JVC TH-A25 Service Manual

3-10
Function board
Block No. [0][3][0][0]
 Symbol No. Part No. Part Name Description Local
C1 2401-000407 E CAPACITOR
C2 2401-000407 E CAPACITOR
C3 2203-000592 CHIP CAPACITOR
C4 2203-000592 CHIP CAPACITOR
CC7 2203-000531 CHIP CAPACITOR
CC8 2401-000213 E CAPACITOR
CC11 2203-000531 CHIP CAPACITOR
CC12 2203-000783 CHIP CAPACITOR
CC13 2401-000213 E CAPACITOR
CC19 2203-000236 CHIP CAPACITOR
CC23 2401-000213 E CAPACITOR
CIC2 BA4560 IC 1201-000163
CJ1 2007-000070 CHIP RESISTOR
CQ1 0501-000341 TRANSISTOR
CR6 2007-000078 CHIP RESISTOR
CR10 2007-000078 CHIP RESISTOR
CR12 2007-000124 CHIP RESISTOR
CR13 2007-000084 CHIP RESISTOR
CR21 2007-000094 CHIP RESISTOR
CR25 2007-000092 CHIP RESISTOR
FC19 2401-000407 E CAPACITOR
FC20 2401-001502 E CAPACITOR
FC30 2401-001502 E CAPACITOR
FC31 2401-001502 E CAPACITOR
FC32 2401-001502 E CAPACITOR
FC35 2203-000888 CHIP CAPACITOR
FC36 2203-001103 CHIP CAPACITOR
FC37 2401-000588 E CAPACITOR
FC38 2401-000588 E CAPACITOR
FC39 2203-001103 CHIP CAPACITOR
FC40 2203-000888 CHIP CAPACITOR
FC41 2401-002186 E CAPACITOR
FC42 2401-002186 E CAPACITOR
FC51 2401-000407 E CAPACITOR
FC52 2401-000407 E CAPACITOR
FC53 2401-000407 E CAPACITOR
FC54 2401-000407 E CAPACITOR
FC55 2401-000407 E CAPACITOR
FC56 2401-000407 E CAPACITOR
FC57 2401-001502 E CAPACITOR
FC58 2401-003336 E CAPACITOR
FC60 2401-001502 E CAPACITOR
FC9L 2401-001238 E CAPACITOR
FC9R 2401-001238 E CAPACITOR
FC10L 2203-000236 CHIP CAPACITOR
FC10R 2203-000236 CHIP CAPACITOR
FC11L 2203-000531 CHIP CAPACITOR
FC11R 2203-000531 CHIP CAPACITOR
FC12L 2401-000650 E CAPACITOR
FC12R 2401-000650 E CAPACITOR
FC14L 2401-000650 E CAPACITOR
FC14R 2401-000650 E CAPACITOR
FC15L 2401-000650 E CAPACITOR
FC15R 2401-000650 E CAPACITOR
FC16L 2401-000213 E CAPACITOR
FC16R 2401-000213 E CAPACITOR
FC17L 2203-001034 CHIP CAPACITOR
FC17R 2203-001034 CHIP CAPACITOR
FC18L 2203-000648 CHIP CAPACITOR
FC18R 2203-000648 CHIP CAPACITOR
FC19L 2203-001064 CHIP CAPACITOR
FC19R 2203-001064 CHIP CAPACITOR
FC23L 2401-000213 E CAPACITOR
FC23R 2401-000213 E CAPACITOR
FC24L 2203-000531 CHIP CAPACITOR
FC24R 2203-000531 CHIP CAPACITOR
FC25L 2203-000783 CHIP CAPACITOR
FC25R 2203-000783 CHIP CAPACITOR
FC26L 2401-000213 E CAPACITOR
FC26R 2401-000213 E CAPACITOR
FC43L 2401-000588 E CAPACITOR
FC43R 2401-000588 E CAPACITOR
FC44L 2401-000588 E CAPACITOR
FC44R 2401-000588 E CAPACITOR
FD5 0401-001090 FR DIODE
