3-11
Power board
Block No. [0][2]
R3101 NRSA63J-750X MG RESISTOR 75 Ω 1/16W J
R3103 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R3115 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R3116 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R3117 NRSA63J-333X MG RESISTOR 33k Ω 1/16W J
R3118 NRSA63J-333X MG RESISTOR 33k Ω 1/16W J
R3119 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R3120 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R3121 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R3122 NRSA63J-333X MG RESISTOR 33k Ω 1/16W J
R3123 NRSA63J-333X MG RESISTOR 33k Ω 1/16W J
R3124 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R3126 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R3127 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R3128 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R3130 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R3131 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R3132 NRSA63J-511X MG RESISTOR 510 Ω 1/16W J
R3133 NRSA63J-511X MG RESISTOR 510 Ω 1/16W J
R3134 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R3135 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R3136 NRSA63J-511X MG RESISTOR 510 Ω 1/16W J
R3137 NRSA63J-511X MG RESISTOR 510 Ω 1/16W J
R3138 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R3139 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
L1101 QQR1783-001 CHOKE COIL
L1201 QQR1783-001 CHOKE COIL
L1301 QQR1783-001 CHOKE COIL
L1302 QQR1783-001 CHOKE COIL
L1401 QQR1783-001 CHOKE COIL
L1501 QQR1783-001 CHOKE COIL
L1601 QQR1783-001 CHOKE COIL
L1602 QQR1783-001 CHOKE COIL
L2000 QQL25CK-221Z COIL 220uH K
L3100 QQL25CK-221Z COIL 220uH K
CN200 QGA2501C1-07 CONNECTOR W-B (1-7)
CN201 QGA2501C1-07 CONNECTOR W-B (1-7)
CN202 QGA2501C1-06 CONNECTOR W-B (1-6)
CN203 QGF1036C2-25 CONNECTOR FFC/FPC (1-25)
CN204 QGF1036C2-05 CONNECTOR FFC/FPC (1-5)
CN205 QGA1002C1-03X CONNECTOR W-B (1-3)
CN206 QGF1036C2-15 CONNECTOR FFC/FPC (1-15)
CN208 QGF1205C2-21 CONNECTOR FFC/FPC (1-21)
CN209 QGA2501C1-03 CONNECTOR W-B (1-3)
CN320 QGA2001C1-05 CONNECTOR W-B (1-5)
CN905 QGF1205C2-11 CONNECTOR FFC/FPC (1-11)
 CP200 ICP-N5-T IC PROTECTOR 250mA
EP102 QNZ0136-001Z EARTH PLATE
EP146 E409182-001SM GRAND TERMINAL
J1001 QNB0189-001 SPEAKER TERMINA
J1800 QNS0173-001 JACK
J2600 QND0156-001 S.JACK
J2601 QNN0814-001 PIN JACK
J2700 QNN0828-001 AUX JACK
J2800 QNN0829-001 PIN JACK
J2900 QNN0557-002 PIN JACK
J3000 QNN0570-001 PIN JACK
J3100 NNZ0177-001X CONNECTOR
J3200 QNZ0938-001 USB CONNECTOR
J3300 GP1FMV31RK0F OPTICAL JACK
J3301 GP1FAV30RK0F OPT RECEIVER
K1001 NQR0502-001X FERRITE BEADS
K1002 NQR0502-001X FERRITE BEADS
K1800 NQR0007-002X FERRITE BEADS
K1801 NQR0007-002X FERRITE BEADS
K1802 NQR0007-002X FERRITE BEADS
K2000 QQR0621-001Z COIL
K3100 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K3101 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K3103 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
K3107 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
K3108 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
PP240 QZW0112-001 WIRE CLAMP
X2000 QAX0667-001Z C RESONATOR 8.000MHz
 Symbol No. Part No. Part Name Description Local
 Symbol No. Part No. Part Name Description Local
 IC100 STR-W6765N IC A,UB
 IC100 STR-X6768N IC US,UJ,UG
,UN
IC250 PQ1CG2032FZ IC
IC260 TC74VHC04FT-K-X IC
IC270 KIA431A-T IC
IC850 GP1UE281RKVF IR DETECT
IC900 TC74VHC04FT-K-X IC
Q201 2SJ651 POWER MOS FET
Q204 RT1N141C-X DIGI TRANSISTOR
Q211 KTC3265/Y/-X TRANSISTOR
Q213 ISA1530AC1/QR/X TRANSISTOR
Q214 RT1N441C-X TRANSISTOR
Q231 2SJ632-X POWER MOS FET
Q232 2SC3928A/QR/-X TRANSISTOR
Q251 RTQ035P02-W MOS FET
Q271 RT1N141C-X DIGI TRANSISTOR
Q272 RT1N141C-X DIGI TRANSISTOR
Q273 RT1N141C-X DIGI TRANSISTOR
Q274 RT1P141C-X DIGI TRANSISTOR
Q850 RT1N430C-X TRANSISTOR
 D101 D3SBA60 BRIDGE DIODE
D102 SARS01-T2 FR DIODE
D103 SARS01-T2 FR DIODE
D104 1SS244-T2 SI DIODE
D105 1SS133-T2 SI DIODE
D106 1SS133-T2 SI DIODE
D107 1SS133-T2 SI DIODE US,UJ,UG
,UN
D201 FMN-G12S SI DIODE
D202 MTZJ39D-T2 Z.DIODE
D211 FR104S-T5 FR DIODE
D213 MTZJ2.4B-T2 Z DIODE
D214 FR104S-T5 FR DIODE
D215 1SS133-T2 SI DIODE
D216 MTZJ3.3B-T2 Z DIODE
D231 FR104S-T5 FR DIODE
D232 MTZJ16B-T2 Z DIODE
D233 MTZJ5.1C-T2 Z DIODE
D251 EC30HA04-X SB DIODE
D252 1N4003S-T5 SI DIODE
D253 MTZJ10C-T2 Z DIODE
D261 MTZJ5.6A-T2 Z DIODE
D271 MTZJ10C-T2 Z DIODE
D273 MTZJ20C-T2 Z DIODE
D274 MTZJ20C-T2 Z DIODE
D275 1SS133-T2 SI DIODE
D851 SLR-343VC-T LED
D852 SLR-343VC-T LED
D853 SLR-343VC-T LED
D854 SLR-343VC-T LED
D855 SLR-343VC-T LED
D856 SLR-343VC-T LED
D857 SELU1E54CM-P LED
D858 SELU1E54CM-P LED
D900 1SS133-T2 SI DIODE
D901 1SS133-T2 SI DIODE
 PC101 PC123Y22FZ PHOTO COUPLER
 C101 QFZ9073-154 MM CAPACITOR 0.15uF AC250V
M
A,UB
 C101 QFZ9085-684 M CAPACITOR 0.68uF US,UJ,UG
,UN
 C102 QCZ9134-102 C CAPACITOR 1000pF
 C103 QCZ9134-102 C CAPACITOR 1000pF
 C104 QFZ9073-154 MM CAPACITOR 0.15uF AC250V
M
A,UB
 C105 QEZ0792-227 E CAPACITOR 220uF 400V M A,UB
 C105 QEZ0791-477 E CAPACITOR 470uF US,UJ,UG
,UN
C106 QCZ0136-332Z C CAPACITOR 3300pF 1kV K
C107 QCZ0340-102 C CAPACITOR 1000pF 2kV K
