JVC SR-VS30U Service Manual

5-23
--------------- ----------------------- ----------------------------------------------------- ---------------- ----------------------- ------------------------------------------------------
# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION
R4007 NRSA63J-241X MG RESISTOR 240Ø,1/16W
R4008 NRSA63J-223X MG RESISTOR 22kØ,1/16W
R4009 NRSA63J-472X MG RESISTOR 4.7kØ,1/16W
R4010 NRSA63J-223X MG RESISTOR 22kØ,1/16W
R4021 NRSA63J-0R0X MG RESISTOR 0Ø,1/16W
RA1505 NRZ0040-102X NET RESISTOR
RA1506 NRZ0040-102X NET RESISTOR
RA1507 NRZ0040-102X NET RESISTOR
RA1508 NRZ0040-102X NET RESISTOR
RA1509 NRZ0040-102X NET RESISTOR
RA1510 NRZ0040-473X NET RESISTOR
C1001 NEA70JM-107X E CAPACITOR 100µF,6.3V
C1002 NCB31CK-104X CAPACITOR 0.1µF,16V
C1003 NEA70JM-107X E CAPACITOR 100µF,6.3V
C1004 NCB31CK-104X CAPACITOR 0.1µF,16V
C1005 NEA70JM-107X E CAPACITOR 100µF,6.3V
C1006 NCB31CK-104X CAPACITOR 0.1µF,16V
C1007 NCF21CZ-105X CAPACITOR 1µF,16V
C1008 NCF21CZ-105X CAPACITOR 1µF,16V
C1009 NCF21CZ-105X CAPACITOR 1µF,16V
C1010 NCB31CK-104X CAPACITOR 0.1µF,16V
C1011 NCB31CK-104X CAPACITOR 0.1µF,16V
C1012 NCF21CZ-105X CAPACITOR 1µF,16V
C1014 NBE21AM-106X T CAPACITOR 10µF,10V
C1015 NCF21CZ-105X CAPACITOR 1µF,16V
C1016 NCF21CZ-105X CAPACITOR 1µF,16V
C1017 NCB31EK-103X CAPACITOR 0.01µF,25V
C1018 NCF21CZ-105X CAPACITOR 1µF,16V
C1019 NCB31EK-103X CAPACITOR 0.01µF,25V
C1020 NCF21CZ-105X CAPACITOR 1µF,16V
C1021 NBE21AM-106X T CAPACITOR 10µF,10V
C1022 NCF21CZ-105X CAPACITOR 1µF,16V
C1023 NCB31EK-103X CAPACITOR 0.01µF,25V
C1024 NCF21CZ-105X CAPACITOR 1µF,16V
C1025 NBE21AM-106X T CAPACITOR 10µF,10V
C1026 NCF21CZ-105X CAPACITOR 1µF,16V
C1027 NCB31EK-103X CAPACITOR 0.01µF,25V
C1028 NCB31EK-103X CAPACITOR 0.01µF,25V
C1029 NCF21CZ-105X CAPACITOR 1µF,16V
C1030 NBE21AM-106X T CAPACITOR 10µF,10V
C1501 NCB31CK-104X CAPACITOR 0.1µF,16V
C1502 NCB31CK-104X CAPACITOR 0.1µF,16V
C1504 NCB31CK-104X CAPACITOR 0.1µF,16V
C1505 NCB31EK-103X CAPACITOR 0.01µF,25V
C1506 NCB31EK-103X CAPACITOR 0.01µF,25V
C1507 NCB31EK-103X CAPACITOR 0.01µF,25V
C1508 NCB31CK-104X CAPACITOR 0.1µF,16V
C1509 NEA70JM-476X E CAPACITOR 47µF,6.3V
C1510 NEA70JM-476X E CAPACITOR 47µF,6.3V
C1515 NCB31EK-223X CAPACITOR 0.022µF,25V
C1516 NCB31EK-223X CAPACITOR 0.022µF,25V
C1517 NCB31EK-223X CAPACITOR 0.022µF,25V
C1518 NCB31EK-223X CAPACITOR 0.022µF,25V
C1520 NCB31CK-104X CAPACITOR 0.1µF,16V
C1521 NCB31CK-104X CAPACITOR 0.1µF,16V
C1522 NCB31CK-104X CAPACITOR 0.1µF,16V
C1523 NCB31CK-104X CAPACITOR 0.1µF,16V
C2001 NCB31CK-104X CAPACITOR 0.1µF,16V
