JVC RX-E100SL - Technical Specifications

RX-E100SL
3-9
Item
Parts number Parts name Area
Electrical parts list
Remarks
Block No. 02
A
Item
Parts number Parts name Area
Remarks
A
R 466 NRSA63J-221X MG RESISTOR
R 467 NRSA63J-221X MG RESISTOR
R 468 NRSA63J-221X MG RESISTOR
R 469 NRSA63J-221X MG RESISTOR
R 470 NRSA63J-221X MG RESISTOR
R 471 NRSA63J-221X MG RESISTOR
R 472 NRSA63J-221X MG RESISTOR
R 473 NRSA63J-221X MG RESISTOR
R 474 NRSA63J-221X MG RESISTOR
R 475 NRSA63J-221X MG RESISTOR
R 476 NRSA63J-221X MG RESISTOR
R 477 NRSA63J-221X MG RESISTOR
R 478 NRSA63J-221X MG RESISTOR
R 479 NRSA63J-221X MG RESISTOR
R 480 NRSA63J-221X MG RESISTOR
R 488 NRSA63J-103X MG RESISTOR
R 489 NRSA63J-103X MG RESISTOR
R 490 NRSA63J-103X MG RESISTOR
R 491 NRSA63J-221X MG RESISTOR
R 492 NRSA63J-392X MG RESISTOR
R 493 NRSA63J-103X MG RESISTOR
R 494 NRSA63J-103X MG RESISTOR
R 495 NRSA63J-103X MG RESISTOR
R 496 NRSA63J-103X MG RESISTOR
R 497 NRSA63J-103X MG RESISTOR
R 498 NRSA63J-103X MG RESISTOR
R 499 NRSA63J-103X MG RESISTOR
R 701 QRL022J-562 UNF OMF RESISTOR
A
5.6K 5% 1/2W
R 704 NRSA63J-104X MG RESISTOR
R 705 NRSA63J-104X MG RESISTOR
R 706 NRSA63J-823X MG RESISTOR
R 707 NRSA63J-104X MG RESISTOR
R 708 NRSA63J-823X MG RESISTOR
R 709 NRSA63J-103X MG RESISTOR
R 710 NRSA63J-103X MG RESISTOR
R 711 NRSA63J-104X MG RESISTOR
R 712 NRSA63J-223X MG RESISTOR
R 713 QRZ9005-100X F RESISTOR
A
10 1/0W
R 714 QRJ146J-103X UNF C RESISTOR
A
10K 5% 1/4W
R 715 QRZ9005-100X F RESISTOR
A
10 1/0W
R 716 QRJ146J-102X UNF C RESISTOR
A
1.0K 5% 1/4W
R 717 QRJ146J-223X UNF C RESISTOR
A
22K 5% 1/4W
R 718 NRSA63J-103X MG RESISTOR
R 719 NRSA63J-473X MG RESISTOR
R 720 QRJ146J-392X UNF C RESISTOR
A
3.9K 5% 1/4W
R 721 NRSA63J-472X MG RESISTOR
R 722 NRSA63J-123X MG RESISTOR
R 723 NRSA63J-822X MG RESISTOR
R 724 NRSA63J-472X MG RESISTOR
R 725 NRSA63J-472X MG RESISTOR
R 726 NRSA63J-472X MG RESISTOR
R 727 NRSA63J-472X MG RESISTOR
R 728 NRSA63J-472X MG RESISTOR
R 729 NRSA63J-123X MG RESISTOR
R 730 NRSA63J-822X MG RESISTOR
R 731 NRSA63J-123X MG RESISTOR
R 732 NRSA63J-822X MG RESISTOR
R 741 QRJ146J-120X UNF C RESISTOR
A
12 5% 1/4W
R 742 QRJ146J-120X UNF C RESISTOR
A
12 5% 1/4W
R 743 QRJ146J-120X UNF C RESISTOR
A
12 5% 1/4W
RY741 QSK0109-001 RELAY
A
RY742 QSK0109-001 RELAY
A
RY743 QSK0109-001 RELAY
A
R1422 NRSA63J-104X MG RESISTOR
R1423 NRSA63J-104X MG RESISTOR
R1424 NRSA63J-104X MG RESISTOR
R1425 NRSA63J-104X MG RESISTOR
R1426 NRSA63J-104X MG RESISTOR
R1427 NRSA63J-104X MG RESISTOR
R1428 NRSA63J-104X MG RESISTOR
R1581 NRSA63J-471X MG RESISTOR
R1582 NRSA63J-471X MG RESISTOR
R1583 NRSA63J-471X MG RESISTOR
R1584 NRSA63J-471X MG RESISTOR
R1585 NRSA63J-471X MG RESISTOR
R1586 NRSA63J-471X MG RESISTOR
R1587 NRSA63J-471X MG RESISTOR
R1588 NRSA63J-471X MG RESISTOR
R1589 NRSA63J-471X MG RESISTOR
R1590 NRSA63J-471X MG RESISTOR
R1591 NRSA63J-104X MG RESISTOR
R1592 NRSA63J-104X MG RESISTOR
R1593 NRSA63J-104X MG RESISTOR
R1594 NRSA63J-104X MG RESISTOR
R1595 NRSA63J-104X MG RESISTOR
R1596 NRSA63J-104X MG RESISTOR
R1597 NRSA63J-104X MG RESISTOR
R1598 NRSA63J-104X MG RESISTOR
S 401 QSW0683-001Z PUSH SWITCH SURROUND
S 402 QSW0683-001Z PUSH SWITCH DSP MODE
S 403 QSW0683-001Z PUSH SWITCH INPUT MODE
S 404 QSW0683-001Z PUSH SWITCH DVD
S 405 QSW0683-001Z PUSH SWITCH TV
S 406 QSW0683-001Z PUSH SWITCH UP
S 407 QSW0683-001Z PUSH SWITCH LEFT
S 408 QSW0683-001Z PUSH SWITCH VOL.DOWN
S 409 QSW0683-001Z PUSH SWITCH ADJUST
S 410 QSW0683-001Z PUSH SWITCH SETTING
S 411 QSW0683-001Z PUSH SWITCH VCR
S 412 QSW0683-001Z PUSH SWITCH CD
S 413 QSW0683-001Z PUSH SWITCH DOWN
S 414 QSW0683-001Z PUSH SWITCH RIGHT
S 415 QSW0683-001Z PUSH SWITCH VOL.UP
S 416 QSW0683-001Z PUSH SWITCH MEMORY
S 417 QSW0683-001Z PUSH SWITCH FM
S 418 QSW0683-001Z PUSH SWITCH AM
S 421 QSW0683-001Z PUSH SWITCH POWER
ST741 QNB0065-002 SPK TERMINAL FRONT
ST742 QNB0070-002 SPK TERMINAL CNT/SR
X 401 QAX0246-001Z RESONATOR
(Main & System control board)
