RX-E100SL
3-8
Item
Parts number Parts name Area
Electrical parts list
Remarks
Block No. 02
A
Item
Parts number Parts name Area
Remarks
A
BK401 LV32554-001A FL HOLDER(L)
BK402 LV32555-001A FL HOLDER(R)
C 401 QETN0JM-107Z E CAPACITOR 100MF 20% 6.3V
C 402 NCB31CK-223X C CAPACITOR
C 403 QETN1HM-225Z E CAPACITOR 2.2MF 20% 50V
C 404 QETN0JM-107Z E CAPACITOR 100MF 20% 6.3V
C 405 QCZ0205-155Z ML C CAPACITOR 1.5MF
C 406 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C 407 QEKC1HM-475Z E CAPACITOR 4.7MF 20% 50V
C 408 QEKC1HM-475Z E CAPACITOR 4.7MF 20% 50V
C 412 NCB31HK-103X C CAPACITOR
C 413 NCB31HK-103X C CAPACITOR
C 414 NCB31HK-103X C CAPACITOR
C 415 NCB31HK-103X C CAPACITOR
C 416 NCB31HK-103X C CAPACITOR
C 417 NCB31HK-561X C CAPACITOR
C 418 NCB31CK-223X C CAPACITOR
C 419 QETN0JM-107Z E CAPACITOR 100MF 20% 6.3V
C 701 QFZ9076-104Z MM CAPACITOR .10MF
C 702 QCE22HP-103 C CAPACITOR .010MF +100:-0%
C 703 QCE22HP-103 C CAPACITOR .010MF +100:-0%
C 704 QTE1J45-478 E CAPACITER
C 705 QTE1J45-478 E CAPACITER
C 706 QETN1EM-476Z E CAPACITOR 47MF 20% 25V
C 709 QETN1HM-106Z E CAPACITOR 10MF 20% 50V
C 710 QETN1CM-476Z E CAPACITOR 47MF 20% 16V
C 711 QEKC1HM-226Z E CAPACITOR 22MF 20% 50V
C 712 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C 713 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C 714 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C 715 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C 717 QCS31HJ-101Z C CAPACITOR 100PF 5% 50V
CL701 QZW0038-001 WIRE CLAMP
CL702 QZW0038-001 WIRE CLAMP
CN121 QGB2501J1-12 CONNECTOR
CN202 QGA2501C1-03 3P CONNECTOR
CN206 QGD2501C1-03Z SOCKET
CN214 QGF1205F1-12 CONNECTOR
CN401 QGF1205F1-17 CONNECTOR
CN513 QGB2510K1-12 CONNECTOR
CN515 QGA2501C1-03 3P CONNECTOR
CN516 QGA2501C1-02 2P CONNECTOR
CN517 QGA2501C1-03 3P CONNECTOR
CN522 QGF1205F1-16 CONNECTOR
CN711 QGB2510J1-09 CONNECTOR
CN712 QGB2510J1-09 CONNECTOR
CN713 QGB2510J1-09 CONNECTOR
CN714 QGB2510J1-09 CONNECTOR
CN715 QGB2510J1-09 CONNECTOR
D 407 SLR-342VC-T LED
D 408 1SS355-X DIODE
D 701 30DF2-FC DIODE
A
D 702 30DF2-FC DIODE
A
D 703 30DF2-FC DIODE
A
D 704 30DF2-FC DIODE
A
D 705 MTZJ18C-T2 Z DIODE
D 707 1SS133-T2 SI DIODE
D 708 1SS133-T2 SI DIODE
D 709 MTZJ12C-T2 Z DIODE
D 710 MTZJ5.1C-T2 Z DIODE
D 711 1SS133-T2 SI DIODE
D 712 1SS133-T2 SI DIODE
D 713 1SS133-T2 SI DIODE
D 714 1SS133-T2 SI DIODE
D 715 1SS133-T2 SI DIODE
D 741 1SS133-T2 SI DIODE
D 742 1SS133-T2 SI DIODE
D 743 1SS133-T2 SI DIODE
DI401 QLF0086-001 FL TUBE
EP701 QNZ0136-001Z EARTH PLATE
FW401 QUM133-20Z4Z4 PARA RIBON WIRE
FW701 QUM134-27Z4Z4 PARA RIBON WIRE
FW702 QUM136-24Z4Z4 PARA RIBON WIRE
FW707 QUM134-22DGZ4 PARA RIBON WIRE
IC401 MN101C35DHR IC
IC403 GP1U281X IC
IC404 IC-PST9139-T IC
J1581 QNN0058-001 PIN JACK
J1582 QNN0056-001 PIN JACK
Q
407 DTC114EKA-X TRANSISTOR
Q
702 KTC3200/GL/-T TRANSISTOR
Q
703 KTA1268/GL/-T TRANSISTOR
Q
704 KTC3199/GL/-T TRANSISTOR
Q
705 2SD2395/EF/ TRANSISTOR
Q
706 KTA1023/OY/-T TRANSISTOR
Q
707 KTC3200/GL/-T TRANSISTOR
Q
708 KRC109M-T D TRANSISTOR
Q
709 KRC109M-T D TRANSISTOR
Q
710 KRC109M-T D TRANSISTOR
Q
711 KRC109M-T D TRANSISTOR
Q
712 KRC109M-T D TRANSISTOR
Q
713 KRC109M-T D TRANSISTOR
Q
714 KRC109M-T D TRANSISTOR
Q
715 KRC109M-T D TRANSISTOR
R 400 NRSA63J-103X MG RESISTOR
R 425 NRSA63J-103X MG RESISTOR
R 426 NRSA63J-223X MG RESISTOR
R 427 NRSA63J-472X MG RESISTOR
R 429 NRSA63J-103X MG RESISTOR
R 430 NRSA63J-102X MG RESISTOR
R 431 NRSA63J-102X MG RESISTOR
R 432 NRSA63J-122X MG RESISTOR
R 433 NRSA63J-152X MG RESISTOR
R 434 NRSA63J-222X MG RESISTOR
R 435 NRSA63J-272X MG RESISTOR
R 436 NRSA63J-103X MG RESISTOR
R 437 NRSA63J-102X MG RESISTOR
R 438 NRSA63J-102X MG RESISTOR
R 439 NRSA63J-122X MG RESISTOR
R 440 NRSA63J-152X MG RESISTOR
R 441 NRSA63J-222X MG RESISTOR
R 442 NRSA63J-272X MG RESISTOR
R 443 NRSA63J-392X MG RESISTOR
R 444 NRSA63J-103X MG RESISTOR
R 445 NRSA63J-102X MG RESISTOR
R 446 NRSA63J-102X MG RESISTOR
R 447 NRSA63J-122X MG RESISTOR
R 448 NRSA63J-152X MG RESISTOR
R 449 NRSA63J-222X MG RESISTOR
R 450 NRSA63J-272X MG RESISTOR
R 451 NRSA63J-392X MG RESISTOR
R 452 NRSA63J-103X MG RESISTOR
R 455 NRSA63J-103X MG RESISTOR
R 456 NRSA63J-103X MG RESISTOR
R 457 NRSA63J-102X MG RESISTOR
R 465 NRSA63J-221X MG RESISTOR
(Main & System control board)
