JVC TH-A25 Service Manual

3-9
Front board
Block No. [0][2][0][0]
RIC5 BA4560 IC 1201-000163
SPK1 3716-001179 TERMINAL
SPK2 3716-001205 TERMINAL
UD100 0401-001090 FR DIODE
UD101 0401-001090 FR DIODE
UD102 0401-001090 FR DIODE
UD103 0401-001090 FR DIODE
UR27 2007-000449 CHIP RESISTOR
ZD5C 0403-001079 Z DIODE
ZD5W 0403-001079 Z DIODE
ZD6C 0403-001079 Z DIODE
ZD6W 0403-001079 Z DIODE
ZD7C 0403-001376 Z DIODE
ZD7W 0403-001062 Z DIODE
ZD8C 0403-001376 Z DIODE
ZD8W 0403-001062 Z DIODE
ZD5FL 0403-001079 Z DIODE
ZD5FR 0403-001079 Z DIODE
ZD5RL 0403-001079 Z DIODE
ZD5RR 0403-001079 Z DIODE
ZD6FL 0403-001079 Z DIODE
ZD6FR 0403-001079 Z DIODE
ZD6RL 0403-001079 Z DIODE
ZD6RR 0403-001079 Z DIODE
ZD7FL 0403-001376 Z DIODE
ZD7FR 0403-001376 Z DIODE
ZD7RL 0403-001376 Z DIODE
ZD7RR 0403-001376 Z DIODE
ZD8FL 0403-001376 Z DIODE
ZD8FR 0403-001376 Z DIODE
ZD8RL 0403-001376 Z DIODE
ZD8RR 0403-001376 Z DIODE
 Symbol No. Part No. Part Name Description Local
E-VR 3406-001047 ROTARY SWITCH
LED1 0601-001238 LED
REYE AC59-60060A MODULE REMOCON
SW2 3404-000165 TACT SWITCH
SW3 3404-000165 TACT SWITCH
SW4 3404-000165 TACT SWITCH
SW5 3404-000165 TACT SWITCH
SW6 3404-000165 TACT SWITCH
SW7 3404-000165 TACT SWITCH
SW9 3404-000165 TACT SWITCH
UC1 2203-000203 CHIP CAPACITOR
UC2 2203-000203 CHIP CAPACITOR
UC3 2401-000485 E CAPACITOR
UC8 2401-000752 E CAPACITOR
UC9 2409-000123 C-EDL
UC10 2203-000979 CHIP CAPACITOR
UC12 2203-000979 CHIP CAPACITOR
UC13 2401-000485 E CAPACITOR
UC14 2401-000243 E CAPACITOR
UC15 2203-000979 CHIP CAPACITOR
UC16 2401-000243 E CAPACITOR
UC20 2401-003336 E CAPACITOR
UC21 2203-000979 CHIP CAPACITOR
UC77 2203-000203 CHIP CAPACITOR
UCW3 3708-000448 CONNECTOR
UCW7 3708-001043 CONNECTOR
UCW12 AH39-00477A LEAD CONNECTOR
UCW13 3711-000907 CONNECTOR
UD1 0401-001090 FR DIODE
UD2 0401-001090 FR DIODE
UD4 0401-001090 FR DIODE
UD5 0401-001090 FR DIODE
UD6 0401-001090 FR DIODE
UD7 0402-000309 FR DIODE
UD8 0401-000101 FR DIODE
UD8 0401-001090 FR DIODE
 Symbol No. Part No. Part Name Description Local
UD10 0401-001090 FR DIODE
UD11 0401-001090 FR DIODE
UD12 0401-000101 FR DIODE
UD77 0401-001090 FR DIODE
UIC1 AH11-00106A MASK ROM
UQ3 0504-000156 DIGI TRANSISTOR
UQ4 0501-000398 TRANSISTOR
UR1 2001-000023 C RESISTOR
UR2 2001-000023 C RESISTOR
UR10 2007-000300 CHIP RESISTOR
UR11 2007-000822 CHIP RESISTOR
UR12 2007-000822 CHIP RESISTOR
UR13 2007-000872 CHIP RESISTOR
UR14 2007-000682 CHIP RESISTOR
UR15 2007-000493 CHIP RESISTOR
UR16 2007-000267 CHIP RESISTOR
UR17 2007-000241 CHIP RESISTOR
UR18 2007-000468 CHIP RESISTOR
UR20 2007-000493 CHIP RESISTOR
UR21 2007-000872 CHIP RESISTOR
UR22 2007-000565 CHIP RESISTOR
UR23 2007-000572 CHIP RESISTOR
UR24 2007-000300 CHIP RESISTOR
UR25 2007-000300 CHIP RESISTOR
UR29 2007-000300 CHIP RESISTOR
UR31 2007-000941 CHIP RESISTOR
UR32 2007-000300 CHIP RESISTOR
UR34 2007-000468 CHIP RESISTOR
UR48 2007-000941 CHIP RESISTOR
UR49 2007-000941 CHIP RESISTOR
UR50 2007-000941 CHIP RESISTOR
UR51 2007-000941 CHIP RESISTOR
UR52 2007-000941 CHIP RESISTOR
UR53 2007-000941 CHIP RESISTOR
UR54 2007-000941 CHIP RESISTOR
UR55 2007-000941 CHIP RESISTOR
UR56 2007-000941 CHIP RESISTOR
UR57 2007-000941 CHIP RESISTOR
UR58 2007-000941 CHIP RESISTOR
UR59 2007-000941 CHIP RESISTOR
UR60 2007-000941 CHIP RESISTOR
UR61 2007-000941 CHIP RESISTOR
UR62 2007-000941 CHIP RESISTOR
UR63 2007-000941 CHIP RESISTOR
UR64 2007-000941 CHIP RESISTOR
UR65 2007-000941 CHIP RESISTOR
UR66 2007-000300 CHIP RESISTOR
UR70 2007-000941 CHIP RESISTOR
UR71 2007-000941 CHIP RESISTOR
UR72 2007-000941 CHIP RESISTOR
UR73 2007-000941 CHIP RESISTOR
UR74 2007-000941 CHIP RESISTOR
UR75 2007-000941 CHIP RESISTOR
UR76 2007-000941 CHIP RESISTOR
UR77 2007-000941 CHIP RESISTOR
UR78 2007-000941 CHIP RESISTOR
UR79 2007-000941 CHIP RESISTOR
UR80 2007-000941 CHIP RESISTOR
UR81 2007-000941 CHIP RESISTOR
UR82 2007-000941 CHIP RESISTOR
UR83 2007-000941 CHIP RESISTOR
UR84 2007-000941 CHIP RESISTOR
UR86 2007-000300 CHIP RESISTOR
UR90 2007-000300 CHIP RESISTOR
UR100 2007-000300 CHIP RESISTOR
UR101 2007-000300 CHIP RESISTOR
UR102 2007-000300 CHIP RESISTOR
UR103 2007-000468 CHIP RESISTOR
UX1 2802-001174 RESONATOR
UZD1 0403-000367 Z DIODE
VFD AH07-00110A VF DISPLAY
XR01 2007-000477 CHIP RESISTOR
 Symbol No. Part No. Part Name Description Local
