JVC TH-L1A User Manual

3-13
HDMI board
Block No. [0][3]
DSP board
Block No. [0][4]
HS250 GV40614-001A HEAT SINK
J900 QNZ0689-001 PIN JACK
K900 NQR0007-002X FERRITE BEADS
S861 QSW0683-001Z PUSH SW
S862 QSW0683-001Z PUSH SW
S863 QSW0683-001Z PUSH SW
S864 QSW0683-001Z PUSH SW
S865 QSW0683-001Z PUSH SW
S866 QSW0683-001Z PUSH SW
S867 QSW0683-001Z PUSH SW
S868 QSW0683-001Z PUSH SW
S869 QSW0683-001Z PUSH SW
 TH101 QAD0141-8R0 N THERMISTOR 8 Ω
TH201 NAD0025-103X N THERMISTOR 10k Ω
 VA101 QAF0026-751 VARISTOR 750V
 Symbol No. Part No. Part Name Description Local
IC52 TC7WB125FK-X IC
IC53 CXB1442AR IC
IC55 MM1563DF-X IC
IC56 LD2981ABM50-X IC
IC57 TC7WB125FK-X IC
Q2001 ISA1530AC1/QR/X TRANSISTOR
Q2002 2SC3928A/QR/-X TRANSISTOR
Q2003 2SC3928A/QR/-X TRANSISTOR
Q2004 RT1N141C-X DIGI TRANSISTOR
Q2005 RT1N141C-X DIGI TRANSISTOR
Q2006 RT1N141C-X DIGI TRANSISTOR
Q2007 RT1N141C-X DIGI TRANSISTOR
Q2008 RT1N141C-X DIGI TRANSISTOR
Q2009 RT1N141C-X DIGI TRANSISTOR
Q2010 RT1N141C-X DIGI TRANSISTOR
C2002 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C2004 NCB31HK-471X C CAPACITOR 470pF 50V K
C2006 NCB21AK-225X C CAPACITOR 2.2uF 10V K
C2013 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C2014 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C2015 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C2016 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C2017 NEAF0JM-476X E CAPACITOR 47uF 6.3V M
C2019 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C2036 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C2039 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C2040 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C2051 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C2052 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C2053 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C2070 NCB31CK-104X C CAPACITOR 0.1uF 16V K
R2002 NRSA63F-472X MG RESISTOR 4.7k Ω 1/16W F
R2025 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R2026 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R2027 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R2046 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R2047 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R2048 NRSA63J-183X MG RESISTOR 18k Ω 1/16W J
R2049 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R2050 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R2051 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R2052 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R2053 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R2054 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R2055 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R2056 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R2063 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R2065 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R2066 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R2083 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
 Symbol No. Part No. Part Name Description Local
R2084 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R2085 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R2086 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R2087 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R2088 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R2091 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R2092 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
L2001 NQR0597-001X EMI FILTER
L2002 NQR0597-001X EMI FILTER
L2003 NQR0597-001X EMI FILTER
L2004 NQR0597-001X EMI FILTER
CN51 QGF1016F8-08W CONNECTOR FFC/FPC (1-8)
J2001 NNZ0161-002 CONNECTOR
J2002 NNZ0161-002 CONNECTOR
J2003 NNZ0161-002 CONNECTOR
K2001 NQR0502-001X FERRITE BEADS
K2006 NQR0502-001X FERRITE BEADS
K2008 NQR0502-001X FERRITE BEADS
K2009 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K2010 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K2011 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
VA51 NAF0024-001X ESD SUPPRESSOR V
VA52 NAF0024-001X ESD SUPPRESSOR V
VA53 NAF0024-001X ESD SUPPRESSOR V
VA54 NAF0024-001X ESD SUPPRESSOR V
VA55 NAF0024-001X ESD SUPPRESSOR V
VA56 NAF0024-001X ESD SUPPRESSOR V
VA57 NAF0024-001X ESD SUPPRESSOR V
VA58 NAF0024-001X ESD SUPPRESSOR V
VA59 NAF0018-800X VARISTOR 80V
VA60 NAF0018-800X VARISTOR 80V
VA61 NAF0018-800X VARISTOR 80V
VA62 NAF0024-001X ESD SUPPRESSOR V
VA63 NAF0024-001X ESD SUPPRESSOR V
VA64 NAF0024-001X ESD SUPPRESSOR V
VA65 NAF0024-001X ESD SUPPRESSOR V
VA66 NAF0024-001X ESD SUPPRESSOR V
VA67 NAF0024-001X ESD SUPPRESSOR V
VA68 NAF0024-001X ESD SUPPRESSOR V
VA69 NAF0024-001X ESD SUPPRESSOR V
VA70 NAF0018-800X VARISTOR 80V
VA71 NAF0018-800X VARISTOR 80V
VA72 NAF0018-800X VARISTOR 80V
VA73 NAF0024-001X ESD SUPPRESSOR V
VA74 NAF0024-001X ESD SUPPRESSOR V
VA75 NAF0024-001X ESD SUPPRESSOR V
VA76 NAF0024-001X ESD SUPPRESSOR V
VA77 NAF0024-001X ESD SUPPRESSOR V
VA78 NAF0024-001X ESD SUPPRESSOR V
VA79 NAF0024-001X ESD SUPPRESSOR V
VA80 NAF0024-001X ESD SUPPRESSOR V
VA81 NAF0018-800X VARISTOR 80V
VA82 NAF0018-800X VARISTOR 80V
VA83 NAF0018-800X VARISTOR 80V
 Symbol No. Part No. Part Name Description Local
IC301 MN2DS0018MA IC
IC302 MM1701CH-X IC
IC303 XC2164A51FM-X IC
IC305 MM1563DF-X IC
IC453 S-80830CNNB-G-W IC
IC505 K4S641632K-UC75 IC
IC505 or K4S641632H-UC75 IC
IC509 SG32A90TFIR3 IC(MICRO C ROM)
IC510 BR24L16F-W-X IC(DIGITAL)
IC706 TC7SH08FU-X IC
IC707 TC7SH04FU-X IC
IC801 MM1565AF-X IC
 Symbol No. Part No. Part Name Description Local
