RESISTOR
A
330 5% 1/4W
R 231 QRZ9005-680X F RESISTOR
A
68 1/4W
R 232 QRZ9005-680X F RESISTOR
A
68 1/4W
R 237 QRZ9005-680X F RESISTOR
A
68 1/4W
R 238 QRZ9005-680X F RESISTOR
A
68 1/4W
R 240 QRZ9005-331X F RESISTOR
A
330 1/4W
R 241 NRSA63J-104X MG RESISTOR
R 242 NRSA63J-104X MG RESISTOR
R 243 NRSA63J-104X MG RESISTOR
R 244 NRSA63J-104X MG RESISTOR
R 245 NRSA63J-104X MG RESISTOR
R 246 NRSA63J-104X MG RESISTOR
R 247 QRA14CF-1001Y MF RESISTOR 10 1/4W
R 248 QRA14CF-1001Y MF RESISTOR 10 1/4W
R 249 QRA14CF-1001Y MF RESISTOR 10 1/4W
R 250 QRA14CF-1001Y MF RESISTOR 10 1/4W
R 251 NRSA63J-471X MG RESISTOR
R 252 NRSA63J-471X MG RESISTOR
R 253 NRSA63J-471X MG RESISTOR
R 254 NRSA63J-471X MG RESISTOR
R 255 NRSA63J-471X MG RESISTOR
R 256 NRSA63J-471X MG RESISTOR
R 257 NRSA63J-471X MG RESISTOR
R 258 NRSA63J-471X MG RESISTOR
R 259 NRSA63J-471X MG RESISTOR
R 260 NRSA63J-471X MG RESISTOR
R 261 NRSA63J-561X MG RESISTOR
R 262 NRSA63J-561X MG RESISTOR
R 263 NRSA63J-561X MG RESISTOR
R 264 NRSA63J-561X MG RESISTOR
R 265 NRSA63J-561X MG RESISTOR
R 266 NRSA63J-561X MG RESISTOR
R 267 QRZ9005-680X F RESISTOR
A
68 1/4W
R 268 QRZ9005-680X F RESISTOR
A
68 1/4W
R 269 QRZ9005-680X F RESISTOR
A
68 1/4W
R 270 QRZ9005-680X F RESISTOR
A
68 1/4W
R 281 QRZ9005-680X F RESISTOR
A
68 1/4W
R 282 QRZ9005-680X F RESISTOR
A
68 1/4W
R 291 QRA14CF-1001Y MF RESISTOR 10 1/4W
R 292 QRA14CF-1001Y MF RESISTOR 10 1/4W
R 293 NRSA63J-103X MG RESISTOR
R 294 NRSA63J-103X MG RESISTOR
R 295 QRA14CF-1001Y MF RESISTOR 10 1/4W
R 296 QRA14CF-1001Y MF RESISTOR 10 1/4W
R 297 NRSA63J-103X MG RESISTOR
R 298 NRSA63J-103X MG RESISTOR
R 299 QRA14CF-1001Y MF RESISTOR 10 1/4W
R 300 QRA14CF-1001Y MF RESISTOR 10 1/4W
R 301 NRSA63J-103X MG RESISTOR
R 302 NRSA63J-103X MG RESISTOR
R 303 QRA14CF-1001Y MF RESISTOR 10 1/4W
R 304 QRA14CF-1001Y MF RESISTOR 10 1/4W
R 305 NRSA63J-103X MG RESISTOR
R 306 NRSA63J-103X MG RESISTOR
R 307 NRSA63J-102X MG RESISTOR
R 308 NRSA63J-474X MG RESISTOR
