JVC RX-E100SL - Page 39

RX-E100SL
3-10
Item
Parts number Parts name Area
Electrical parts list
Remarks
Block No. 03
A
Item
Parts number Parts name Area
Remarks
A
C 519 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C 520 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C 521 QETN1HM-106Z E CAPACITOR 10MF 20% 50V
C 522 QETN1HM-106Z E CAPACITOR 10MF 20% 50V
C 523 QFLC1HJ-683Z M CAPACITOR .068MF 5% 50V
C 524 QFLC1HJ-683Z M CAPACITOR .068MF 5% 50V
C 525 QFLC1HJ-682Z M CAPACITOR 6800PF 5% 50V
C 526 QFLC1HJ-682Z M CAPACITOR 6800PF 5% 50V
C 527 QFLC1HJ-682Z M CAPACITOR 6800PF 5% 50V
C 528 QFLC1HJ-682Z M CAPACITOR 6800PF 5% 50V
C 529 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C 530 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C 531 QFLC1HJ-104Z M CAPACITOR .10MF 5% 50V
C 532 QFLC1HJ-104Z M CAPACITOR .10MF 5% 50V
C 533 QFLC1HJ-104Z M CAPACITOR .10MF 5% 50V
C 534 QFLC1HJ-104Z M CAPACITOR .10MF 5% 50V
C 535 NCB31CK-223X C CAPACITOR
C 536 NCB31CK-223X C CAPACITOR
C 537 NCB31CK-223X C CAPACITOR
C 541 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C 542 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C 544 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C 545 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C 546 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C 549 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C 550 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C 551 QFLC1HJ-562Z M CAPACITOR 5600PF 5% 50V
C 552 QFLC1HJ-562Z M CAPACITOR 5600PF 5% 50V
C 553 QETN0JM-477Z E CAPACITOR 470MF 20% 6.3V
C 554 QETN1HM-225Z E CAPACITOR 2.2MF 20% 50V
C 555 NCB31CK-223X C CAPACITOR
C 556 NCB31CK-223X C CAPACITOR
C 557 QETN1EM-476Z E CAPACITOR 47MF 20% 25V
C 558 QETN1EM-476Z E CAPACITOR 47MF 20% 25V
C 559 QETN1EM-476Z E CAPACITOR 47MF 20% 25V
C 560 QETN1EM-107Z E CAPACITOR 100MF 20% 25V
C 561 QETN1EM-107Z E CAPACITOR 100MF 20% 25V
C 562 QETN1EM-107Z E CAPACITOR 100MF 20% 25V
C 563 QCZ0205-155Z ML C CAPACITOR 1.5MF
C 564 QCF31HZ-223Z C CAPACITOR .022MF +80:-20%
C 565 QETN1EM-107Z E CAPACITOR 100MF 20% 25V
C 581 QETN1HM-225Z E CAPACITOR 2.2MF 20% 50V
C 601 QETN1HM-106Z E CAPACITOR 10MF 20% 50V
C 602 QETN1HM-106Z E CAPACITOR 10MF 20% 50V
C 603 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C 604 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C 605 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C 606 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
CL501 QZW0038-001 WIRE CLAMP
CL502 QZW0038-001 WIRE CLAMP
CN205 QGD2501C1-04Z SOCKET
CN411 QGF1205C1-17 CONNECTOR
CN501 QGB2510J1-20 CONNECTOR
CN502 QGF1205C1-16 CONNECTOR
CN503 QGB2510J1-12 CONNECTOR
CN505 QJP001-031401 SHI CR C-B WIRE
CN506 QJP002-021401 SHI CR C-B WIRE
CN507 QJP001-031101 SHI CR C-B WIRE
CN511 QGB2510K1-20 B TO B CONNE
CN601 QGB2510J1-20 CONNECTOR
D 503 MTZJ7.5C-T2 Z DIODE
D 504 MTZJ7.5C-T2 Z DIODE
D 505 MTZJ13C-T2 Z DIODE
D 506 MTZJ13C-T2 Z DIODE
D 507 MTZJ5.6C-T2 Z DIODE
D 508 MTZJ5.6C-T2 Z DIODE
D 509 1SS355-X DIODE
D 519 MTZJ10C-T2 Z DIODE
EP502 QNZ0136-001Z EARTH PLATE
FL501 QQR0590-001 FILTER
FL502 QQR0590-001 FILTER
HS512 E70306-001 HEAT SINK
HS513 E70306-001 HEAT SINK
HS514 E70306-001 HEAT SINK
HS515 E70306-001 HEAT SINK
HS520 E70306-001 HEAT SINK
IC501 M61501FP IC
IC503 BA15218F-XE IC
J 504 QNN0060-001 PIN JACK SUBWOOFER OUT
Q
501 2SC3576-JVC-T TRANSISTOR
Q
502 2SC3576-JVC-T TRANSISTOR
Q
503 2SC3576-JVC-T TRANSISTOR
Q
505 2SC3576-JVC-T TRANSISTOR
Q
506 2SC3576-JVC-T TRANSISTOR
Q
507 2SC3576-JVC-T TRANSISTOR
Q
508 2SC3576-JVC-T TRANSISTOR
Q
509 DTA114YKA-X TRANSISTOR
Q
510 KTA1271/OY/-T TRANSISTOR
A
Q
511 KTC3203/OY/-T TRANSISTOR
A
Q
512 KTA1046/Y/ TRANSISTOR
A
Q
513 2SD2395/EF/ TRANSISTOR
A
Q
514 2SD2395/EF/ TRANSISTOR
A
Q
515 2SD2395/EF/ TRANSISTOR
A
Q
516 DTA114YKA-X TRANSISTOR
Q
518 KTC3203/OY/-T TRANSISTOR
A
Q
520 2SD2395/EF/ TRANSISTOR
A
R 529 NRSA63J-102X MG RESISTOR
R 530 NRSA63J-102X MG RESISTOR
R 531 NRSA63J-103X MG RESISTOR
R 532 NRSA63J-103X MG RESISTOR
R 533 NRSA63J-472X MG RESISTOR
R 534 NRSA63J-472X MG RESISTOR
R 535 NRSA63J-103X MG RESISTOR
R 536 NRSA63J-103X MG RESISTOR
R 537 NRSA63J-103X MG RESISTOR
R 538 NRSA63J-103X MG RESISTOR
R 541 QRJ146J-2R2X UNF C RESISTOR
A
2.2 5% 1/4W
R 542 QRJ146J-2R2X UNF C RESISTOR
A
2.2 5% 1/4W
R 545 NRSA63J-104X MG RESISTOR
R 546 NRSA63J-104X MG RESISTOR
R 547 NRSA63J-102X MG RESISTOR
R 548 NRSA63J-102X MG RESISTOR
R 549 NRSA63J-103X MG RESISTOR
R 550 NRSA63J-103X MG RESISTOR
R 552 NRSA63J-104X MG RESISTOR
R 554 NRSA63J-273X MG RESISTOR
R 556 NRSA63J-102X MG RESISTOR
R 557 NRSA63J-104X MG RESISTOR
R 558 NRSA63J-104X MG RESISTOR
R 559 NRSA63J-102X MG RESISTOR
R 561 NRSA63J-103X MG RESISTOR
R 569 NRSA63J-104X MG RESISTOR
R 570 NRSA63J-104X MG RESISTOR
R 571 NRSA63J-102X MG RESISTOR
R 572 NRSA63J-102X MG RESISTOR
R 573 NRSA63J-103X MG RESISTOR
(Audio signal input board)
