JVC TH-A25 Service Manual

3-11
Jack board
Block No. [0][4][0][0]
DVD pack board
Block No. [0][5][0][0]
FR63L 2007-000134 CHIP RESISTOR
FR63R 2007-000134 CHIP RESISTOR
FR64L 2007-000092 CHIP RESISTOR
FR64R 2007-000092 CHIP RESISTOR
FR65L 2007-000082 CHIP RESISTOR
FR65R 2007-000082 CHIP RESISTOR
FZD1 0403-001409 Z DIODE
FZD5 0403-000621 Z DIODE
FZD6 0403-000621 Z DIODE
RC8L 2401-000213 E CAPACITOR
RC8R 2401-000213 E CAPACITOR
RC9L 2203-000236 CHIP CAPACITOR
RC9R 2203-000236 CHIP CAPACITOR
RC12L 2203-000531 CHIP CAPACITOR
RC12R 2203-000531 CHIP CAPACITOR
RC13L 2203-000783 CHIP CAPACITOR
RC13R 2203-000783 CHIP CAPACITOR
RC14L 2401-000213 E CAPACITOR
RC14R 2401-000213 E CAPACITOR
RIC2 BA4560 IC 1201-000163
RJ1 2007-000070 CHIP RESISTOR
RJ2 2007-000070 CHIP RESISTOR
RQ1 0501-000341 TRANSISTOR
RR7 2007-000094 CHIP RESISTOR
RR10L 2007-000078 CHIP RESISTOR
RR10R 2007-000078 CHIP RESISTOR
RR12L 2007-000124 CHIP RESISTOR
RR12R 2007-000124 CHIP RESISTOR
RR13L 2007-000084 CHIP RESISTOR
RR13R 2007-000084 CHIP RESISTOR
SC8 2401-001238 E CAPACITOR
SC11 2203-001140 CHIP CAPACITOR
SC12 2203-005221 CHIP CAPACITOR
SC13 2401-001324 E CAPACITOR
SC19 2203-000783 CHIP CAPACITOR
SC20 2401-000752 E CAPACITOR
SC25 2203-000604 CHIP CAPACITOR
SIC1 BA4560 IC 1201-000163
SJ1 2007-000070 CHIP RESISTOR
SR6 2007-000101 CHIP RESISTOR
SR10 2007-000101 CHIP RESISTOR
SR11 2007-000098 CHIP RESISTOR
SR12 2007-000129 CHIP RESISTOR
SR13 2007-000098 CHIP RESISTOR
SR14 2007-000075 CHIP RESISTOR
SR18 2007-000075 CHIP RESISTOR
SR20 2007-000119 CHIP RESISTOR
SR21 2007-000084 CHIP RESISTOR
SR29 2007-000094 CHIP RESISTOR
UC500 2203-005005 CHIP CAPACITOR
UC510 2203-000604 CHIP CAPACITOR
UD500 0401-001090 FR DIODE
UIC50 M66010 IC 0904-001316
UR500 2007-000090 CHIP RESISTOR
UR501 2007-000090 CHIP RESISTOR
UR503 2007-000124 CHIP RESISTOR
UR504 2007-000124 CHIP RESISTOR
UR505 2007-000090 CHIP RESISTOR
UR506 2007-000090 CHIP RESISTOR
UR507 2007-000090 CHIP RESISTOR
UR508 2007-000082 CHIP RESISTOR
UR509 2007-000082 CHIP RESISTOR
UR510 2007-000082 CHIP RESISTOR
UR511 2007-000082 CHIP RESISTOR
UR512 2007-000082 CHIP RESISTOR
UR513 2007-000090 CHIP RESISTOR
UR514 2007-000090 CHIP RESISTOR
UR517 2007-000124 CHIP RESISTOR
UR518 2007-000090 CHIP RESISTOR
UR519 2007-000090 CHIP RESISTOR
UR520 2007-000124 CHIP RESISTOR
UR521 2007-000090 CHIP RESISTOR
UR522 2007-000090 CHIP RESISTOR
UR524 2007-000090 CHIP RESISTOR
UR525 2007-000078 CHIP RESISTOR
UW1 3710-001422 CONNECTOR
UW2 3710-001422 CONNECTOR
UW3 3710-001868 CONNECTOR
 Symbol No. Part No. Part Name Description Local
UW4 3708-000266 CONNECTOR
UW6 3708-001574 CONNECTOR
UW7 3710-001422 CONNECTOR
UW8 3710-001422 CONNECTOR
UW9 3711-000820 CONNECTOR
 Symbol No. Part No. Part Name Description Local
VC2 2401-001092 E CAPACITOR
VC6 2401-001092 E CAPACITOR
VC10 2401-001092 E CAPACITOR
VC14 2202-000781 C CAPACITOR
VC15 2401-001975 E CAPACITOR
VC16 2201-000783 C CAPACITOR
VC17 2202-000781 C CAPACITOR
VC18 2201-000783 C CAPACITOR
VC19 2401-001912 E CAPACITOR
VC20 2401-001893 E CAPACITOR
VC21 2401-001938 E CAPACITOR
VC22 2401-001893 E CAPACITOR
VC23 2401-001938 E CAPACITOR
VC24 2201-000783 C CAPACITOR
VC32 2201-000783 C CAPACITOR
VC35 2202-000797 C CAPACITOR
VR4 2001-000969 C RESISTOR
VR12 2001-000969 C RESISTOR
VR20 2001-000969 C RESISTOR
VR28 2001-000429 C RESISTOR
VR29 2001-000969 C RESISTOR
VR30 2001-000969 C RESISTOR
VR31 2001-000429 C RESISTOR
VR32 2001-000429 C RESISTOR
VR35 2001-000429 C RESISTOR
VR43 2001-000938 C RESISTOR
OC1 2202-000780 C CAPACITOR
OJ1 0603-001126 OP TRANSMITTER
SVJ5 3722-001894 JACK-DIN
VIC4 BA7665FS IC 1201-001922
VJ1 3722-001693 PIN JACK
VJK3 AH37-00005A RCA JACK
VL1 2701-000116 INDUCTOR-AXIAL
VL2 2701-000116 INDUCTOR-AXIAL
VW1 3711-004110 CONNECTOR
VW2 3711-004110 CONNECTOR
VW3 3708-001760 CONNECTOR
VW4 3708-001051 CONNECTOR
 Symbol No. Part No. Part Name Description Local
Q1 0504-000128 DIGI TRANSISTOR
D2 0401-001090 FR DIODE
PC1 2203-005005 CHIP CAPACITOR
PC2 2402-001042 E.CAPACITOR SMD
PC3 2402-001059 E.CAPACITOR SMD
PC4 2203-005005 CHIP CAPACITOR
PC8 2203-005005 CHIP CAPACITOR
PC9 2203-005005 CHIP CAPACITOR
PC10 2402-000107 E.CAPACITOR SMD
PC11 2402-000009 E CAPACITOR
PC12 2203-005005 CHIP CAPACITOR
