JVC RX-DP10VBK User Manual

RX-DP10VBK/BX-DP10VSL
RX-DP10RSL
3-19
Item
Parts number Parts name Ar
e
a
Electrical parts list
(Audio/video input & outpat board)
Remarks
Block No. 02
A
Item
Parts number Parts name
Are
a
Remarks
A
R 311 NRSA63J-102X MG RESISTOR
R 312 NRSA63J-102X MG RESISTOR
R 313 NRSA63J-102X MG RESISTOR
R 314 NRSA63J-102X MG RESISTOR
R 315 NRSA63J-102X MG RESISTOR
R 316 NRSA63J-102X MG RESISTOR
R 319 QRA14CF-1001Y MF RESISTOR 10 1/4W
R 320 NRSA63J-103X MG RESISTOR
R 321 NRSA63J-471X MG RESISTOR
R 322 NRSA63J-471X MG RESISTOR
R 323 NRSA63J-471X MG RESISTOR
R 324 NRSA63J-471X MG RESISTOR
R 325 NRSA63J-471X MG RESISTOR
R 326 NRSA63J-471X MG RESISTOR
R 327 NRSA63J-471X MG RESISTOR
R 328 NRSA63J-471X MG RESISTOR
R 329 NRSA63J-471X MG RESISTOR
R 330 NRSA63J-471X MG RESISTOR
R 331 NRSA63J-471X MG RESISTOR
R 332 NRSA63J-471X MG RESISTOR
R 333 NRSA63J-471X MG RESISTOR
R 334 NRSA63J-471X MG RESISTOR
R 335 NRSA63J-471X MG RESISTOR
R 336 NRSA63J-471X MG RESISTOR
R 337 NRSA63J-471X MG RESISTOR
R 338 NRSA63J-471X MG RESISTOR
R 339 QRZ9005-680X F RESISTOR
A
68 1/4W
R 340 QRZ9005-680X F RESISTOR
A
68 1/4W
R 341 NRSA63J-471X MG RESISTOR
R 342 NRSA63J-471X MG RESISTOR
R 345 NRSA63J-471X MG RESISTOR
R 346 NRSA63J-471X MG RESISTOR
R 347 NRSA63J-103X MG RESISTOR
R 348 NRSA63J-103X MG RESISTOR
R 349 NRSA63J-471X MG RESISTOR
R 350 NRSA63J-103X MG RESISTOR
R 351 NRSA63J-471X MG RESISTOR
R 352 NRSA63J-471X MG RESISTOR
R 355 NRSA63J-471X MG RESISTOR
R 356 NRSA63J-471X MG RESISTOR
R 357 NRSA63J-103X MG RESISTOR
R 358 NRSA63J-103X MG RESISTOR
R 363 NRSA63J-102X MG RESISTOR
R 364 NRSA63J-474X MG RESISTOR
R 365 NRSA63J-102X MG RESISTOR
R 366 NRSA63J-474X MG RESISTOR
R 369 NRSA63J-102X MG RESISTOR
R 370 NRSA63J-474X MG RESISTOR
R 399 NRSA63J-471X MG RESISTOR
R 400 NRSA63J-471X MG RESISTOR
R 401 NRSA63J-750X MG RESISTOR
R 402 NRSA63J-750X MG RESISTOR
R 403 NRSA63J-750X MG RESISTOR
R 404 NRSA63J-750X MG RESISTOR
R 405 NRSA63J-750X MG RESISTOR
R 406 NRSA63J-750X MG RESISTOR
R 407 NRSA63J-750X MG RESISTOR
R 408 NRSA63J-331X MG RESISTOR
R 409 NRSA63J-473X MG RESISTOR
R 410 NRSA63J-331X MG RESISTOR
R 411 NRSA63J-473X MG RESISTOR
R 412 NRSA63J-331X MG RESISTOR
R 413 NRSA63J-331X MG RESISTOR
R 414 NRSA63J-473X MG RESISTOR
R 415 NRSA63J-151X MG RESISTOR
R 416 NRSA63J-151X MG RESISTOR
R 417 NRSA63J-301X MG RESISTOR
R 418 NRSA63J-103X MG RESISTOR
R 419 NRSA63J-331X MG RESISTOR
R 420 NRSA63J-101X MG RESISTOR
R 421 NRSA63J-121X MG RESISTOR
R 422 NRSA63J-151X MG RESISTOR
R 423 NRSA63J-561X MG RESISTOR
R 424 NRSA63J-561X MG RESISTOR
R 425 NRSA63J-561X MG RESISTOR
R 426 QRJ146J-1R0X UNF C RESISTOR
A
1.0 5% 1/4W
R 427 NRSA63J-222X MG RESISTOR
R 431 NRSA63J-750X MG RESISTOR
R 432 NRSA63J-750X MG RESISTOR
R 433 NRSA63J-750X MG RESISTOR
R 434 NRSA63J-750X MG RESISTOR
R 435 NRSA63J-473X MG RESISTOR
R 436 NRSA63J-750X MG RESISTOR
R 437 NRSA63J-750X MG RESISTOR
R 438 NRSA63J-750X MG RESISTOR
R 439 NRSA63J-750X MG RESISTOR
R 440 NRSA63J-473X MG RESISTOR
R 441 NRSA63J-750X MG RESISTOR
R 442 NRSA63J-750X MG RESISTOR
R 443 NRSA63J-750X MG RESISTOR
R 444 NRSA63J-750X MG RESISTOR
R 445 NRSA63J-750X MG RESISTOR
R 446 NRSA63J-750X MG RESISTOR
R 447 NRSA63J-473X MG RESISTOR
R 448 NRSA63J-121X MG RESISTOR
R 449 NRSA63J-121X MG RESISTOR
R 450 NRSA63J-151X MG RESISTOR
R 451 NRSA63J-151X MG RESISTOR
R 452 QRJ146J-6R8X UNF C RESISTOR
A
6.8 5% 1/4W
R 453 QRJ146J-2R2X UNF C RESISTOR
A
2.2 5% 1/4W
R 461 NRSA63J-562X MG RESISTOR
R 462 NRSA63J-562X MG RESISTOR
R 463 NRSA63J-562X MG RESISTOR
R 464 NRSA63J-562X MG RESISTOR
R 465 NRSA63J-562X MG RESISTOR
R 466 NRSA63J-223X MG RESISTOR
R 467 NRSA63J-223X MG RESISTOR
R 468 NRSA63J-223X MG RESISTOR
R 469 NRSA63J-104X MG RESISTOR
R 470 NRSA63J-334X MG RESISTOR
R 471 NRSA63J-472X MG RESISTOR
R 472 NRSA63J-472X MG RESISTOR
R 473 NRSA63J-472X MG RESISTOR
R 474 NRSA63J-103X MG RESISTOR
R 475 NRSA63J-103X MG RESISTOR
R 476 NRSA63J-103X MG RESISTOR
RY240 QSK0125-001 RELAY
RY351 QSK0125-001 RELAY
R1351 QRZ9005-331X F RESISTOR
A
330 1/4W
R2001 QRZ9005-680X F RESISTOR
A
68 1/4W
R2002 QRZ9005-680X F RESISTOR
A
68 1/4W
R2011 NRSA63J-104X MG RESISTOR
R2012 NRSA63J-104X MG RESISTOR
R2013 NRSA63J-104X MG RESISTOR
R2014 NRSA63J-104X MG RESISTOR
R2015 NRSA63J-104X MG RESISTOR
