JVC SR-VS30U Service Manual

--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------
# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION
5-16
C2609 QEKJ1EM-106 E CAPACITOR 10µF,25V
C2610 QEKJ1EM-106 E CAPACITOR 10µF,25V
C2611 QEKC1EM-106 E CAPACITOR 10µF,25V
C2612 QEKC1EM-106 E CAPACITOR 10µF,25V
C2613 QEKC1EM-106 E CAPACITOR 10µF,25V
C2616 QEKJ1EM-106 E CAPACITOR 10µF,25V
C2617 QEKJ1EM-106 E CAPACITOR 10µF,25V
C3001 NCB21EK-104X CAPACITOR 0.1µF,25V
C3002 NCB21HK-103X CAPACITOR 0.01µF,50V
C3003 QEKJ1EM-106 E CAPACITOR 10µF,25V
C3004 NCB21EK-104X CAPACITOR 0.1µF,25V
C3008 NDC21HJ-102X CAPACITOR 0.001µF,50V
C3010 QEZ0244-229 EDL CAPACITOR 0.0022F,5.5V
C3012 QEKJ0JM-107 E CAPACITOR 100µF,6.3V
C3015 NCB21EK-104X CAPACITOR 0.1µF,25V
C3016 NCB21EK-104X CAPACITOR 0.1µF,25V
C3022 NCB21EK-104X CAPACITOR 0.1µF,25V
C3024 NDC21HJ-180X CAPACITOR 18pF,50V
C3027 QERF1CM-106 E CAPACITOR 10µF,16V
C3030 QERF1CM-226 E CAPACITOR 22µF,16V
C3031 NCB21EK-104X CAPACITOR 0.1µF,25V
C3032 NCB21EK-104X CAPACITOR 0.1µF,25V
C3033 NCB21EK-104X CAPACITOR 0.1µF,25V
C3036 NDC21HJ-180X CAPACITOR 18pF,50V
C3037 NDC21HJ-120X CAPACITOR 12pF,50V
C3040 NCB21HK-103X CAPACITOR 0.01µF,50V
C3041 NDC21HJ-120X CAPACITOR 12pF,50V
C3042 QETL0JM-108 E CAPACITOR 1000µF,6.3V
C3050 NCB21EK-104X CAPACITOR 0.1µF,25V
C3054 NCB21HK-103X CAPACITOR 0.01µF,50V
C3602 NCB21EK-104X CAPACITOR 0.1µF,25V
C3652 NCB21EK-104X CAPACITOR 0.1µF,25V
C4002 NCB21EK-104X CAPACITOR 0.1µF,25V
C4003 NCB21HK-102X CAPACITOR 0.001µF,50V
C4004 QEKJ1AM-226 E CAPACITOR 22µF,10V
C4006 QEKJ0JM-476 E CAPACITOR 47µF,6.3V
C4007 NCB21HK-102X CAPACITOR 0.001µF,50V
C4008 NCB21AK-105X CAPACITOR 1µF,10V
C4009 NCB21HK-563X CAPACITOR 0.056µF,50V
C4010 NCB21EK-223X CAPACITOR 0.022µF,25V
C4011 NCB21EK-104X CAPACITOR 0.1µF,25V
C4012 NCB21AK-105X CAPACITOR 1µF,10V
C4013 NCB21HK-563X CAPACITOR 0.056µF,50V
C4014 NDC21HJ-101X CAPACITOR 100pF,50V
C4015 NCB21HK-102X CAPACITOR 0.001µF,50V
C6023 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
C6040 NCB21EK-104X CAPACITOR 0.1µF,25V
C6042 NDC21HJ-471X CAPACITOR 470pF,50V
C6043 NCB21HK-223X CAPACITOR 0.022µF,50V
C6044 QEKJ1HM-225 E CAPACITOR 2.2µF,50V
C6553 QEKJ1AM-227 E CAPACITOR 220µF,10V
C7502 QETJ0JM-477 E CAPACITOR 470µF,6.3V
L1 QQL29BJ-100Z COIL 10µH
L2 QQL071J-101Y COIL 100µH
L3 QQL29BJ-100Z COIL 10µH
L4 QQL29BJ-100Z COIL 10µH
L5 QQL29BJ-100Z COIL 10µH
L11 QQL01BJ-120Z COIL 12µH