C2002 NCB31CK-104X CAPACITOR 0.1µF,16V
C2003 NCB31CK-104X CAPACITOR 0.1µF,16V
C2005 NCB31CK-104X CAPACITOR 0.1µF,16V
C2006 NCB31CK-104X CAPACITOR 0.1µF,16V
C2007 NCB31CK-104X CAPACITOR 0.1µF,16V
C2008 NDC31HJ-120X CAPACITOR 12pF,50V
C2009 NDC31HJ-120X CAPACITOR 12pF,50V
C2010 NCB31CK-104X CAPACITOR 0.1µF,16V
C2011 NCB31CK-104X CAPACITOR 0.1µF,16V
C2014 NDC31HJ-390X CAPACITOR 39pF,50V
C2015 NDC31HJ-102X CAPACITOR 0.001µF,50V
C2016 NCB31CK-104X CAPACITOR 0.1µF,16V
C2017 NCF21CZ-105X CAPACITOR 1µF,16V
C2018 NCB31EK-472X CAPACITOR 0.0047µF,25V
C2019 NDC31HJ-271X CAPACITOR 270pF,50V
C2020 NCB31CK-104X CAPACITOR 0.1µF,16V
C2022 NCB31CK-104X CAPACITOR 0.1µF,16V
C2023 NCB31CK-104X CAPACITOR 0.1µF,16V
C2024 NDC31HJ-6R0X CAPACITOR 6pF,50V
C2025 NDC31HJ-6R0X CAPACITOR 6pF,50V
C2026 NDC31HJ-102X CAPACITOR 0.001µF,50V
C2027 NDC31HJ-390X CAPACITOR 39pF,50V
C2028 NDC31HJ-102X CAPACITOR 0.001µF,50V
C2029 NDC31HJ-560X CAPACITOR 56pF,50V
C2031 NCB31CK-104X CAPACITOR 0.1µF,16V
C2032 NCB31CK-104X CAPACITOR 0.1µF,16V
C2036 NCB31CK-104X CAPACITOR 0.1µF,16V
C2037 NCB31CK-104X CAPACITOR 0.1µF,16V
C2038 NCB31CK-104X CAPACITOR 0.1µF,16V
C2039 NCB31CK-104X CAPACITOR 0.1µF,16V
C2040 NCB31CK-104X CAPACITOR 0.1µF,16V
C2041 NCB31CK-104X CAPACITOR 0.1µF,16V
C2042 NCB31CK-104X CAPACITOR 0.1µF,16V
C2043 NCB31CK-104X CAPACITOR 0.1µF,16V
C2044 NCB31CK-104X CAPACITOR 0.1µF,16V
C2046 NCB31CK-104X CAPACITOR 0.1µF,16V
C2047 NCB31CK-104X CAPACITOR 0.1µF,16V
C2048 NCB31EK-103X CAPACITOR 0.01µF,25V
C2051 NEA70JM-226X E CAPACITOR 22µF,6.3V
C2052 NCF21CZ-105X CAPACITOR 1µF,16V
C2053 NCB31CK-104X CAPACITOR 0.1µF,16V
C2054 NEA70JM-226X E CAPACITOR 22µF,6.3V
C2055 NEA70JM-226X E CAPACITOR 22µF,6.3V
C2056 NCB31CK-104X CAPACITOR 0.1µF,16V
C2057 NCF21CZ-105X CAPACITOR 1µF,16V
C2058 NEA70JM-226X E CAPACITOR 22µF,6.3V
C2059 NEA70JM-226X E CAPACITOR 22µF,6.3V
C2060 NCB31CK-104X CAPACITOR 0.1µF,16V
C2061 NCF21CZ-105X CAPACITOR 1µF,16V
C2062 NEA70JM-226X E CAPACITOR 22µF,6.3V
C2063 NCB31CK-104X CAPACITOR 0.1µF,16V
C2064 NEA70JM-226X E CAPACITOR 22µF,6.3V
C2101 NCB31CK-104X CAPACITOR 0.1µF,16V
C2102 NDC31HJ-151X CAPACITOR 150pF,50V
C2104 NCB31EK-473X CAPACITOR 0.047µF,25V
C2105 NBE21AM-106X T CAPACITOR 10µF,10V
C2113 NCB31CK-104X CAPACITOR 0.1µF,16V
C2114 NCB31EK-103X CAPACITOR 0.01µF,25V
C2115 NCB31CK-104X CAPACITOR 0.1µF,16V
C3001 NCB31CK-104X CAPACITOR 0.1µF,16V
C3002 NCB31CK-104X CAPACITOR 0.1µF,16V
C3003 NCB31CK-104X CAPACITOR 0.1µF,16V
C3004 NCB31CK-104X CAPACITOR 0.1µF,16V
C3005 NCB31CK-104X CAPACITOR 0.1µF,16V
