70
Designs & specifications are subject to change without notice.
Specifications
Amplifier
Output Power At Stereo operation:
Front channels: 80 W per channel, min. RMS, driven into 8 Ω at 1
kHz, with no more than 0.9% total harmonic
distortion. (IEC268-3/DIN)
At Surround operation:
Front channels: 80 W per channel, min. RMS, driven into 8 Ω
at 1 kHz, with no more than 0.8% total harmonic
distortion.
Center channel: 80 W, min. RMS, driven into 8 Ω
at 1 kHz, with no more than 0.8% total harmonic
distortion.
Rear channels: 80 W per channel, min. RMS, driven into 8 Ω
at 1 kHz, with no more than 0.8% total harmonic
distortion.
Audio
Audio Input Sensitivity/Impedance (1 kHz): TV, TAPE/CDR, STB, VCR: 240 mV/47 kΩ
Audio Input (DIGITAL IN)* : Coaxial: DIGITAL 1 (STB): 0.5 V(p-p)/75 Ω
Optical: DIGITAL 2 (TV): –21 dBm to –15 dBm (660 nm ±30 nm)
* Corresponding to Linear PCM, Dolby Digital, and DTS Digital Surround
(with sampling frequency—32 kHz, 44.1 kHz, 48 kHz).
Signal-to-Noise Ratio (’66 IHF/DIN): TV, TAPE/CDR, STB, VCR: 87 dB/67 dB
Frequency Response (8 Ω): TV, TAPE/CDR, STB, VCR: 20 Hz to 20 kHz (±1 dB)
Tone Control: Bass (100 Hz): ±10 dB ±2 dB
Treble (10 kHz): ±10 dB ±2 dB
Video
Video Input Sensitivity/Impedance (1 kHz):
Composite video: STB IN, VCR IN: 1 V(p-p)/75 Ω
S-VIDEO: STB IN, VCR IN: (Y:luminance): 1 V(p-p)/75 Ω
(C:chrominance): 0.286 V(p-p)/75 Ω
RGB: STB IN, VCR IN: 0.7 V(p-p)/75 Ω
Video Output Level/Impedance (1 kHz):
Composite video: VCR OUT, TV OUT: 1 V(p-p)/75 Ω
S-VIDEO: TV OUT: (Y:luminance): 1 V(p-p)/75 Ω
(C:chrominance): 0.286 V(p-p)/75 Ω
RGB: TV OUT: 0.7 V(p-p)/75 Ω
Color System: PAL
Horizontal Resolution: 500 lines
Signal-to-Noise Ratio (S/N): 63 dB
Synchronize: Negative
FM tuner (IHF)
Tuning Range: 87.50 MHz to 108.00 MHz
AM tuner
Tuning Range: MW: 522 kHz to 1 629 kHz
General
Power Requirements: AC 230V , 50 Hz
Power Consumption: 180 W (in operation)
2 W (in standby mode)
Dimensions (W x H x D): 435 mm x 100 mm x 403.5 mm
Mass: 7.9 kg
EN61-70RX-DV3SL[B]f.pm5 02.6.6, 2:43 PM70
