JVC RX-DP10VBK User Manual

RX-DP10VBK/BX-DP10VSL
RX-DP10RSL
3-21
Item
Parts number Parts name Ar
e
a
Electrical parts list
(Audio/video input & outpat board)
Remarks
Block No. 02
A
R2406 NRSA63J-104X MG RESISTOR
R2411 NRSA63J-104X MG RESISTOR
R2412 NRSA63J-104X MG RESISTOR
R2413 NRSA63J-104X MG RESISTOR
R2414 NRSA63J-104X MG RESISTOR
R2415 NRSA63J-104X MG RESISTOR
R2416 NRSA63J-104X MG RESISTOR
R2421 NRSA63J-104X MG RESISTOR
R2422 NRSA63J-104X MG RESISTOR
R2423 NRSA63J-104X MG RESISTOR
R2424 NRSA63J-104X MG RESISTOR
R2425 NRSA63J-104X MG RESISTOR
R2426 NRSA63J-104X MG RESISTOR
R2501 NRSA63J-333X MG RESISTOR
R2502 NRSA63J-333X MG RESISTOR
R2503 NRSA63J-104X MG RESISTOR
R2504 NRSA63J-104X MG RESISTOR
R2505 NRSA63J-223X MG RESISTOR
R2506 NRSA63J-223X MG RESISTOR
R2507 NRSA63J-333X MG RESISTOR
R2508 NRSA63J-333X MG RESISTOR
R2509 NRSA63J-622X MG RESISTOR
R2510 NRSA63J-102X MG RESISTOR
R2511 NRSA63J-103X MG RESISTOR
R4001 NRSA63J-750X MG RESISTOR
R4002 NRSA63J-471X MG RESISTOR
R4003 NRSA63J-473X MG RESISTOR
R4004 NRSA63J-101X MG RESISTOR
R4005 NRSA63J-121X MG RESISTOR
R4006 NRSA63J-151X MG RESISTOR
R4031 NRSA63J-750X MG RESISTOR
R4032 NRSA63J-750X MG RESISTOR
R4033 NRSA63J-473X MG RESISTOR
R4034 NRSA63J-471X MG RESISTOR
SP403 VYH7653-001 IC HOLDER
WR204 QJK016-031803 SIN CR C-B WIRE
WR307 QJP001-031001 SHI CR C-B WIRE
WR318 QJK016-031403 SIN CR C-B WIRE
WR322 WJP0032-001A E-SH C WIRE C-B
WR323 QJK016-111401 SIN CR C-B WIRE
WR324 WJK0130-001A E-SI C WIRE C-B
X 401 QAX0260-001Z CRYSTAL
