JVC RX-DP10VBK User Manual

RX-DP10VBK/RX-DP10VSL
RX-DP10RSL
3-20
Item
Parts number Parts name Ar
e
a
Electrical parts list
(Audio/video input & outpat board)
Remarks
Block No. 02
A
Item
Parts number Parts name Ar
e
a
Remarks
A
R2016 NRSA63J-104X MG RESISTOR
R2017 QRZ9005-680X F RESISTOR
A
68 1/4W
R2018 QRZ9005-680X F RESISTOR
A
68 1/4W
R2021 NRSA63J-334X MG RESISTOR
R2022 NRSA63J-334X MG RESISTOR
R2023 NRSA63J-102X MG RESISTOR
R2024 NRSA63J-102X MG RESISTOR
R2025 NRSA63J-103X MG RESISTOR
R2026 NRSA63J-103X MG RESISTOR
R2027 NRSA63J-102X MG RESISTOR
R2028 NRSA63J-474X MG RESISTOR
R2031 NRSA63J-104X MG RESISTOR
R2032 NRSA63J-104X MG RESISTOR
R2033 NRSA63J-102X MG RESISTOR
R2034 NRSA63J-102X MG RESISTOR
R2035 NRSA63J-512X MG RESISTOR
R2036 NRSA63J-512X MG RESISTOR
R2037 NRSA63J-104X MG RESISTOR
R2038 NRSA63J-104X MG RESISTOR
R2039 QRZ9005-680X F RESISTOR
A
68 1/4W
R2040 QRZ9005-680X F RESISTOR
A
68 1/4W
R2041 NRSA63J-102X MG RESISTOR
R2042 NRSA63J-102X MG RESISTOR
R2043 NRSA63J-103X MG RESISTOR
R2044 NRSA63J-103X MG RESISTOR
R2045 NRSA63J-474X MG RESISTOR
R2046 NRSA63J-102X MG RESISTOR
R2051 NRSA63J-334X MG RESISTOR
R2052 NRSA63J-334X MG RESISTOR
R2053 NRSA63J-104X MG RESISTOR
R2054 NRSA63J-104X MG RESISTOR
R2055 NRSA63J-104X MG RESISTOR
R2056 NRSA63J-104X MG RESISTOR
R2057 QRZ9005-680X F RESISTOR
A
68 1/4W
R2058 QRZ9005-680X F RESISTOR
A
68 1/4W
R2059 NRSA63J-334X MG RESISTOR
R2060 NRSA63J-334X MG RESISTOR
R2061 NRSA63J-104X MG RESISTOR
R2062 NRSA63J-104X MG RESISTOR
R2063 NRSA63J-104X MG RESISTOR
R2064 NRSA63J-104X MG RESISTOR
R2065 QRZ9005-680X F RESISTOR
A
68 1/4W
R2066 QRZ9005-680X F RESISTOR
A
68 1/4W
R2067 NRSA63J-334X MG RESISTOR
R2068 NRSA63J-334X MG RESISTOR
R2069 NRSA63J-104X MG RESISTOR
R2070 NRSA63J-104X MG RESISTOR
R2071 NRSA63J-104X MG RESISTOR
R2072 NRSA63J-104X MG RESISTOR
R2073 QRZ9005-680X F RESISTOR
A
68 1/4W
R2074 QRZ9005-680X F RESISTOR
A
68 1/4W
R2075 NRSA63J-334X MG RESISTOR
R2076 NRSA63J-334X MG RESISTOR
R2077 NRSA63J-104X MG RESISTOR
R2078 NRSA63J-104X MG RESISTOR
R2079 NRSA63J-104X MG RESISTOR
R2080 NRSA63J-104X MG RESISTOR
R2081 QRZ9005-680X F RESISTOR
A
68 1/4W
R2082 QRZ9005-680X F RESISTOR
A
68 1/4W
R2091 NRSA63J-222X MG RESISTOR
