# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

5-10

IC3004 BA6956AN IC

IC3601 BU2090FS IC

IC3651 BU2090FS IC

Q5 2SB1218A/QR/-X TRANSISTOR

or 2PA1576/R/-X TRANSISTOR

or 2SA1576A/QR/-X TRANSISTOR

Q7 2SD1819A/QRS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR

or 2SC4081/QRS/-X TRANSISTOR

Q8 2SD1819A/QRS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR

or 2SC4081/QRS/-X TRANSISTOR

Q9 2SB1218A/QR/-X TRANSISTOR

or 2PA1576/R/-X TRANSISTOR

or 2SA1576A/QR/-X TRANSISTOR

Q10 2SA1576A/QR/-X TRANSISTOR

Q17 DTC144WU DIGI TRANSISTOR

or PDTC144WU DIGI TRANSISTOR

or RN1309 DIGI TRANSISTOR

or UN521E DIGI TRANSISTOR

Q21 2SB1218A/QR/-X TRANSISTOR

or 2PA1576/R/-X TRANSISTOR

or 2SA1576A/QR/-X TRANSISTOR

Q24 2SB1218A/QR/-X TRANSISTOR

or 2PA1576/R/-X TRANSISTOR

or 2SA1576A/QR/-X TRANSISTOR

Q38 2SD1819A/QRS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR

or 2SC4081/QRS/-X TRANSISTOR

Q401 2SA1576A/QR/-X TRANSISTOR

Q402 2SA1576A/QR/-X TRANSISTOR

Q403 DTC144WU DIGI TRANSISTOR

or PDTC144WU DIGI TRANSISTOR

or RN1309 DIGI TRANSISTOR

or UN521E DIGI TRANSISTOR

Q405 2SA1576A/QR/-X TRANSISTOR

Q701 2SA1576A/QR/-X TRANSISTOR

or 2SB1218A/QR/-X TRANSISTOR

or 2PA1576/R/-X TRANSISTOR

Q702 2SA1576A/QR/-X TRANSISTOR

or 2SB1218A/QR/-X TRANSISTOR

or 2PA1576/R/-X TRANSISTOR

Q703 2SC4081/QRS/-X TRANSISTOR

or 2SD1819A/QRS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR

Q704 2SA1576A/QR/-X TRANSISTOR

or 2SB1218A/QR/-X TRANSISTOR

or 2PA1576/R/-X TRANSISTOR

Q705 2SC4081/QRS/-X TRANSISTOR

or 2SD1819A/QRS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR

Q706 2SA1576A/QR/-X TRANSISTOR

or 2SB1218A/QR/-X TRANSISTOR

or 2PA1576/R/-X TRANSISTOR

Q707 2SC4081/QRS/-X TRANSISTOR

or 2SD1819A/QRS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR

Q708 2SA1576A/QR/-X TRANSISTOR

or 2SB1218A/QR/-X TRANSISTOR

or 2PA1576/R/-X TRANSISTOR

Q709 2SC4081/QRS/-X TRANSISTOR

or 2SD1819A/QRS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR

Q712 2SC3938/QR/-X TRANSISTOR

Q713 2SC3938/QR/-X TRANSISTOR

Q714 2SC4081/QRS/-X TRANSISTOR

or 2SD1819A/QRS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR

Q715 2SA1576A/QR/-X TRANSISTOR

or 2SB1218A/QR/-X TRANSISTOR

or 2PA1576/R/-X TRANSISTOR

Q717 DTA144WU DIGI TRANSISTOR

or PDTA144WU DIGI TRANSISTOR

or RN2309 TRANSISTOR

or UN511E DIGI TRANSISTOR

Q718 2SA1576A/QR/-X TRANSISTOR

or 2SB1218A/QR/-X TRANSISTOR

or 2PA1576/R/-X TRANSISTOR

Q719 DTC144WU DIGI TRANSISTOR

or PDTC144WU DIGI TRANSISTOR

or RN1309 DIGI TRANSISTOR

or UN521E DIGI TRANSISTOR

Q720 DTC144WU DIGI TRANSISTOR

or PDTC144WU DIGI TRANSISTOR

or RN1309 DIGI TRANSISTOR

or UN521E DIGI TRANSISTOR

Q721 2SC3938/QR/-X TRANSISTOR

Q722 2SC3938/QR/-X TRANSISTOR

Q723 2SC4081/QRS/-X TRANSISTOR

or 2SD1819A/QRS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR

Q2001 2SC4081/QRS/-X TRANSISTOR

or 2SD1819A/QRS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR

Q2002 2SC4081/QRS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR

or 2SD1819A/QRS/-X TRANSISTOR

Q2003 DTA144WU DIGI TRANSISTOR

or PDTA144WU DIGI TRANSISTOR

or RN2309 TRANSISTOR

or UN511E DIGI TRANSISTOR

Q2006 DTC144WU DIGI TRANSISTOR

or PDTC144WU DIGI TRANSISTOR

or RN1309 DIGI TRANSISTOR

or UN521E DIGI TRANSISTOR

Q2051 2SC4081/QRS/-X TRANSISTOR

or 2SD1819A/QRS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR

Q2052 2SA1576A/QR/-X TRANSISTOR

or 2SB1218A/QR/-X TRANSISTOR

or 2PA1576/R/-X TRANSISTOR

Q2053 DTC144WU DIGI TRANSISTOR

or PDTC144WU DIGI TRANSISTOR

or RN1309 DIGI TRANSISTOR

or UN521E DIGI TRANSISTOR

Q2054 2SA1576A/QR/-X TRANSISTOR

or 2SB1218A/QR/-X TRANSISTOR

or 2PA1576/R/-X TRANSISTOR

Q2061 2SC4081/QRS/-X TRANSISTOR

or 2SD1819A/QRS/-X TRANSISTOR

or 2PC4081/R/-X TRANSISTOR

Q2062 2SA1576A/QR/-X TRANSISTOR
