3-24
Item
Parts number Parts name Ar
e
a
Electrical parts list
(Front & system control board)
Remarks
Block No. 04
A
BK961 LV42093-001A FL HOLDER(L)
BK962 LV42092-001A FL HOLDER(R)
C 471 QCSB1HJ-470Y C CAPACITOR 47PF 5% 50V
C 472 QCSB1HJ-470Y C CAPACITOR 47PF 5% 50V
C 473 QCSB1HJ-470Y C CAPACITOR 47PF 5% 50V
C 475 QCBB1HK-331Y C CAPACITOR 330PF 10% 50V
C 476 QCBB1HK-331Y C CAPACITOR 330PF 10% 50V
C 478 QDVB1EZ-223Y C CAPACITOR
C 479 QFN31HJ-473Z M CAPACITOR 0.047MF 5% 50V
CN301 QGA2001F1-07 CONNECTOR
CN963 QGF1205F1-16 CONNECTOR
CN964 QGF1205F1-20 CONNECTOR
CN969 QGA2001C1-09 9P PLUG ASSY
CN971 QGA2001F1-02 2P CONNECTOR
CN973 QGA2501F1-09 CONNECTOR
CN975 QGA2001F1-02 2P CONNECTOR
CN977 QGA2001F1-04 4P PLUG ASSY
CN981 QGA2001F1-02 2P CONNECTOR
CN982 QGF1005F1-04 4P PLUG ASSY
CN983 QGA2001F1-10 10P PLUG ASSY
CN985 QGA2001F1-06 6P PLUG ASSY
C1001 QEKC0JM-107Z E CAPACITOR 100MF 20% 6.3V
C1002 QCZ0202-155Z ML C CAPACITOR 1.5MF
C1003 QEZ0361-479 E.D.L.CAPACITOR 47000MF
C1004 QEKC1HM-225Z E CAPACITOR 2.2MF 20% 50V
C1005 QDVB1EZ-223Y C CAPACITOR
C1006 QEKC0JM-107Z E CAPACITOR 100MF 20% 6.3V
C1007 QCZ0202-155Z ML CAPACITOR 1.5MF
C1011 QEKC1HM-475Z E CAPACITOR 4.7MF 20% 50V
C1012 QEKC1HM-475Z E CAPACITOR 4.7MF 20% 50V
C1013 QEKC1HM-475Z E CAPACITOR 4.7MF 20% 50V
C1021 QCBB1HK-331Y C CAPACITOR 330PF 10% 50V
C1025 QEKC0JM-107Z E CAPACITOR 100MF 20% 6.3V
C1034 QDVB1EZ-223Y C CAPACITOR
C1035 QEKC1CM-476Z E CAPACITOR 47MF 20% 16V
C1036 QEKC1CM-106Z E CAPACITOR 10MF 20% 16V
C1037 QCZ0202-155Z ML C CAPACITOR 1.5MF
C1038 QEKC1CM-476Z E CAPACITOR 47MF 20% 16V
C1041 NCB31HK-471X C CAPACITOR
C1042 NCB31HK-471X C CAPACITOR
C1043 NCB31HK-471X C CAPACITOR
C1044 NCB31HK-471X C CAPACITOR
C1045 NCB31HK-471X C CAPACITOR
C1046 NCB31HK-471X C CAPACITOR
C1047 NCB31HK-471X C CAPACITOR
C1059 NCF31CZ-104X C CAPACITOR
C1060 NCF31CZ-104X C CAPACITOR
C1061 QCBB1HK-101Y C CAPACITOR 100PF 10% 50V
C1201 NCB31HK-102X C CAPACITOR
C1202 QFLC1HJ-104Z M CAPACITOR 0.1MF 5% 50V
C1203 QETN1AM-107Z E CAPACITOR 100MF 20% 10V
C1204 QETN1AM-107Z E CAPACITOR 100MF 20% 10V
C1211 NCB31HK-221X C CAPACITOR
C1212 NCB31HK-221X C CAPACITOR
C1213 NCB31HK-221X C CAPACITOR
DI961 QLF0087-001 FL TUBE
D1001 1SR35-400A-T5 DIODE
D1002 1SR35-400A-T5 DIODE
D1003 1SR35-400A-T5 DIODE
D1004 1SR35-400A-T5 DIODE
D1005 1SS133-T2 SI DIODE
D1023 1SS133-T2 SI DIODE
D1024 1SS133-T2 SI DIODE
D1031 SLR-342VC-T LED
D1032 SLR-342MC3F LED C
D1032 SLA-370LT3F LED J
D1033 SLA-370LT3F LED J
D1033 SLR-342MC3F LED C
D1034 SLA-370LT3F LED J
D1034 SELU2E10C LED C
D1201 1SS133-T2 SI DIODE
D1202 1SS133-T2 SI DIODE
D1211 MTZJ6.2C-T2 ZENER DIODE
FS961 E3400-444 FELT SPACER
FS962 E3400-444 FELT SPACER
IC301 NJM2406F-X IC
IC657 AK5383VF-X IC
IC961 MN101C49GJR IC
IC962 MN101C35DHN IC
IC963 IC-PST9139-T IC
IC964 GP1U271X RM RECIVER
IC967 TA8409S IC
J 471 QND0026-001 S JACK
JS961 QSW0867-001 ROTARY ENCODER
J1201 QNS0001-001 3.5 JACK
J1211 QNS0073-001 JACK
J1212 QNS0073-001 JACK
J1213 QNS0077-001 3.5 JACK
K 472 QQR0779-001Z INDUCTOR
K1035 QQR1183-001Z F BEADS
Q
1003 KRC107M-T D TRANSISTOR
Q
1011 KRC107M-T D TRANSISTOR
Q
1012 KRA107M-T D TRANSISTOR
Q
1013 KRA107M-T D TRANSISTOR
Q
1014 KRA107M-T D TRANSISTOR
Q
1015 KRA107M-T D TRANSISTOR
Q
1016 KRA107M-T D TRANSISTOR
Q
1017 KRA107M-T D TRANSISTOR
Q
1018 KRA107M-T D TRANSISTOR
Q
1019 KRA107M-T D TRANSISTOR
Q
1020 KRA107M-T D TRANSISTOR
Q
1021 KRC111M-T TRANSISTOR
Q
1022 KRC109M-T D TRANSISTOR
Q
1023 KRC107M-T D TRANSISTOR
Q
1031 KRA107M-T D TRANSISTOR
Q
1032 KRA107M-T D TRANSISTOR
Q
1033 KRA107M-T D TRANSISTOR
Q
1034 KRA107M-T D TRANSISTOR
Q
1035 KRC103M-T TRANSISTOR
Q
1201 KRA107M-T D TRANSISTOR
Q
1202 KTA1273/Y/-T TRANSISTOR
R 471 QRE141J-750Y C RESISTOR 75 5% 1/4W
R 472 QRE141J-750Y C RESISTOR 75 5% 1/4W
R 473 QRE141J-750Y C RESISTOR 75 5% 1/4W
RA966 QRB169J-104 R NETWORK 100K 5% 1/6W
R1003 QRE141J-331Y C RESISTOR 330 5% 1/4W
R1004 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R1005 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
R1011 QRE141J-513Y C RESISTOR 51K 5% 1/4W
R1021 QRE141J-471Y C RESISTOR 470 5% 1/4W
R1022 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R1023 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R1024 QRE141J-223Y C RESISTOR 22K 5% 1/4W
R1025 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R1030 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R1031 QRE141J-221Y C RESISTOR 220 5% 1/4W
