RX-DP10VBK/BX-DP10VSL
RX-DP10RSL
3-25
Item
Parts number Parts name Ar
e
a
Electrical parts list
(Front & system control board)
Remarks
Block No. 04
A
Item
Parts number Parts name Ar
e
a
Remarks
A
R1032 QRE141J-221Y C RESISTOR 220 5% 1/4W
R1033 QRE141J-221Y C RESISTOR 220 5% 1/4W
R1034 QRD161J-122 C RESISTOR C1.2K 5% 1/6W
R1035 QRE141J-100Y C RESISTOR 10 5% 1/4W
R1036 QRE141J-100Y C RESISTOR 10 5% 1/4W
R1037 QRE141J-153Y C RESISTOR 15K 5% 1/4W
R1038 QRE141J-333Y C RESISTOR 33K 5% 1/4W
R1039 QRE141J-273Y C RESISTOR 27K 5% 1/4W
R1041 NRSA63J-103X MG RESISTOR
R1042 NRSA63J-103X MG RESISTOR
R1043 NRSA63J-103X MG RESISTOR
R1044 NRSA63J-103X MG RESISTOR
R1045 NRSA63J-103X MG RESISTOR
R1046 NRSA63J-103X MG RESISTOR
R1047 NRSA63J-103X MG RESISTOR
R1048 NRSA63J-103X MG RESISTOR
R1049 NRSA63J-103X MG RESISTOR
R1050 NRSA63J-103X MG RESISTOR
R1051 NRSA63J-102X MG RESISTOR
R1052 NRSA63J-102X MG RESISTOR
R1053 NRSA63J-122X MG RESISTOR
R1056 NRSA63J-102X MG RESISTOR
R1059 NRSA63J-104X MG RESISTOR
R1060 NRSA63J-104X MG RESISTOR
R1061 NRSA63J-103X MG RESISTOR
R1062 NRSA63J-103X MG RESISTOR
R1063 NRSA63J-103X MG RESISTOR
R1064 NRSA63J-103X MG RESISTOR
R1065 NRSA63J-103X MG RESISTOR
R1066 NRSA63J-103X MG RESISTOR
R1067 NRSA63J-103X MG RESISTOR
R1071 NRSA63J-221X MG RESISTOR
R1072 NRSA63J-221X MG RESISTOR
R1073 NRSA63J-221X MG RESISTOR
R1074 NRSA63J-221X MG RESISTOR
R1075 NRSA63J-221X MG RESISTOR
R1076 NRSA63J-221X MG RESISTOR
R1081 NRSA63J-103X MG RESISTOR
R1082 NRSA63J-103X MG RESISTOR
R1083 NRSA63J-103X MG RESISTOR
R1084 NRSA63J-474X MG RESISTOR
R1085 NRSA63J-103X MG RESISTOR
R1086 NRSA63J-103X MG RESISTOR
R1091 NRSA63J-221X MG RESISTOR
R1092 NRSA63J-221X MG RESISTOR
R1093 NRSA63J-221X MG RESISTOR
R1094 NRSA63J-221X MG RESISTOR
R1095 NRSA63J-221X MG RESISTOR
R1096 NRSA63J-221X MG RESISTOR
R1097 NRSA63J-221X MG RESISTOR
R1098 NRSA63J-221X MG RESISTOR
R1099 NRSA63J-221X MG RESISTOR
R1101 NRSA63J-102X MG RESISTOR
R1102 NRSA63J-102X MG RESISTOR
R1103 NRSA63J-122X MG RESISTOR
R1104 NRSA63J-152X MG RESISTOR
R1105 NRSA63J-222X MG RESISTOR
R1106 NRSA63J-272X MG RESISTOR
R1107 NRSA63J-332X MG RESISTOR
R1122 NRSA63J-102X MG RESISTOR
R1123 NRSA63J-102X MG RESISTOR
R1124 NRSA63J-122X MG RESISTOR
R1125 NRSA63J-102X MG RESISTOR
R1126 NRSA63J-102X MG RESISTOR
R1127 NRSA63J-122X MG RESISTOR
R1128 NRSA63J-152X MG RESISTOR
R1129 NRSA63J-222X MG RESISTOR
R1130 NRSA63J-272X MG RESISTOR
R1131 NRSA63J-102X MG RESISTOR
R1132 NRSA63J-102X MG RESISTOR
R1133 NRSA63J-122X MG RESISTOR
R1134 NRSA63J-152X MG RESISTOR
R1135 NRSA63J-222X MG RESISTOR
R1141 NRSA63J-152X MG RESISTOR
R1142 NRSA63J-222X MG RESISTOR
R1143 NRSA63J-272X MG RESISTOR
R1144 NRSA63J-332X MG RESISTOR
R1151 NRSA63J-221X MG RESISTOR
R1152 NRSA63J-221X MG RESISTOR
R1153 NRSA63J-221X MG RESISTOR
R1154 NRSA63J-221X MG RESISTOR
R1155 NRSA63J-221X MG RESISTOR
R1156 NRSA63J-221X MG RESISTOR
R1157 NRSA63J-221X MG RESISTOR
R1158 NRSA63J-221X MG RESISTOR
R1161 NRSA63J-221X MG RESISTOR
R1162 NRSA63J-221X MG RESISTOR
R1163 NRSA63J-221X MG RESISTOR
R1164 NRSA63J-221X MG RESISTOR
R1165 NRSA63J-221X MG RESISTOR
R1166 NRSA63J-221X MG RESISTOR
R1167 NRSA63J-221X MG RESISTOR
R1168 NRSA63J-221X MG RESISTOR
R1169 NRSA63J-221X MG RESISTOR
R1170 NRSA63J-221X MG RESISTOR
R1171 NRSA63J-221X MG RESISTOR
R1172 NRSA63J-221X MG RESISTOR
R1173 NRSA63J-221X MG RESISTOR
R1174 NRSA63J-221X MG RESISTOR
R1175 NRSA63J-221X MG RESISTOR
R1176 NRSA63J-221X MG RESISTOR
R1177 NRSA63J-221X MG RESISTOR
R1178 NRSA63J-221X MG RESISTOR
R1179 NRSA63J-221X MG RESISTOR
R1180 NRSA63J-221X MG RESISTOR
R1181 NRSA63J-221X MG RESISTOR
R1182 NRSA63J-221X MG RESISTOR
R1183 NRSA63J-221X MG RESISTOR
R1184 NRSA63J-221X MG RESISTOR
R1191 NRSA63J-221X MG RESISTOR
R1192 NRSA63J-221X MG RESISTOR
R1193 NRSA63J-221X MG RESISTOR
R1194 NRSA63J-221X MG RESISTOR
R1195 NRSA63J-221X MG RESISTOR
R1196 NRSA63J-221X MG RESISTOR
R1197 NRSA63J-221X MG RESISTOR
R1198 NRSA63J-221X MG RESISTOR
R1201 NRSA63J-393X MG RESISTOR
R1202 NRSA63J-393X MG RESISTOR
R1203 NRSA63J-104X MG RESISTOR
R1204 NRSA63J-273X MG RESISTOR
R1205 NRSA63J-104X MG RESISTOR
R1206 NRSA63J-103X MG RESISTOR
R1207 QRJ146J-5R6X UNF C RESISTOR 5.6 5% 1/4W
R1208 NRSA63J-102X MG RESISTOR
R1209 NRSA63J-152X MG RESISTOR
