JVC TH-M42 Service Manual

3-16
Amplifier board
Block No. [0][5][0][0]
C156 QFLC2AJ-104Z M CAPACITOR 0.1uF 100V J
C161 QEZ0223-478 E CAPACITER 4700uF
C162 QEZ0223-478 E CAPACITER 4700uF
C163 QETM1EM-688 E CAPACITOR 6800uF 25V M
C164 QETM1EM-688 E CAPACITOR 6800uF 25V M
C165 QETN1EM-476Z E CAPACITOR 47uF 25V M
C166 QETN1EM-107Z E CAPACITOR 100uF 25V M
C501 QETN1HM-335Z E CAPACITOR 3.3uF 50V M
C502 QFN31HJ-103Z M CAPACITOR 0.01uF 50V J
C503 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C511 QETN1CM-227Z E CAPACITOR 220uF 16V M
C512 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C521 QETN1HM-226Z E CAPACITOR 22uF 50V M
C522 QETN1HM-106Z E CAPACITOR 10uF 50V M
C523 QETN1EM-476Z E CAPACITOR 47uF 25V M
C531 QETN1HM-106Z E CAPACITOR 10uF 50V M
C532 QCF31HZ-103Z C CAPACITOR 0.01uF 50V Z
C533 QCF31HZ-103Z C CAPACITOR 0.01uF 50V Z
R151 QRE141J-222Y C RESISTOR 2.2k Ω 1/4W J
R152 QRE141J-222Y C RESISTOR 2.2k
Ω 1/4W J
R153 QRL027J-391 OMF RESISTOR 390
Ω 2W J
 R161 QRZ9005-100X FUSI RESISTOR 10 Ω
R162 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
 R491 QRL027J-470 OMF RESISTOR 47 Ω 2W J
R492 QRE141J-472Y C RESISTOR 4.7k Ω 1/4W J
R501 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R502 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R503 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R504 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R505 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R506 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R510 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R511 QRE141J-753Y C RESISTOR 75k Ω 1/4W J
R512 QRE141J-223Y C RESISTOR 22k Ω 1/4W J
R513 QRE141J-101Y C RESISTOR 100 Ω 1/4W J
R514 QRE141J-753Y C RESISTOR 75k Ω 1/4W J
R515 QRE141J-223Y C RESISTOR 22k Ω 1/4W J
R516 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R517 QRE141J-224Y C RESISTOR 220k Ω 1/4W J
R518 QRE141J-222Y C RESISTOR 2.2k Ω 1/4W J
R519 QRE141J-332Y C RESISTOR 3.3k Ω 1/4W J
R520 QRE141J-332Y C RESISTOR 3.3k Ω 1/4W J
R521 QRE141J-223Y C RESISTOR 22k Ω 1/4W J
R522 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R531 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R532 QRE141J-101Y C RESISTOR 100 Ω 1/4W J
R533 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R534 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R535 QRE141J-104Y C RESISTOR 100k
Ω 1/4W J
R536 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R537 QRE141J-472Y C RESISTOR 4.7k
Ω 1/4W J
R538 QRE141J-472Y C RESISTOR 4.7k
Ω 1/4W J
R539 QRE141J-472Y C RESISTOR 4.7k Ω 1/4W J
R541 QRE141J-472Y C RESISTOR 4.7k
Ω 1/4W J
R543 QRE141J-472Y C RESISTOR 4.7k
Ω 1/4W J
R544 QRE141J-222Y C RESISTOR 2.2k Ω 1/4W J
R545 QRE141J-123Y C RESISTOR 12k
Ω 1/4W J
R546 QRE141J-222Y C RESISTOR 2.2k Ω 1/4W J
R547 QRE141J-104Y C RESISTOR 100k
Ω 1/4W J
R548 QRE141J-223Y C RESISTOR 22k
Ω 1/4W J
R549 QRE141J-223Y C RESISTOR 22k Ω 1/4W J
R550 QRE141J-102Y C RESISTOR 1k
Ω 1/4W J
 R555 QRZ9005-271X FUSI RESISTOR 270 Ω
