JVC RX-E100RSB - Page 41

RX-E100RSL/RX-E100RSB
3-8
Item
Parts number Parts name Area
Electrical parts list
Remarks
Block No. 02
A
Item
Parts number Parts name Area
Remarks
A
BK401 LV32554-001A FL HOLDER(L)
BK402 LV32555-001A FL HOLDER(R)
C 401 QETN0JM-107Z E CAPACITOR 100MF 20% 6.3V
C 402 NCB31CK-223X C CAPACITOR
C 403 QETN1HM-225Z E CAPACITOR 2.2MF 20% 50V
C 404 QETN0JM-107Z E CAPACITOR 100MF 20% 6.3V
C 405 QCZ0205-155Z ML C CAPACITOR 1.5MF
C 406 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C 407 QEKC1HM-475Z E CAPACITOR 4.7MF 20% 50V
C 408 QEKC1HM-475Z E CAPACITOR 4.7MF 20% 50V
C 409 NCB31HK-102X C CAPACITOR
C 410 NCB31HK-102X C CAPACITOR
C 411 NCB31HK-102X C CAPACITOR
C 412 NCB31HK-103X C CAPACITOR
C 413 NCB31HK-103X C CAPACITOR
C 414 NCB31HK-103X C CAPACITOR
C 415 NCB31HK-103X C CAPACITOR
C 416 NCB31HK-103X C CAPACITOR
C 417 NCB31HK-561X C CAPACITOR
C 418 NCB31CK-223X C CAPACITOR
C 701 QFZ9076-104Z MM CAPACITOR .10MF
C 702 QFZ9076-104Z MM CAPACITOR .10MF
C 703 QFZ9076-104Z MM CAPACITOR .10MF
C 704 QTE1J45-478 E CAPACITER
C 705 QTE1J45-478 E CAPACITER
C 706 QETN1EM-476Z E CAPACITOR 47MF 20% 25V
C 709 QETN1HM-106Z E CAPACITOR 10MF 20% 50V
C 710 QETN1CM-476Z E CAPACITOR 47MF 20% 16V
C 711 QEKC1HM-226Z E CAPACITOR 22MF 20% 50V
C 712 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C 713 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C 714 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C 715 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C 717 QCS31HJ-101Z C CAPACITOR 100PF 5% 50V
C 741 QFLC1HJ-223Z M CAPACITOR .022MF 5% 50V
C 742 QFLC1HJ-223Z M CAPACITOR .022MF 5% 50V
C 743 QCS31HJ-221Z C CAPACITOR 220PF 5% 50V
C 744 QCS31HJ-221Z C CAPACITOR 220PF 5% 50V
C 745 QCS31HJ-221Z C CAPACITOR 220PF 5% 50V
C 746 QCS31HJ-221Z C CAPACITOR 220PF 5% 50V
C 747 QCF31HZ-223Z C CAPACITOR .022MF +80:-20%
C 748 QCF31HZ-223Z C CAPACITOR .022MF +80:-20%
C 749 QFLC1HJ-223Z M CAPACITOR .022MF 5% 50V
C 750 QFLC1HJ-223Z M CAPACITOR .022MF 5% 50V
C 751 QCS31HJ-221Z C CAPACITOR 220PF 5% 50V
C 752 QCS31HJ-221Z C CAPACITOR 220PF 5% 50V
C 753 QCS31HJ-221Z C CAPACITOR 220PF 5% 50V
C 754 QCS31HJ-221Z C CAPACITOR 220PF 5% 50V
C 755 QCS31HJ-221Z C CAPACITOR 220PF 5% 50V
