JVC TH-A25 Service Manual

3-4
General assembly
Block No. [M][1][M][M]
 Symbol No. Part No. Part Name Description Local
1 AH64-02580A BADGE-DVD
2 AH64-02575B WINDOW-CD
3 AH64-02569A DOOR-CD
4 AH61-01404A HOLDER-DOOR
5 AH61-01325A SPRING-DOOR (x2)
6 AH64-02574C WINDOW-FRONT
7 AH64-02570A KNOB-VOLUME
8 AH64-02573B DECO-VOLUME
9 AH73-00005A RUBBER-FOOT (x4)
10 AH63-00610A FILTER-VFD
11 AH64-02568C CABINET-FRONT
12 AH64-02572B KNOB-POWER
13 AH64-02571B KNOB-FUNCTION
14 AH61-01406A HOLDER-VFD
15 AH64-02316A CABINET-BOTTOM
16 AH62-00052D HEAT-SINK DIO
17 AH62-00096A HEAT-SINK S
18 AH62-00097A HEAT-SINK L
19 AH62-00098A HEAT-SINK TR
20 AH62-00062C HEAT-SINK TR
21 AH62-00062D HEAT-SINK TR
22 AH61-01140A BRKT-PCB (x2)
23 AH61-01355A BRKT-TUNER
24 AH63-00278H COVER-FUSE
25 AH61-00855A HOLDER-IC
26 AH61-00779A HOLDER-IC (x5)
27 AH64-02648B CABINET-REAR
28 AH63-00384A SHIELD-SPK8
29 AH63-00385A SHIELD-SPK4
30 AH31-00039A MOTOR FAN
31 AH63-00517A COVER-FAN
32 AH64-02315B CABINET-TOP
 33 AH39-00258U POWER-CORD
34 AH63-00632B SHIELD-FRONT.L
35 AH63-00632C SHIELD-FRONT.R
38 AH68-01348B LABEL-RATING A25C
38 AH68-01348A LABEL-RATING A25J
40 AH68-00093E LABEL-NO.1
41 AH68-00331C LABEL-FCC
42 AH68-00331D LABEL-HHS A25J
 44 AH26-00261B TRANS POWER
45 AH40-00058A TUNER-PACK ASSY
 46 3601-000301 FUSE-CARTRIDGE (x2)
47 AH59-01153B DVD MECHA ASSY
48 AJ60-10001A SCREW TAP (x2)
49 AH60-00025A SCREW-TAPTITE (x18)
50 6002-000126 SCREW-TAPPING (x2)
51 6003-000276 SCREW-TAPTITE (x29)
52 6003-000283 SCREW-TAPTITE (x16)
53 AH60-00014A SCREW-TAPTITE (x6)
54 6003-001499 SCREW-TAPTITE (x8)