R2092 NRSA63J-222X MG RESISTOR
R2093 NRSA63J-471X MG RESISTOR
R2094 NRSA63J-471X MG RESISTOR
R2111 NRSA63J-473X MG RESISTOR
R2112 NRSA63J-104X MG RESISTOR
R2113 NRSA63J-102X MG RESISTOR
R2114 NRSA63J-102X MG RESISTOR
R2115 NRSA63J-473X MG RESISTOR
R2116 NRSA63J-102X MG RESISTOR
R2117 NRSA63J-104X MG RESISTOR
R2118 NRSA63J-103X MG RESISTOR
R2119 NRSA63J-103X MG RESISTOR
R2120 NRSA63J-103X MG RESISTOR
R2121 NRSA63J-332X MG RESISTOR
R2122 NRSA63J-103X MG RESISTOR
R2123 NRSA63J-103X MG RESISTOR
R2124 QRJ146J-101X UNF C RESISTOR
A
100 5% 1/4W
R2211 NRSA63J-102X MG RESISTOR
R2212 NRSA63J-102X MG RESISTOR
R2213 NRSA63J-102X MG RESISTOR
R2214 NRSA63J-102X MG RESISTOR
R2215 NRSA63J-102X MG RESISTOR
R2216 NRSA63J-102X MG RESISTOR
R2259 NRSA63J-333X MG RESISTOR
R2260 NRSA63J-333X MG RESISTOR
R2261 NRSA63J-333X MG RESISTOR
R2262 NRSA63J-333X MG RESISTOR
R2263 NRSA63J-333X MG RESISTOR
R2264 NRSA63J-333X MG RESISTOR
R2265 NRSA63J-333X MG RESISTOR
R2266 NRSA63J-333X MG RESISTOR
R2267 NRSA63J-333X MG RESISTOR
R2268 NRSA63J-333X MG RESISTOR
R2269 NRSA63J-102X MG RESISTOR
R2270 NRSA63J-102X MG RESISTOR
R2273 NRSA63J-102X MG RESISTOR
R2274 NRSA63J-102X MG RESISTOR
R2275 QRZ9005-680X F RESISTOR
A
68 1/4W
R2276 QRZ9005-680X F RESISTOR
A
68 1/4W
R2301 NRSA63J-682X MG RESISTOR
R2302 NRSA63J-682X MG RESISTOR
R2303 NRSA63J-102X MG RESISTOR
R2304 NRSA63J-102X MG RESISTOR
R2316 NRSA63J-103X MG RESISTOR
R2317 NRSA63J-103X MG RESISTOR
R2351 QRA14CF-1001Y MF RESISTOR 10 1/4W
R2352 QRA14CF-1001Y MF RESISTOR 10 1/4W
R2353 QRA14CF-5101Y MF RESISTOR 51 1/4W
R2354 QRA14CF-5101Y MF RESISTOR 51 1/4W
R2355 QRA14CF-1001Y MF RESISTOR 10 1/4W
R2356 QRA14CF-1001Y MF RESISTOR 10 1/4W
R2357 QRA14CF-5101Y MF RESISTOR 51 1/4W
R2358 QRA14CF-1802Y MF RESISTOR 18 1/4W
R2359 QRA14CF-1001Y MF RESISTOR 10 1/4W
R2360 QRA14CF-1001Y MF RESISTOR 10 1/4W
R2361 QRA14CF-5101Y MF RESISTOR 51 1/4W
R2362 QRA14CF-5101Y MF RESISTOR 51 1/4W
R2363 QRA14CF-1001Y MF RESISTOR 10 1/4W
R2364 QRA14CF-1001Y MF RESISTOR 10 1/4W
R2365 QRA14CF-5101Y MF RESISTOR 51 1/4W
R2366 QRA14CF-5101Y MF RESISTOR 51 1/4W
R2401 NRSA63J-104X MG RESISTOR
R2402 NRSA63J-104X MG RESISTOR
R2403 NRSA63J-104X MG RESISTOR
R2404 NRSA63J-104X MG RESISTOR
R2405 NRSA63J-104X MG RESISTOR