C 756 QCS31HJ-221Z C CAPACITOR 220PF 5% 50V
C 757 QFLC1HJ-473Z M CAPACITOR .047MF 5% 50V
C 758 QCS31HJ-221Z C CAPACITOR 220PF 5% 50V
C 759 QCS31HJ-221Z C CAPACITOR 220PF 5% 50V
C 760 QCS31HJ-221Z C CAPACITOR 220PF 5% 50V
CL701 QZW0038-001 WIRE CLAMP
CL702 QZW0038-001 WIRE CLAMP
CN121 QGB2501J1-12 CONNECTOR
CN122 QGB2501J1-04 CONNECTOR
CN202 QGA2501C1-03 3P CONNECTOR
CN206 QGD2501C1-03Z SOCKET
CN214 QGF1205F1-12 CONNECTOR
CN401 QGF1205F1-17 CONNECTOR
CN402 QGF1205F1-14 CONNECTOR
CN513 QGB2510K1-12 CONNECTOR
CN514 QGB2510K1-04 CONNECTOR
CN515 QGA2501C1-03 3P CONNECTOR
CN516 QGA2501C1-02 2P CONNECTOR
CN517 QGA2501C1-03 3P CONNECTOR
CN711 QGB2510J1-09 CONNECTOR
CN712 QGB2510J1-09 CONNECTOR
CN713 QGB2510J1-09 CONNECTOR
CN714 QGB2510J1-09 CONNECTOR
CN715 QGB2510J1-09 CONNECTOR
D 401 SLR-342MC-T LED
D 402 SLR-342MC-T LED
D 403 SLR-342MC-T LED
D 404 SPR-325MVW/L/-T LED
D 405 SPR-325MVW/L/-T LED
D 406 SPR-325MVW/L/-T LED
D 407 SLR-342VC-T LED
D 408 1SS355-X DIODE
D 701 30DF2-FC DIODE
A
D 702 30DF2-FC DIODE
A
D 703 30DF2-FC DIODE
A
D 704 30DF2-FC DIODE
A
D 705 MTZJ18C-T2 Z DIODE
D 707 1SS133-T2 SI DIODE
D 708 1SS133-T2 SI DIODE
D 709 MTZJ15C-T2 Z DIODE
D 710 MTZJ5.1C-T2 Z DIODE
D 711 1SS133-T2 SI DIODE
D 712 1SS133-T2 SI DIODE
D 713 1SS133-T2 SI DIODE
D 714 1SS133-T2 SI DIODE
D 715 1SS133-T2 SI DIODE
D 716 1SS133-T2 SI DIODE
D 741 1SS133-T2 SI DIODE
D 742 1SS133-T2 SI DIODE
D 743 1SS133-T2 SI DIODE
DI401 QLF0086-001 FL TUBE
EP701 QNZ0136-001Z EARTH PLATE
FW401 QUM133-20Z4Z4 PARA RIBON WIRE
FW701 QUM134-27Z4Z4 PARA RIBON WIRE
FW702 QUM136-24Z4Z4 PARA RIBON WIRE
FW707 QUM134-22DGZ4 PARA RIBON WIRE
IC401 MN101C35DHR IC
IC402 BU2092F-X IC
IC403 GP1U281X IC
IC404 IC-PST9139-T IC
L 741 QQLZ005-R45 INDUCTOR
L 742 QQLZ005-R45 INDUCTOR
L 743 QQLZ005-R45 INDUCTOR
L 744 QQLZ005-R45 INDUCTOR
L 745 QQLZ005-R45 INDUCTOR
Q
401 KTC3199/GL/-T TRANSISTOR
Q
402 KTC3199/GL/-T TRANSISTOR
Q
403 KTC3199/GL/-T TRANSISTOR
Q
404 KTC3199/GL/-T TRANSISTOR
Q
405 KTC3199/GL/-T TRANSISTOR
Q
406 KTC3199/GL/-T TRANSISTOR
Q
407 DTC114EKA-X TRANSISTOR
Q
408 DTA114EKA-X D TRANSISTOR
Q
409 DTA114EKA-X D TRANSISTOR
Q
410 DTA114EKA-X D TRANSISTOR
Q
411 DTA114EKA-X D TRANSISTOR
Q
412 DTA114EKA-X D TRANSISTOR
(Main & System control board)