FIC2 BA4560 IC 1201-000163
FIC3 TDA7440D IC 1204-001465
FIC4 BA4560 IC 1201-000163
FIC5 M62446AFP IC 1201-000163
FIC6 BA4560 IC 1201-000163
FIC9 BA4560 IC 1201-000163
FJ1 2007-000070 CHIP RESISTOR
FJ2 2007-000070 CHIP RESISTOR
FQ3 0501-000341 TRANSISTOR
FQ4 0501-000341 TRANSISTOR
FR7 2007-000094 CHIP RESISTOR
FR8 2007-000094 CHIP RESISTOR
FR9 2007-000124 CHIP RESISTOR
FR10 2007-000124 CHIP RESISTOR
FR13 2007-000074 CHIP RESISTOR
FR14 2007-000074 CHIP RESISTOR
FR15 2007-000090 CHIP RESISTOR
FR16 2007-000077 CHIP RESISTOR
FR17 2007-000074 CHIP RESISTOR
FR18 2007-000074 CHIP RESISTOR
FR29 2007-000074 CHIP RESISTOR
FR30 2007-007347 CHIP RESISTOR
FR31 2007-007347 CHIP RESISTOR
FR32 2007-000078 CHIP RESISTOR
FR33 2007-000078 CHIP RESISTOR
FR35 2007-000078 CHIP RESISTOR
FR36 2007-000078 CHIP RESISTOR
FR37 2007-000078 CHIP RESISTOR
FR38 2007-000078 CHIP RESISTOR
FR39 2007-000078 CHIP RESISTOR
FR40 2007-000078 CHIP RESISTOR
FR41 2007-000078 CHIP RESISTOR
FR42 2007-000090 CHIP RESISTOR
FR43 2007-000090 CHIP RESISTOR
FR44 2007-000090 CHIP RESISTOR
FR56 2007-000077 CHIP RESISTOR
FR57 2007-000090 CHIP RESISTOR
FR58 2007-000090 CHIP RESISTOR
FR59 2007-000090 CHIP RESISTOR
FR60 2007-000078 CHIP RESISTOR
FR10L 2007-000084 CHIP RESISTOR
FR10R 2007-000084 CHIP RESISTOR
FR11L 2007-000081 CHIP RESISTOR
FR11R 2007-000081 CHIP RESISTOR
FR12L 2007-000078 CHIP RESISTOR
FR12R 2007-000078 CHIP RESISTOR
FR17L 2007-000078 CHIP RESISTOR
FR17R 2007-000078 CHIP RESISTOR
FR18L 2007-000092 CHIP RESISTOR
FR18R 2007-000092 CHIP RESISTOR
FR19L 2007-000124 CHIP RESISTOR
FR19R 2007-000124 CHIP RESISTOR
FR20L 2007-000084 CHIP RESISTOR
FR20R 2007-000084 CHIP RESISTOR
FR23L 2007-000086 CHIP RESISTOR
FR23R 2007-000086 CHIP RESISTOR
FR42L 2007-000086 CHIP RESISTOR
FR42R 2007-000086 CHIP RESISTOR
FR43L 2007-000077 CHIP RESISTOR
FR43R 2007-000077 CHIP RESISTOR
FR44L 2007-000097 CHIP RESISTOR
FR44R 2007-000097 CHIP RESISTOR
FR47L 2007-000097 CHIP RESISTOR
FR47R 2007-000097 CHIP RESISTOR
FR57L 2007-000090 CHIP RESISTOR
FR57R 2007-000090 CHIP RESISTOR
FR58L 2007-000090 CHIP RESISTOR
FR58R 2007-000090 CHIP RESISTOR
FR59L 2007-000092 CHIP RESISTOR
FR59R 2007-000092 CHIP RESISTOR
FR60L 2007-000094 CHIP RESISTOR
FR60R 2007-000094 CHIP RESISTOR
FR61L 2007-000090 CHIP RESISTOR
FR61R 2007-000090 CHIP RESISTOR
FR62L 2007-000090 CHIP RESISTOR
FR62R 2007-000090 CHIP RESISTOR
 Symbol No. Part No. Part Name Description Local
