RX-DP10VBK/RX-DP10VSL
RX-DP10RSL
3-26
Item
Parts number Parts name Ar
e
a
Electrical parts list
(Front & system control board)
Remarks
Block No. 04
A
R1211 NRSA63J-221X MG RESISTOR
R1212 NRSA63J-471X MG RESISTOR
R1213 NRSA63J-221X MG RESISTOR
R1214 NRSA63J-101X MG RESISTOR
R1215 NRSA63J-221X MG RESISTOR
R1216 NRSA63J-221X MG RESISTOR
S1001 QSW0683-001Z PUSH SWITCH
(
SURROUND
)
S1002 QSW0683-001Z PUSH SWITCH
(
DSP MODE
)
S1003 QSW0683-001Z PUSH SWITCH
(
DIRECT
)
S1004 QSW0683-001Z PUSH SWITCH
(
THX
)
S1005 QSW0683-001Z PUSH SWITCH
(
SPK1
)
S1006 QSW0683-001Z PUSH SWITCH
(
SPK2
)
S1007 QSW0683-001Z PUSH SWITCH
(
SUBROOM CONT
)
S1022 QSW0683-001Z PUSH SWITCH
(
MAIN ROOM
)
S1023 QSW0683-001Z PUSH SWITCH
(
SUB ROOM
)
S1024 QSW0683-001Z PUSH SWITCH
(
POWER
)
S1025 QSW0683-001Z PUSH SWITCH
(
DOWN
)
S1026 QSW0683-001Z PUSH SWITCH
(
LEFT
)
S1027 QSW0683-001Z PUSH SWITCH
(
SET
)
S1028 QSW0683-001Z PUSH SWITCH
(
SETUP
)
S1029 QSW0683-001Z PUSH SWITCH
(
FM MODE
)
S1030 QSW0683-001Z PUSH SWITCH
(
SOUND SEL
)
S1031 QSW0683-001Z PUSH SWITCH
(
UP
)
S1032 QSW0683-001Z PUSH SWITCH
(
RIGHT
)
S1033 QSW0683-001Z PUSH SWITCH
(
EXIT
)
S1034 QSW0683-001Z PUSH SWITCH
(
ADJUST
)
S1035 QSW0683-001Z PUSH SWITCH
(
INPUT MODE
)
S1041 QSW0683-001Z PUSH SWITCH
(
EX K2
)
S1042 QSW0683-001Z PUSH SWITCH
(
DIMMER
)
S1043 QSW0683-001Z PUSH SWITCH
(
DOOR OPEN
)
S1044 QSW0683-001Z PUSH SWITCH
(
DOOR CLOSE
)
S1051 QSW0851-001 DETECT SWITCH
S1052 QSW0851-001 DETECT SWITCH
WR301 QJK017-030803 SIN CR C-B WIRE
WR961 QJK030-075002 SIN CR C-B WIRE
WR962 QJK030-081803 SIN CR C-B WIRE
WR965 QJK016-092404 SIN CR C-B WIRE
WR966 QJK016-062401 SIN CR C-B WIRE
WR967 QJK016-082802 SIN CR C-B WIRE
WR968 QJK016-094403 SIN CR C-B WIRE
WR970 QJK016-090802 SIN CR C-B WIRE
WR972 QJK016-021002 SIN CR C-B WIRE
WR977 QJK030-042404 SIN CR C-B WIRE
WR984 QJK016-101104 SIN CR C-B WIRE
WR986 QJK016-061102 SIN CR C-B WIRE
X1001 QAX0246-001Z RESONATOR
X1002 QAX0246-001Z RESONATOR
