1.7 Importance administering point on the safety
Caution: For continued protection against risk of
fire, replace only with same type 1.6A/125V for
F901, 6.3A/125V for F101, 8A/125V for F153 and
F154.
This symbol specifies type of fast operating fuse.
Precaution: Pour eviter risques de feux, remplacez
le fusible de surete de F901 comme le meme type
que 1.6A/125V, et 6.3A/125V pour F101, et 8A/125V
pour F153 et F154.
Ce sont des fusibles suretes qui functionnes rapide.
^
Power supply board (Forward side)
F901
<Main body section>
F101
<SP-PWM45 subwoofer section>
Speaker terminal board (Forward side)
F153
F154
Mother board (Forward side)