L13 QQL071J-330Y COIL 33µH
L15 QQL29BJ-100Z COIL 10µH
L18 QUY153-050Y IM BUS WIRE
L19 QQL071J-100Y COIL 10µH
L20 QUY153-050Y IM BUS WIRE
L28 QQL071J-150Y COIL 15µH
L30 QUY153-050Y IM BUS WIRE
L201 QQL29BK-1R0Z COIL 1.0µH
L202 QUY153-050Y IM BUS WIRE
L205 QUY153-050Y IM BUS WIRE
L206 QQL29BJ-220Z COIL 22µH
L401 QQL071J-150Y COIL 15µH
L402 QUY153-050Y IM BUS WIRE
L601 QQL29BJ-100Z COIL 10µH
L701 QQL29BJ-100Z COIL 10µH
L702 QQL29BJ-100Z COIL 10µH
L703 QQL29BJ-100Z COIL 10µH
L704 QQL29BJ-100Z COIL 10µH
L705 QQL29BJ-100Z COIL 10µH
L2001 QUY153-050Y IM BUS WIRE
L2251 QQL29BJ-100Z COIL 10µH
L3001 QUY153-050Y IM BUS WIRE
L6001 QUY153-050Y IM BUS WIRE
L6005 QUY153-050Y IM BUS WIRE
L6032 QUY153-050Y IM BUS WIRE
L7501 QQL29BJ-101Z COIL 100µH
X2 QAX0575-001 CRYSTAL RESONATOR
X3001 QAX0444-001 CRYSTAL RESONATOR
X3002 QAX0527-001 CRYSTAL RESONATOR
S3001 QSW0602-004 PUSH SWITCH,REC SAFETY
S3002 QSW0695-001 PUSH SWITCH,S CASS SW
K2001 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
K2002 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
K2003 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
K2004 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
K2251 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
K2252 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
K2253 NRSA02J-0R0X MG RESISTOR 0Ø,1/10W
PC3001 GP3S123 IC(PHOTO SENSOR)
PC3002 GP3S123 IC(PHOTO SENSOR)
T2051 PELN0860 OSC TRANSFORMER
T2052 PELN0861 OSC TRANSFORMER
T6040 PELN0806 LC TRAP
TU6001 QAU0255-001 TUNER
SD1 LP30644-001A S.CASE(PRE)
OT1 QYTDSF3010Z SCREW,X2,TERMINAL
ST2 PU59391 STYLE PIN
ET1 PQ21623-2-5 EARTH PLATE(RF)
WR100 QUQ212-0512CG FFC WIRE,TERMINAL CN901
WR101 QUQ112-1514CG FFC WIRE,TERMINAL CN502
CN1 QGF1028C1-13 FPC CONNECTOR,(1-13)DRUM
CN701 QGF1207C1-14 FPC CONNECTOR,(1-14)DV MAIN
CN2001 QGF1207C1-07 FPC CONNECTOR,(1-7)A/C HEAD
CN2002 QGB2532J1-02 CONNECTOR,(1-2)FE HEAD
CN2601 QGF1016C3-08 FFC/FPC CONNECTOR,(1-8)DV MAIN
CN3001 QGF1207C1-05 FPC CONNECTOR,(1-5)DRUM MDA
CN3002 QGB2532J1-02 CONNECTOR,(1-2)LOADING MOTOR
CN3003 QGB2015M2-08 CONNECTOR,(1-8)CAPSTAN MOTOR
CN3004 QGB2534J2-04 CONNECTOR,(1-4)ROTALY ENCODER
CN3011 QGF1209F2-20
FFC/FPC CONNECTOR,(1-20)SW/DISPLAY
CN3014 QGF1207C1-04 FPC CONNECTOR,(1-4)DV MAIN
CN3901 QGF1207C1-06 FPC CONNECTOR,(1-6)
CN7501 QGB2024K1-09S CONNECTOR,(1-9)TERMINAL
CN7502 QGB2024K1-10S CONNECTOR,(1-10)TERMINAL
