When attaching the rear speakers to a wall
Using the supplied speaker wall brackets, you can fix the rear speakers to the wall.
CAUTION: Attaching the brackets to the wall
When attaching the brackets to the wall, have them attached to the wall by a qualified person.
DO NOT attach the brackets to the wall by yourself to avoid an unexpected damage due to their falling from the wall, caused by incorrect
attachment or weakness in the wall.
Location of attachment to wall:
Take care when selecting a location for attaching rear speakers to the wall. Injury to personnel, or damage to equipment, may
result if the speakers are attached in a location which interferes with daily activities.
Attaching speakers to the brackets
1 Use the supplied screws to attach the brackets to the rear speakers.
2 Adjust the angle of the rear speakers.
Loosen the screw slightly, make an adjustment, and then tighten the screw firmly.
CAUTION:
If the screws are not tightened firmly, this may cause injury to personnel or damage to equipment.
When attaching the AM loop antenna to a wall
You can attach the AM loop antenna to the wall.
Mount the AM loop antenna to a wall using the screw (not supplied) as illustrated below.
Installing the equipment on the wall
