JVC TH-M42 Service Manual

3-12
Front board
Block No. [0][2][0][0]
R4866 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R4871 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R4872 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R4873 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R4874 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R4881 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R4883 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R4884 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R4886 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R4891 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R4892 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
 R4921 QRZ9005-100X FUSI RESISTOR 10 Ω
R4922 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
 R4931 QRZ9005-100X FUSI RESISTOR 10 Ω
R4932 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R4941 QRE141J-271Y C RESISTOR 270 Ω 1/4W J
R4942 QRE141J-271Y C RESISTOR 270 Ω 1/4W J
R4961 QRE141J-271Y C RESISTOR 270 Ω 1/4W J
R4971 QRE141J-271Y C RESISTOR 270 Ω 1/4W J
R4972 QRE141J-271Y C RESISTOR 270 Ω 1/4W J
 L901 QQR1105-001 LINE FILTER
L951 QQL244K-R22Z COIL 0.22uH K
L952 QQL44BK-220Z COIL 22uH K
L955 QQL26AK-220Z COIL 22uH K
L957 QQL244K-100Z COIL 10uH K
L959 QQL244K-100Z COIL 10uH K
L4391 QQL25CK-221Z COIL 220uH K
 T901 QQS0097-001 SW TRANSF
CN402 QGD2504C1-04Z CONNECTOR (1-4)
CN403 QGD2504C1-05Z CONNECTOR (1-5)
CN404 QGD2504C1-05Z CONNECTOR (1-5)
CN405 QGF1016C1-23 CONNECTOR FFC/FPC (1-23)
CN407 QGF1016C1-21 CONNECTOR FFC/FPC (1-21)
CN408 QGD2504C1-04Z CONNECTOR (1-4)
CN409 QGD2504C1-04Z CONNECTOR (1-4)
CN410 QGF1205C1-11 CONNECTOR FFC/FPC (1-11)
CN411 QGF1016C1-31 CONNECTOR FFC/FPC (1-31)
CN412 QGF1205C1-06 CONNECTOR FFC/FPC (1-6)
CN414 QGF1205C1-06 CONNECTOR FFC/FPC (1-6)
CN415 QGF1016C1-07 CONNECTOR FFC/FPC (1-7)
CN416 QGD2504C1-05Z CONNECTOR (1-5)
 CP471 ICP-N5-T IC PROTECTOR 250mA
 CP951 ICP-N10-T IC PROTECTOR 400mA
EP401 QNZ0136-001Z EARTH PLATE
EP402 QNZ0136-001Z EARTH PLATE
EP403 QNZ0136-001Z EARTH PLATE
EP901 QNZ0136-001Z EARTH PLATE
EP902 QNZ0136-001Z EARTH PLATE
EP951 QNZ0136-001Z EARTH PLATE
FC901 QNG0003-001Z FUSE CLIP
FC902 QNG0003-001Z FUSE CLIP
FW401 QUM213-11Z4Z4 PARA RIBON WIR
FW901 QUM219-06DGZ4 PARA RIBON WIR
FW902 QUM21A-06DGZ4 PARA RIBON WIR
HS491 LE40505-001A HEAT SINK
HS901 E70306-002 HEAT SINK
HS964 LE40505-001A HEAT SINK
J4402 QNN0572-001 PIN JACK
J4411 QNN0570-001 PIN JACK
J4891 QNS0089-001 3.5 JACK
K902 QQR0621-001Z COIL
 P901 QNC0082-001 AC INLET
SP471 VYH7653-001 IC HOLDER
X4701 QAX0246-001Z C RESONATOR 8.00MHz
 Symbol No. Part No. Part Name Description Local
 Symbol No. Part No. Part Name Description Local
IC501 MN101C35DKW IC(MPU)
FL driver
microcomputer
IC502 GP1UM271XK IR DETECT UNIT Receiver for remote
Q501 KRC102S-X DIGI TRANSISTOR
Q502 KRC102S-X DIGI TRANSISTOR
Q503 KRC102S-X DIGI TRANSISTOR
D501 SLR-342VC-T LED
D551 SELU2E10C-P-T10 LED
C501 NCB31HK-471X C CAPACITOR 470pF 50V K
C502 NCB31HK-471X C CAPACITOR 470pF 50V K
C503 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C504 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C505 QEKC0JM-107Z E CAPACITOR 100uF 6.3V M
C506 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C507 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C541 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C542 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C551 NCB31CK-103X C CAPACITOR 0.01uF 16V K
R501 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R502 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R503 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R504 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R505 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R531 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J
R532 NRSA63J-392X MG RESISTOR 3.9k Ω 1/16W J
R533 NRSA63J-682X MG RESISTOR 6.8k Ω 1/16W J
R534 NRSA63J-153X MG RESISTOR 15k Ω 1/16W J
R535 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J
R536 NRSA63J-392X MG RESISTOR 3.9k Ω 1/16W J
R537 NRSA63J-682X MG RESISTOR 6.8k Ω 1/16W J
R538 NRSA63J-153X MG RESISTOR 15k Ω 1/16W J
R541 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R542 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R551 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R571 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J
R572 NRSA63J-392X MG RESISTOR 3.9k Ω 1/16W J
R573 NRSA63J-682X MG RESISTOR 6.8k Ω 1/16W J
R574 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J
R575 NRSA63J-392X MG RESISTOR 3.9k Ω 1/16W J
CN501 QGF1016F2-21W CONNECTOR FFC/FPC (1-21)
CN551 QGF1006F1-04W CONNECTOR FFC/FPC (1-4)
CN561 QGF1006F1-04W CONNECTOR FFC/FPC (1-4)
DI501 QLF0119-001 FL TUBE
FW561 QUM214-16DGZ4 PARA RIBON WIRE
FW571 QUM214-16DGZ4 PARA RIBON WIRE
JS501 QSW0898-001 JOG VOLUME
S501 QSW0683-001Z PUSH SW
S502 QSW0683-001Z PUSH SW
S503 QSW0683-001Z PUSH SW
S504 QSW0683-001Z PUSH SW
S505 QSW0683-001Z PUSH SW
S506 QSW0683-001Z PUSH SW
S507 QSW0683-001Z PUSH SW
S508 QSW0683-001Z PUSH SW
S509 QSW0683-001Z PUSH SW
S510 QSW0683-001Z PUSH SW
S571 QSW0683-001Z PUSH SW
S572 QSW0683-001Z PUSH SW
S573 QSW0683-001Z PUSH SW
S574 QSW0683-001Z PUSH SW
S575 QSW0683-001Z PUSH SW
S576 QSW0683-001Z PUSH SW
S577 QSW0683-001Z PUSH SW
X501 NAX0623-001X C RESONATOR