R556 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R557 QRE141J-102Y C RESISTOR 1k
Ω 1/4W J
R561 QRE141J-104Y C RESISTOR 100k
Ω 1/4W J
R562 QRE141J-104Y C RESISTOR 100k
Ω 1/4W J
R563 QRE141J-104Y C RESISTOR 100k
Ω 1/4W J
R564 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R565 QRE141J-104Y C RESISTOR 100k
Ω 1/4W J
R566 QRE141J-104Y C RESISTOR 100k
Ω 1/4W J
 CN101 QGA7901C1-02 CONNECTOR W-B (1-2)
 CN102 QGA7901C1-02 CONNECTOR W-B (1-2)
 CN151 QGA3901C1-05 CONNECTOR W-B (1-5)
CN401 QGB2510K2-08 CONNECTOR B-B (1-8)
CN402 QGA3901F2-04 CONNECTOR W-B (1-4)
 Symbol No. Part No. Part Name Description Local
CN403 QGB2510K2-14 CONNECTOR B-B (1-14)
CN404 QGB2510K2-18 CONNECTOR B-B (1-18)
CN501 QGB2510J1-08 CONNECTOR B-B (1-8)
CN503 QGB2510J1-14 CONNECTOR B-B (1-14)
CN504 QGB2510J1-18 CONNECTOR B-B (1-18)
CN521 QGB2510J1-07 CONNECTOR B-B (1-7)
CN522 QGB2510J1-18 CONNECTOR B-B (1-18)
CN531 QGB2510J1-07 CONNECTOR B-B (1-7)
CN532 QGB2510J1-18 CONNECTOR B-B (1-18)
FC101 QNG0003-001Z FUSE CLIP
FC102 QNG0003-001Z FUSE CLIP
FC155 QNG0003-001Z FUSE CLIP
FC156 QNG0003-001Z FUSE CLIP
FC157 QNG0003-001Z FUSE CLIP
FC158 QNG0003-001Z FUSE CLIP
HS151 QZW0115-001 HEATSINK
J401 QND0118-001 DIN CONNECTOR
J402 QNB0162-002 SPK TERMINAL
J403 QNB0161-002 SPK TERMINAL
J404 QNB0162-002 SPK TERMINAL
K401 QQR1277-001Z COIL
K402 QQR1277-001Z COIL
 RY101 QSK0142-001 RELAY
RY401 QSK0127-001 RELAY
RY402 QSK0127-001 RELAY
RY403 QSK0127-001 RELAY
 Symbol No. Part No. Part Name Description Local
 IC201 STK413-490 IC(HYBRID)
3 channel AF
power amplifier
 IC301 STK413-420 IC(HYBRID)
3 channel AF
power amplifier
Q2101 KTA1267/YG/-T TRANSISTOR
Q2201 KTA1267/YG/-T TRANSISTOR
Q2301 KTA1267/YG/-T TRANSISTOR
Q3101 KTA1267/YG/-T TRANSISTOR
Q3201 KTA1267/YG/-T TRANSISTOR
Q3301 KTA1267/YG/-T TRANSISTOR
D2101 1SS133-T2 DIODE
D2201 1SS133-T2 DIODE
D2301 1SS133-T2 DIODE
D2501 MTZJ13C-T2 Z DIODE
D2502 MTZJ13C-T2 Z DIODE
D3101 1SS133-T2 DIODE
D3201 1SS133-T2 DIODE
D3301 1SS133-T2 DIODE
D3501 MTZJ13C-T2 Z DIODE
D3502 MTZJ13C-T2 Z DIODE
C2102 QCBB1HK-471Y C CAPACITOR 470pF 50V K
C2103 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C2104 QETN1AM-107Z E CAPACITOR 100uF 10V M
C2105 QCBB1HK-101Y C CAPACITOR 100pF 50V K
C2106 QCSB1HK-3R3Y C CAPACITOR 3.3pF 50V K
C2107 QFVF1HJ-104Z MF CAPACITOR 0.1uF 50V J
C2108 QFVF1HJ-104Z MF CAPACITOR 0.1uF 50V J
C2202 QCBB1HK-471Y C CAPACITOR 470pF 50V K
C2203 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C2204 QETN1AM-107Z E CAPACITOR 100uF 10V M
C2205 QCBB1HK-101Y C CAPACITOR 100pF 50V K
C2206 QCSB1HK-3R3Y C CAPACITOR 3.3pF 50V K
C2207 QFVF1HJ-104Z MF CAPACITOR 0.1uF 50V J
C2208 QFVF1HJ-104Z MF CAPACITOR 0.1uF 50V J
C2302 QCBB1HK-471Y C CAPACITOR 470pF 50V K
C2303 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C2304 QETN1AM-107Z E CAPACITOR 100uF 10V M
C2305 QCBB1HK-101Y C CAPACITOR 100pF 50V K
C2306 QCSB1HK-3R3Y C CAPACITOR 3.3pF 50V K
C2307 QFVF1HJ-104Z MF CAPACITOR 0.1uF 50V J
 Symbol No. Part No. Part Name Description Local
