JVC SR-VS30U Service Manual

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------
# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION
5-14
R3236 NRSA02J-332X MG RESISTOR 3.3kØ,1/10W
R3237 NRSA02J-103X MG RESISTOR 10kØ,1/10W
R3238 NRSA02J-103X MG RESISTOR 10kØ,1/10W
R3239 NRSA02J-103X MG RESISTOR 10kØ,1/10W
R3241 NRSA02J-104X MG RESISTOR 100kØ,1/10W
R3242 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W
R3248 NRSA02J-103X MG RESISTOR 10kØ,1/10W
R3251 NRSA02J-103X MG RESISTOR 10kØ,1/10W
R3256 NRSA02J-103X MG RESISTOR 10kØ,1/10W
R3257 NRSA02J-103X MG RESISTOR 10kØ,1/10W
R3258 NRSA02J-103X MG RESISTOR 10kØ,1/10W
R3260 NRSA02J-103X MG RESISTOR 10kØ,1/10W
R3261 NRSA02J-103X MG RESISTOR 10kØ,1/10W
R3604 NRSA02J-222X MG RESISTOR 2.2kØ,1/10W
R3605 NRSA02J-222X MG RESISTOR 2.2kØ,1/10W
R3607 NRSA02J-222X MG RESISTOR 2.2kØ,1/10W
R3608 NRSA02J-222X MG RESISTOR 2.2kØ,1/10W
R3609 NRSA02J-222X MG RESISTOR 2.2kØ,1/10W
R3610 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W
R3613 NRSA02J-102X MG RESISTOR 1kØ,1/10W
R3614 NRSA02J-103X MG RESISTOR 10kØ,1/10W
R3615 NRSA02J-103X MG RESISTOR 10kØ,1/10W
R3616 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W
R4003 NRSA02J-561X MG RESISTOR 560Ø,1/10W
R4004 NRSA02J-561X MG RESISTOR 560Ø,1/10W
R4005 NRSA02J-562X MG RESISTOR 5.6kØ,1/10W
R4006 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
R4007 NRSA02J-102X MG RESISTOR 1kØ,1/10W
R4008 NRSA02J-102X MG RESISTOR 1kØ,1/10W
R4009 NRSA02J-102X MG RESISTOR 1kØ,1/10W
R4010 NRSA02J-102X MG RESISTOR 1kØ,1/10W
R4011 NRSA02J-272X MG RESISTOR 2.7kØ,1/10W
R4012 NRSA02J-222X MG RESISTOR 2.2kØ,1/10W
R4013 NRSA02J-102X MG RESISTOR 1kØ,1/10W
R4014 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
R4015 NRSA02J-562X MG RESISTOR 5.6kØ,1/10W
R4017 NRSA02J-102X MG RESISTOR 1kØ,1/10W
R4018 NRSA02J-102X MG RESISTOR 1kØ,1/10W
R4019 NRSA02J-103X MG RESISTOR 10kØ,1/10W
R4020 NRSA02J-103X MG RESISTOR 10kØ,1/10W
R4021 NRSA02J-103X MG RESISTOR 10kØ,1/10W
R5401 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W
R5402 NRSA02J-222X MG RESISTOR 2.2kØ,1/10W
R6020 NRSA02J-102X MG RESISTOR 1kØ,1/10W
R6021 NRSA02J-102X MG RESISTOR 1kØ,1/10W
R6030 NRSA02J-332X MG RESISTOR 3.3kØ,1/10W
R6031 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
R6032 NRSA02J-123X MG RESISTOR 12kØ,1/10W
R6040 NRSA02J-471X MG RESISTOR 470Ø,1/10W
R6041 NRSA02J-184X MG RESISTOR 180kØ,1/10W
R6042 NRSA02J-272X MG RESISTOR 2.7kØ,1/10W
R6043 NRSA02J-223X MG RESISTOR 22kØ,1/10W
R6044 NRSA02J-822X MG RESISTOR 8.2kØ,1/10W
R6045 NRSA02J-471X MG RESISTOR 470Ø,1/10W
R6046 NRSA02J-103X MG RESISTOR 10kØ,1/10W
R6508 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
R6510 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
R6551 NRSA02J-271X MG RESISTOR 270Ø,1/10W
R6552 NRSA02J-101X MG RESISTOR 100Ø,1/10W
R6553 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
R6554 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
R7504 NRSA02J-562X MG RESISTOR 5.6kØ,1/10W
R7505 NRSA02J-221X MG RESISTOR 220Ø,1/10W
R7506 NRSA02J-472X MG RESISTOR 4.7kØ,1/10W
R7507 QRE121J-100Y RESISTOR 10Ø,1/2W
B8 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
B13 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
B65 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
B201 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
B203 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
B205 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
B208 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
B704 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
B3004 QUY160-100Y IM BUS WIRE
B3044 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
B3046 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
B3056 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
B3063 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
B3070 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
B3093 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
B3962 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
B3966 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
B3971 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
B5402 QUY160-100Y IM BUS WIRE
B5403 QUY153-050Y IM BUS WIRE
B6001 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
B6034 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
C1 NCF21CZ-105X CAPACITOR 1µF,16V
C2 NCF21CZ-105X CAPACITOR 1µF,16V
C3 NCF21CZ-105X CAPACITOR 1µF,16V
C4 NCF21CZ-105X CAPACITOR 1µF,16V
C5 QEKJ0JM-476 E CAPACITOR 47µF,6.3V
C6 NCB11EK-104X CAPACITOR 0.1µF,25V
C7 NCB21HK-102X CAPACITOR 0.001µF,50V
C8 NCB21EK-104X CAPACITOR 0.1µF,25V
C9 QEKJ1HM-225 E CAPACITOR 2.2µF,50V
C10 NDC21HG-151X CAPACITOR 150pF,50V
C11 NCB21EK-104X CAPACITOR 0.1µF,25V
C12 NDC21HJ-100X CAPACITOR 10pF,50V
C14 NCB21EK-104X CAPACITOR 0.1µF,25V
C15 NCB21HK-103X CAPACITOR 0.01µF,50V
C16 NCB21EK-104X CAPACITOR 0.1µF,25V
C17 QEKJ1HM-335 E CAPACITOR 3.3µF,50V
C19 QEKJ1HM-225 E CAPACITOR 2.2µF,50V
C20 QEKJ1HM-105 E CAPACITOR 1µF,50V
C21 NCB21EK-104X CAPACITOR 0.1µF,25V
C22 QEKJ0JM-476 E CAPACITOR 47µF,6.3V
C23 NCB21EK-104X CAPACITOR 0.1µF,25V
C24 NCB21EK-104X CAPACITOR 0.1µF,25V
C25 NDC21HJ-4R0X CAPACITOR 4pF,50V
C26 NCB21EK-104X CAPACITOR 0.1µF,25V
C27 NCB21HK-223X CAPACITOR 0.022µF,50V
C28 QEKJ1HM-335 E CAPACITOR 3.3µF,50V
C29 NCB21HK-472X CAPACITOR 0.0047µF,50V
C30 NCB21CK-474X CAPACITOR 0.47µF,16V
C31 QEKJ0JM-476 E CAPACITOR 47µF,6.3V
C32 NCB21EK-104X CAPACITOR 0.1µF,25V
C33 QEKJ1HM-225 E CAPACITOR 2.2µF,50V
C34 NCB21EK-104X CAPACITOR 0.1µF,25V
C35 NCB21EK-104X CAPACITOR 0.1µF,25V
C36 QEKJ1HM-475 E CAPACITOR 4.7µF,50V
C37 QEKJ1HM-105 E CAPACITOR 1µF,50V
